TotalScan
Transducer
Installation manual
ENGLISH
www.simrad-yachting.com | www.lowrance.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LOWRANCE TotalScan and is the answer not in the manual?

Questions and answers

Summary of Contents for Simrad LOWRANCE TotalScan

  • Page 1 TotalScan Transducer Installation manual ENGLISH www.simrad-yachting.com | www.lowrance.com...
  • Page 2 Trademarks: Lowrance ® ® and Navico are registered trademarks of ® Navico. Simrad is used by license from Kongsberg. This manual refers to the following Navico products: DownScan Imaging™ (DownScan), DownScan Overlay™ (DownScan Overlay), ® ® StructureScan (StructureScan), and StructureScan (StructureScan HD).
  • Page 3 Copyright: Copyright © 2017 Navico Holding AS. Preface | TotalScan Transducer User Manual...
  • Page 4: Check The Contents

    Check the contents Included with the TotalScan Transducer, is the transom mounting bracket assembly parts, and a hardware mounting kit. The transducer has a 7 m (24 ft) cable attached. Bracket Insert/name plate Transducer Plug Cable cover Transom mounting plate Hardware mounting kit (included) Transom mount screws #10x1-1/4"...
  • Page 5 Hardware mounting kit (included) Transducer attachment screws M4x8mm (6) Transducer attachment lock washers M4 (6) Zip ties (2) Required tools and supplies (not included) Drill Phillips (cross-head) screwdriver Drill bits Marine high-grade above- or below- waterline sealant/adhesive compound Check the contents | TotalScan Transducer User Manual...
  • Page 6: Installation

    Installation Mounting options The transducer can be mounted on the transom, jackplate, or step. Use the following table to determine which mounting option is best suited to your boat/installation preferences. Ú Note: Before drilling any holes, ensure that holes are drilled in a safe position.
  • Page 7 Direct Step mount (Flush bracket) Requires separately sold Skimmer Flush mount kit (part no. 000-12602-001) Step mount (Transom bracket) Transom mount (Transom bracket) TotalScan Transducer mounting options • Keeps transducer in the water when the boat is on plane, allowing you to track Transom mount bottom at high speeds (Transom bracket)
  • Page 8: Transducer Angle

    TotalScan Transducer mounting options • Transducer is not in the water when boat "Direct Step mount (Flush is on plane; protects transducer and bracket)" on page 10 prevents drag from transducer Requires separately • Transducer angle cannot be adjusted so sold Skimmer Flush it is parallel with the water mount kit (part no.
  • Page 9 be in the water when you are on plane, or can be mounted so it is only in the water when you are moving at trolling speed. Transom and Step mount (fiberglass) supplies (not included) 3 mm (1/8”) Drill bit (Transom Marine high-grade above- or mount pilot holes) below-waterline sealant/...
  • Page 10: Direct Step Mount (Flush Bracket)

    Run the transducer cable up through the grommet on the mounting bracket (F) Reattach the transducer bracket to the transom mounting plate Set the transducer to the desired angle and tighten the bracket assembly bolt (with washers) and nylon lock nut Snap the cable cover into place (H).
  • Page 11 Direct Step mount (Flush bracket) installation Ú Note: Do not install the transducer under the hull. You can mount the transducer in either direction; with the cable coming out towards or away from the transom when installing with the direct step (Flush bracket) mount. Ú...
  • Page 12: Jackplate Mount (Transom Bracket)

    Direct step mount bracket and supplies (not included) Maximum 5 mm (#10 or 3/16”) self-tapping metal screws To direct step mount using flush bracket Make sure the boat’s step is the same length or longer than the transducer. After selecting a mounting location, route the transducer cable to the location where the display will be installed.
  • Page 13 Ú Note: Jackplate mount requires the separately sold 'StructureScan 3D, StructureScan HD & TotalScan Skimmer Transom mount kit' (part no. 000-12603-001). The transducer transom bracket can be mounted inside or outside of the jackplate by drilling through the jackplate and then running bolts through the hinge hole in the side of the bracket into the jackplate.
  • Page 14 Slide M6 bolts with washers into each hole on the side of jackplate. Guide the bolts through the Transducer mounting bracket holes. Place a washer over the end of the bolts and tighten the nuts. Connect the transducer cable to the display sonar port. After the transducer is connected and your boat is in the water, turn on the Flip Left/Right feature in your display unit to ensure what is shown on the left and right side on your display corresponds with...
  • Page 15 Dimensions Transducer and transom mount bracket 74.5 mm 292 mm (11.49”) (2.93”) 59 mm 258 mm (10.15”) (2.32”) Transducer cable 7 m (24’) 47.9 mm (2”) 24.5 mm (0.97”) A 26mm (1”) diameter hole is recommended for cable clearance. Dimensions | TotalScan Transducer User Manual...
  • Page 16: Parts And Accessories

    Parts and accessories The most up-to-date parts and accessories are available at: www.simrad-yachting.com or www.lowrance.com. TotalScan Transducer (000-12568-001) Includes transducer, transom mounting bracket, and assembly and mounting screws, washers, and nuts. TotalScan (plastic) Skimmer Transom mount kit (000-13522-001) Includes transom mounting bracket, and bracket assembly and mounting screws, washers, and nuts.
  • Page 17: Specifications

    Specifications Sidescan specifications Max Range 455 kHz - 182 m (600 ft) total, 92 m (300 ft) on each side 800 kHz - 60 m (200 ft) total, 30 m (100 ft) on each side Max Speed 56 kph (35 mph) Mark objects 24 kph (15 mph) Optimum speed...
  • Page 18: Troubleshooting Tips

    Troubleshooting tips Troubleshooting tips • Check transducer cable is connected to display unit • Check sonar is enabled in display unit, Sonar data is not refer to display unit Operator manual displayed • Check transducer is submerged in the water No depth Check range or turn on auto range Data washed out /...
  • Page 20 www.simrad-yachting.com...
