Summary of Contents for Parkray CHEVIN 20DB CVWCHI08FM
- Page 1 CHEVIN INSET 20DB MULTIFUEL CENTRAL-HEATING CE STOVE Instructions for: Installation/Operating/Maintenance/Servicing JINCDW09 REV C 31/07/18...
-
Page 2: Stove Models
STOVE MODELS CHEVIN 20DB CVWSCHI08FM/CVWCHI08FM CVWSCHI08DBFM... -
Page 3: Table Of Contents
Welcome to the Hunter Stoves family and thank you for purchasing a Parkray Chevin stove. This stove was designed and built to be a high-performance heating appliance, and we hope it will bring you great enjoyment. The natural environment is important to us, so our stoves are manufactured to provide you with a clean and efficient burn that will keep you warm through cold winter nights. -
Page 4: Technical Specification
Technical Specification Chevin 20DB Energy Efficiency Class Nominal Heat Output Ancit 15.8kW Energy Efficiency Output to Water Ancit 10.7kW Output to Room Ancit 5.1kW Efficiency Ancit 69.9% Mean CO (@13% O₂) Ancit 0.33% Appliance Mass 128kg Recommended Fuels Wood Seasoned Wood (less than 20% moisture content) Smokeless Anthracite or a manufactured... -
Page 5: Important Information
IMPORTANT INFORMATION PLEASE READ THESE INSTRUCTIONS PRIOR TO INSTALLATION AND OPERATION. KEEP THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE AND SERVICING. THIS APPLIANCE WILL BECOME HOT WHEN USED IN ACCORDANCE WITH THESE INSTRUCTIONS. HUNTER STOVES RECOMMEND THAT AN APPROVED GUARD IS USED TO PROTECT THE YOUNG, ELDERLY OR INFIRM FROM HARM. -
Page 6: Safety
Modification No unauthorized modification of this appliance should be carried out. Safety WARNING! This appliance will be hot when in operation and due care should be taken. The supplied gloves may be used to open the door and operate the air controls. Aerosols Do not use an aerosol spray on or near the stove when it is alight. -
Page 7: Removing Internal Components
Removing Internal Components All internal components must be removed prior to fitting the stove. This will make handling the stove easier; allow access to fixings and the flue outlet; as well as protect the internal components from damage during the installation process. -
Page 8: Appliance Dimensions
Remove the cam bar and cam bar cover by lifting the cam bar from the left-hand side until clear of the support. Slide the cam bar to the left and remove. Remove the rear grate support by lifting the support clear of the locating slots and remove. -
Page 9: Pre-Installation/Legal Requirements
Pre Installation Requirements LEASE CHECK THE FOLLOWING Any existing chimney/flue system must be confirmed as suitable for this appliance as defined in Building Regulations Document J. It must be swept and inspected, by a competent person (see notes), to confirm that is structurally sound and free from cracks and obstructions. - Page 10 Building Regulations, Local Authority Byelaws, European and National Standards and other specifications or regulations as they affect the installation of the stove. It should be noted that the Building Regulations requirements may be met by adopting the relevant recommendations given in British Standards BS 8303, BS 6461 and BS 7566 as an alternative means to achieve an equivalent level of performance to that obtained following the guidance given in Approved Document J.
-
Page 11: Clearances
from the appliance may be reduced to a thickness of 75mm. Ensure the inter-connecting flue pipe also has adequate clearances to combustible materials The walls surrounding the stove will become hot and should therefore be finished in a heat resistant plaster. Do not hang pictures, plasma screen televisions or ornaments above the stove, as these could be damaged and could potentially create a fire hazard. -
Page 12: Installation Instructions
Fire Surrounds Please check the suitability of any fireplace/surround for closed solid fuel appliances before installation. Hunter Stoves cannot be held responsible for any fault arising through incorrect use or installation. Fire surround back panels suitable for solid fuel are usually in three sections and slabbed. Many fire surrounds are suitable only for use with gas and electric fires and therefore not suitable for solid fuel. - Page 13 9. Connect the flue – see ‘Flue connection’. 10. Infill around the stove with vermiculite concrete. 11. Fill in the access for the boiler pipe connections. 12. Fill in the top access. Flue Connection N.B. An adjustable flue bend may be required for some installations. If connecting to a stainless liner, a propriety single wall flue adaptor will be required.
-
Page 14: Installation Of Heating & Hot Water
Installation Of Heating And Hot Water System We strongly recommend that a knowledgeable, experienced and qualified plumbing and heating engineer is responsible for the design and installation of the heating and hot water system. Hunter Stoves Ltd cannot accept responsibility for any consequential loss, however caused, due to under or over specification of the appliance in any installation. - Page 15 Four Tapping System Time Switch Room Thermostat High Limit Thermostat 90°C Circulating Pump Low Limit Thermostat (45°C) Drain Cock Two Tapping System Time Switch Room Thermostat High Limit Thermostat 90°C Circulating Pump Drain Cock Low Limit Thermostat (45°C) Injector Tee...
-
Page 16: Commissioning And Handover
Commissioning and Handover Appliance Check Please check that all components are correctly assembled and working correctly. Ensure the Air Controls are working correctly. Hunter Stoves recommend that you carry out a smoke draw test to check the soundness of the chimney/flue system and seals: Place a Smoke Pellet in the centre of the Grate, ensure that all of the Air Controls are fully open and close the Door. - Page 17 Using The Appliance For The First Time We recommend that the appliance is left for 24 hours after installation to allow the fire cement, fixing glues, etc. to cure. We also recommend that you have two or three small fires before you operate your stove to its maximum heat output.
- Page 18 Lighting Slide the baffle into its open position (see Baffle Operation below) and open secondary air control fully and light one or two firelighters placed centrally on the grate, allowing the flames to become established before placing several pieces of small dry kindling in a criss-cross fashion above the firelighters, taking care not to smother the fire. Close the stove door.
- Page 19 Loading The Appliance (Sold Mineral Fuel) Solid mineral fuel should not be stacked higher than the top of the fuel retainer as this may result in damage to the stove. With a full load of fuel, the stove will need to be refuelled approximately once every 4 hours. Air Controls (Sold Mineral Fuel) Solid mineral fuel burns most efficiently with the secondary air control around the 20% open position.
-
Page 20: Maintenance And Servicing
Maintenance And Servicing WARNING! NO unauthorised modification of this appliance should be carried out. IMPORTANT In order to ensure continued compliance with current Building Regulations and Local Authority Byelaws, this appliance requires regular maintenance by a competent person. N.B. Refer to the ‘Removing Internal Components’ section of the installation instructions for details on how to remove each component. -
Page 21: Annual Service
Chimney And Flue Ways It is important that the chimney, flue ways and any connecting flue pipe are swept regularly. This means at least once a year for smokeless fuels and at least twice a year for wood and other fuels. The baffle will need to be removed from its supports in order to sweep the chimney. -
Page 22: Troubleshooting
Troubleshooting ISSUE CAUSE RESOLUTION Problem starting the fire and Low flue draught Speak to your installer keeping it burning Wood with moisture content over 20% Ensure use of dry seasoned wood with less than 20% moisture content Unable to control fire High flue draught Speak to your installer Short burn time... -
Page 23: Optional Extras
ISSUE CAUSE RESOLUTION Creosote build-up in chimney Wood with moisture content over 20% Use dry seasoned wood (less than 20% moisture content). Operate at a high temperature for short periods each time the appliance is used to avoid large build-ups of tars and creosotes. -
Page 24: Spares Information
Spares Information INGLE OUBLE OORS IGHT... -
Page 25: Spares
Body Assembly Spares... -
Page 26: Installation & Commissioning Check List
Commissioning And Installation Checklist PURCHASE INFORMATION Dealer/Retailer Name Address Telephone Number Email Date Purchased INSTALLER INFORMATION Installer Name Address Telephone Number Email APPLIANCE INFORMATION Date Installed Appliance Stock Code Appliance Description Serial Number COMMISSIONING CHECK (Complete & Sign) Does the chimney/flue system meet the appropriate standard? Has the chimney/flue system been swept and passed the soundness test? Has this appliance passed the smoke test? Has this appliance passed the spillage test? -
Page 27: Service Records
Service Records... -
Page 28: Full Warranty Information
Hunter Stoves Group Ltd Extended 5 and 10 Year Warranty 2-year standard warranty Any appliance bought through the showroom of an authorised Hunter Stoves Group dealership will automatically be covered by our standard 2-year conditional guarantee. However, this standard 2-year warranty can be extended to a 5 year or 10-year conditional warranty dependent on the model type (5 years- Boiler models, 10 years- Room heater and Gas models). - Page 29 For Gas Stoves: Gas pilot assemblies Thermocouples and Oxy pilots Ceramic log & coal 'fuel -effects' For both Solid Fuel and Gas Stoves: The paint or surface covering of the appliance: Damage to the paint surface caused by the appliance being stored in a damp and cold environment is not covered on the warranty.
- Page 30 Further Information For extra guidance on using your stove, please visit our YouTube channel by searching ‘Hunter Stoves Group’ or see the helpful hints section of our website; www.hunterstoves.co.uk. This appliance is suitable for continuous burning. This appliance is not suitable for use in a shared flue. All genuine Hunter Group spares can be purchased through our website www.hunterstoves.co.uk/spares or through your authorised dealer.
