NetApp H Series Installation And Setup Instructions

NetApp H-series Element storage nodes
Installation and Setup Instructions
Prepare for installation | Stage 1
UID
NODE B NODE B
NODE A NODE A
UID
In the box
Chassis
(for H410S nodes)
H610S storage node
(order dependent)
You provide
Access online
A0 A1 A2 A3 A4 A5 B0 B1 B2 B3 B4 B5 C0 C1 C2 C3 C4 C5 D0 D1
Rack space
(order dependent)
H410S: 2U per chassis
H610S: 1U per chassis
SFP28/SFP+
direct-attach cables
or transceivers
• End User License Agreement
• Hardware Universe (HWU)
• NetApp HCI Documentation Center
Prepare Install
for installation hardware
1
UID
NODE D NODE D
HCI
NODE C NODE C
UID
D2 D3 D4 D5
H410S storage node
(order dependent)
Power cables
(Two per chassis)
USB stick
CAT5e or higher cable
with RJ45 connector
H410S storage nodes: Optional,
for out-of-band management
H610S: Required for out-of-band
management and cluster management
• NetApp HCI Resources page
• NetApp SolidFire Resources page
• SolidFire and Element 11.3 Documentation Center
Cable Configure
the node the node
2 3
Slide rail kit
(optional)
Create a
new cluster
4 5
Monitor with a
VGA connection
and keyboard with
a standard USB
connection
Any operating
system (OS) client
with a browser
215-14249_A0
