Kenwood TS-850S Instruction Manual

1
2
Button/Knob Initial Setting
fcw means fully clockwise
1
POWER OFF (out)
DIM BRIGHT (out)
VOX/MAN MAN (out)
FULL/SEMI
AIP OFF
HIGH BOOST OFF (out)
2
REC/SEND REC (out)
THRU/AUTO AUTO (in)
AT TUNE
AGC SLOW
KEY SPEED
CAR fccw
ATT OFF (out)
PROC PROC (in)
MONI 12 o'clock
MIC 12 o'clock
PWR fcw
METER ALC then SWR
FILTER 8.83/455
MODE: LSB 9.5 mHz USB
USB CW FM
Quick Memo
VOICE
3
NOTCH OFF (fccw)
SQL OFF (fccw)
NB LEVEL OFF (fccw)
NB2 WIDTH OFF (fccw)
TF-SET
A=B
RX and TX
1MHZ U/D
F.LOCK
4
DOWN/UP
RIT/XIT OFF (out)
NOTCH OFF (out)
NB1 OFF (out)
NB2 OFF (out)
RIT/XIT zero/zero
TONE fcw
AF/RF AF fccw, RF fcw
M.CH/VFO.CH Memory Channel
SLOPE TUNE HIGH fccw LOW fcw
Discone/Discage
function
fccw means fully counterclockwise
check external power supply
panel lights
sound-actuated transmission
CW break
reduces interference
emphasizes high freq xmit audio
manual PTT
antenna tuner on
in auto, forces antenna match
how fast gain control reacts to changes
CW keyer
carrier level during CW, AM and FSK
attenuates input signal
speech processor
monitor own xmit signal
microphone gain
transmit power for SSB 100 w
check mic w/ALC; meter function in xmit
IF filter selectivity
auto switchover; check antenna
(Discone/Discage)
read/write to quick memory
optional voice synthesizer
reduce heterodyne or CW
reduce background noise
noise blanker
woodpecker noise
check freq in split mode
equalize VFO A and VFO B freq, mode
split opn; VFO A active, B inactive
Up/Down switches 1 MHz or Ham bands only
locks freq, but not RIT
change amateur band
incremental tuning
reduce heterodyne or CW
pulse type noise (auto ignition)
long pulse (woodpecker)
shift receiver w/o xmit OR xmit w/o receiver 1.2 kHz
receiver audio tone
Audio volume/HF amp gain
10 kHz during VFO operation
cuts high/low frequency interference
Numeric Keypad: FINE tuning toggle; Ent freq Ent
3
4
Manual Reference
LSB+ON 35 4-10-15
10 4-10-11
10
10
10
12
12, 30 4-9
12
12,13,16,20
13
13
13
13 4-3-2
12
13
13
14
14
4-3-1
4-10-2 audible CW
15,40 4-11-13
15
12,33 4-10-9
12
12,29
12,29
15,32 4-10-8
15,32
32 4-10-8
15
15
4-10-5
15
12,33 4-10-9
12,34 4-10-9
15,34 4-10-3
15
16
16,29
15,19,32 4-2 4-10-9
