FM radio reception
D300800AHM
How vehicle audio works
AM and FM radio signals are broadcast
from transmitter towers located around
your city. They are intercepted by the
radio antenna on your vehicle. This signal
is then received by the radio and sent to
your vehicle speakers.
When a strong radio signal has reached
your vehicle, the precise engineering of
your audio system ensures the best pos-
sible quality reproduction. However, in
some cases the signal coming to your
vehicle may not be strong and clear. This
can be due to factors such as the dis-
tance from the radio station, closeness of
other strong radio stations or the pres-
ence of buildings, bridges or other large
obstructions in the area.
JBM001
Features of your vehicle
AM radio reception
AM broadcasts can be received at
greater distances than FM broadcasts.
This is because AM radio waves are
transmitted at low frequencies. These
long, low frequency radio waves can fol-
low the curvature of the earth rather than
travelling straight out into the atmos-
phere. In addition, they curve around
obstructions so that they can provide bet-
ter signal coverage.
JBM002
4 1
Advertisement
Related Manuals for Hyundai AC110DFEE
Summary of Contents for Hyundai AC110DFEE
- Page 1 Features of your vehicle When a strong radio signal has reached FM radio reception AM radio reception your vehicle, the precise engineering of your audio system ensures the best pos- sible quality reproduction. However, in some cases the signal coming to your vehicle may not be strong and clear.
- Page 2 Features of your vehicle FM radio station JBM003 JBM004 JBM005 FM broadcasts are transmitted at high • Fading - As your vehicle moves away • Station Swapping - As a FM signal frequencies and do not bend to follow the from the radio station, the signal will weakens, another more powerful sig- earth's surface.
- Page 3 Features of your vehicle Using a cellular phone or a two-way Care of disc • Keep CDs in their cases after use to radio protect them from scratches or dirt. • If the temperature inside the car is too When a cellular phone is used inside the •...
- Page 4 Features of your vehicle ■ ■ ■ ■ CD Player : AC110DFEE/AC110DFCG CD Changer : AC610DFEE/AC610DFCG ❋There will be no ® logo if the Bluetooth feature is not supported. VF_AC110DF_GEN / VF_AC610DF_GEN...
- Page 5 Features of your vehicle matically select channel. Stops at the previous frequency if no channel is found. SEEK • When the button is pressed, it TRACK reduces the band frequency to auto- matically select channel. Stops at the previous frequency if no channel is found.
- Page 6 Features of your vehicle • SCROLL • Return( This function is used to display charac- This function displays the previous MODE ters longer than the LCD text display and screen. can be turned On/Off through the sound quality control knob. •...
- Page 7 Features of your vehicle • PHONE (if equipped) • BASS Control • FADER Control Select this item to enter PHONE setup Press and turn the knob Press and turn the knob BASS TUNE FADER TUNE mode. Refer to “BLUETOOTH PHONE to adjust the bass setting.
- Page 8 Features of your vehicle • RPT : Only a track(file) is repeatedly SEEK • Push button for 0.8 or longer TRACK played back. to initiate high speed sound search of • FLD.RPT (MP3/WMA Only) : Only files current song. in a folder are repeatedly played back. Button (SCAN) Play each song in the CD for 10 seconds.
- Page 9 Features of your vehicle • MP3/WMA : File Name, Title, Artist, Turn the button counterclockwise to dis- CD. If VCD, Data CD are loaded, Album, Folder, Total File play the songs before the currently "Reading Error" message will appear (not displayed if the information is not played song.
- Page 10 Features of your vehicle NOTE: 2. Folder playing order : ❋ If no song file is contained in the Order of playing files (folders) : folder, that folder is not displayed. 1. Song playing order : sequen- tially.
- Page 11 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
- Page 12 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
-
Page 13: Using Usb Device
Features of your vehicle direction in fast speed. • RPT : Only a file is repeatedly played SEEK back. • Press the button for less than TRACK • ‘FLD.RPT’ : All files in a folder are 0.8 seconds to move to the next song. repeatedly played back. - Page 14 Features of your vehicle VF_GEN_USB FOLDER Button • Press FOLDER button to move to child folder of the current folder and display the first song in the folder. Press TUNE knob to move to the folder displayed. It will play the first song in the folder.
- Page 15 • When the iPod cable is connected, iPod DEVICE the system can be switched to AUX • Some iPod models might not sup- • The Hyundai iPod Power Cable is mode even without iPod device port the communication protocol needed in order to operate iPod and may cause noise.
-
Page 16: Using Ipod
Features of your vehicle longer to play the song in reverse Button (MENU) direction in fast speed. Moves to the upper category from cur- SEEK • Press the button for less rently played category of the iPod. TRACK than 0.8 seconds to move to the next To move to (play) the category (song) track. - Page 17 Features of your vehicle VF_GEN_USB TUNE Knob & ENTER Button When you rotate the knob clockwise, it will display the songs (category) ahead of the song currently played (category in the same level). Also, when you rotate the knob counter- clockwise, it will display the songs (cate- gory) before the song currently played (category in the same level).
- Page 18 Features of your vehicle (continued) CAUTION IN USING • Do not place the phone near or ® BLUETOOTH CELLULAR inside metallic objects, otherwise PHONE ® communications with Bluetooth • Do not use a cellular phone or system or cellular service sta- ®...
- Page 19 Features of your vehicle ■ ■ ® General Features Phone Setup BLUETOOTH PHONE OPERATION ® ® • This audio system supports Bluetooth All Bluetooth -related operations can be (if equipped) hands-free and stereo-headset fea- performed in PHONE menu. tures. 1) Push the SETUP button to enter - HANDS-FREE feature: Making or...
- Page 20 Up to 5 phones can be connect following order when the vehicles are HYUNDAI i40, some ® paired with the system. Bluetooth system is enabled: ®...
- Page 21 Features of your vehicle ■ ■ ® Receiving a Phone Call Talking on the Phone • Turning Bluetooth ON/OFF ® Bluetooth system can be enabled (ON) When receiving a phone call, a ringtone When talking on the phone, “Active Calls” or disabled (OFF) by this menu.
- Page 22 Features of your vehicle ✽ ✽ NOTICE ■ Bluetooth ® Audio Music Streaming NOTE: In the following situations, you or the This audio system supports A2DP (Audio • Not only MP3 files, all the sounds other party may have difficulty hearing Advanced Distribution Profile)
