Summary of Contents for Lacanche LAE 010 CKG
- Page 1 10-2016...
-
Page 2: Table Of Contents
→ If the appliance is to be built in between two surfaces, it is CRUCIAL to allow free circulation of air behind the appliance (provide shielding at rear). Cooktops should NEVER be installed lower INSTALLER’S MANUAL LAE 010 CKG than adjacent worksurfaces. It is also recommended to allow the unit front panel to protrude 50 mm relative to the adjacent units. -
Page 3: Technical Date Lag 010 Ckg
TECHNICAL DATA LAG 010 CKG Hop top, gas lava rock chargrill left or right of central hob (depending on model). Charcoal: ► A 4-kW gas burner, controlled by a thermocouple safety valve. Hob top option ► A 260 x 460 mm grill resting on pillars is located above the fire tray. ►... -
Page 4: Adjustment Of The Hob Burner
CHANGE OF GAS ADJUSTMENT OF THE HOB BURNER Lacanche’s gas appliances are delivered fully adjusted in compliance with relevant regulations and Lacanche’s gas appliances are delivered fully adjusted in compliance with relevant regulations and for use with the particular gas supply (type, pressure) stated in the purchase order and indicated in for use with the particular gas supply (type, pressure) stated in the purchase order and indicated in the appliance’s nameplate. -
Page 5: Gas Circuit
GAS CIRCUIT ELECTRICAL CIRCUIT DIAGRAM 1 2 3 4 650800012 See tab. 6 in appendix 6516295 65062010 6551764 65062011 65412010 65330007 6551539 Note: Ignition controller terminal lugs not in use are to be grounded. INSTALLER’S MANUAL INSTALLER’S MANUAL 10-2016... - Page 6 TECHNICAL DATA LAE 010 CKG Charcoal: Hop top, electric chargrill left or right of central hob (depending on model). ► Power: 2.5 kW. Hob top option ► A 260 x 460 mm grill resting on pillars is located above the fire tray.
-
Page 7: Electrical Circuit Diagram
ELECTRICAL CONNECTION ELECTRICAL CIRCUIT DIAGRAM The installation must be carried out in accordance with recognised best practices, the instructions given For references and descriptions of the various components refer to table 9 in appendix 0. in this manual and the regulations in force in the country of installation. BEFORE CONNECTION: 230 V1N~ Check that:... - Page 8 Hob top options «LAG 010 CKG» «LAE 010 CKG» USER’S MANUAL IMPORTANT It must be installed in accordance with the applicable regulations and standards in an adequately ventilated room. Any changeover to a gas other than that for which the cooker is set up must be carried out by a qualified installer.
-
Page 9: User's Manual
GAS HOB ELECTRIC CHARGRILL Useful hint: Before use, it is imperative to remove all the internal and external plastic packaging & coating, failure CAUTION: to do so will cause irreversible damage to the steel body. Initial usage will cause some smoke and is no cause for alarm. →... -
Page 10: Cleaning And Maintenance
CLEANING AND MAINTENANCE Before any cleaning work, close the gas supply and/or isolate from the mains electricities supply Do not use a steam cleaner to clean the range. Wait until the fire tray has at least partially cooled. Cooking grill: After use, scrub the grill on which the food has grilled with a metal brush, whide still hot.
