SECOLink P16 Wiring Manual page 5

Intruder alarm system
Normally closed
contact with one
contact
(NC)
Control panel or
module
+AUX COM Z1 COM +AUX COM
12V T1 T2 NC C 12V
Tamper
Detector
Wiring of double zones
Control panel
+AUX COM Z1 COM
300Ω 1kΩ
12V T1 T2 NC* C
Tamper
Detector A
* - Detector contact must be NC or NO.
To -Z5F
Control
panel
2,2kΩ
-Z5F +Z5F
2,2kΩ 2,2kΩ
Terminals of smoke detector
Note: smoke detectors, produced
NO
by different manufacturers, may
have a different terminals layout.
Detector
For more information
detector wiring manual from
manufacturer.
Normally closed Normally closed
contact with two
resistor resistors
(NC/EOL) (NC/DEOL)
Control panel or Control panel or
module module
Z1 COM +AUX COM
1kΩ
T1 T2 NC C 12V
Tamper
Detector Detector
620Ω
12V T1 T2 NC* C
Tamper
Detector B
Wiring of 2-wire smoke detector
Smoke detectors can be triggered by dust. Therefore, to prevent
false alarms, it is recommended to verify the fire alarm. For
verification, the user must activate system settings listed bellow.
Zone settings:
Zone address: 00_5 (control panel zone terminals -Z5F, +Z5F);
Zone loop type: NO/EOL;
Zone definition: 24h smoke;
Attribute assigned to a zone: Fire verification;
Reset time must be set;
System times settings:
Detector settling time must be set;
Fire verification time must be set;
To +Z5F
Operation: In order to check the triggered fire detector, the
power supply of the detector has to be turned off and turned on
again. The system turns the -Z5F off for a Reset time. When the
reset time expires, the system turns the -Z5F on again and waits for
the detector to settle down (Detector settling time). After that, the
system checks the detector again for a time period set in the menu
check
under the Fire verification time setting. If the fire detector is
triggered again, it means the alarm was real.
Wiring of zones
Wiring of single zones
Normally open contact
(NO)
Control panel or
module
Z1 COM +AUX COM
1kΩ 1kΩ
T1 T2 NC C 12V T1 T2
Tamper Tamper
Detector
Control panel
Detector B
Detector A
Wiring samples
Control Panels P16, P32, P64
Normally open contact
with one resistor
(NO/EOL)
Control panel or
module
Z1 COM +AUX COM Z1 COM
1kΩ
NO C 12V T1 T2 NO
Tamper
Detector
ATTENTION! Avoid power supply loops
Correct wiring
Detector
Cable
Detector
Cable
Control
panel
Wrong wiring
Detector
Cable
Detector
Cable
Control
panel
Control panel or
module
+PGM COM
D1
Relay
NC NC NO NO
It is recommended to use
supress voltage surges on relay.
Wiring manual
Normally open contact
with two resistors
(NO/DEOL)
Control panel or
module
+AUX COM Z1 COM
1kΩ 1kΩ
C 12V T1 T2 NO C
Tamper
Detector
Detector
Cable
EXM800
Detector
EXM800
Wiring of relays
Control panel or
module
+AUX -PGM
D1
Relay
NC NC NO NO
diode to
Page 5
