Diamatic BMG-535 Operating Manual

Planetary grinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SECTION 2
SAFETY INSTRUCTIONS
Technical Data
Safety Instructions
General
Transport
Initial Operation
Operation
Maintenance
Electrical Systems
Fault Diagnosis
Spare Parts
Grinding & Polishing
Grinding & Polishing
1
2
3
4
5
6
7
8
9
10
MODEL BMG-780 GRINDER
MODEL
BMG-535
Planetary Grinder
OPERATING MANUAL
JANUARY 2008
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BMG-535 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Diamatic BMG-535

Summary of Contents for Diamatic BMG-535

  • Page 1 MODEL BMG-780 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS JANUARY 2008 Technical Data Safety Instructions General MODEL Transport BMG-535 Planetary Grinder Initial Operation Operation Maintenance Electrical Systems Fault Diagnosis Spare Parts Grinding & Polishing Grinding & Polishing...

  • Page 2: Technical Data

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 1 TECHNICAL DATA APRIL 2009 CONTENTS – SECTION 1 Rating Unit specifications Operative range and correct usage Stand-by power supply Machine type designation Grinding & Polishing...
  • Page 3 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 1 TECHNICAL DATA APRIL 2009 1.1 RATING Unit / Designation: Grinding Machine Machine Type: BMG-535 Manufacturer: 13201 North Santa Fe Utrechthaven 12 Oklahoma City, OK 73114 3433 PN Nieuwegein United States of America THE NETHERLANDS Local: 405-478-3440 T +31(0)30 –...
  • Page 4 In these cases, the user takes responsibility for all risks. 1.4 STAND-BY SUPPLY (GENERATOR) If the BMG-535 is to be operated using power from a generator, the generator must be operated in accordance with the current U. S. National Electric Code guidelines or European VDE...

  • Page 5: Safety Instructions

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 CONTENTS – SECTION 2 Warnings and symbols Organizational measures Personnel selection and qualification Safety precautions applicable to some operating sequences Special work within the scope of use of the equipment and maintenance...

  • Page 6: General

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 2.1 WARNINGS AND SYMBOLS The following denominations and symbols are used in the Operating Instructions to highlight areas of particular importance: Symbol of operational safety. In these Operating Instructions this symbol will be...
  • Page 7 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 Indicates where consultation with the manufacturer is required. Instructions relating to periodic checks. Reference to important instructions contained in the Operating Instructions. 2.2 ORGANIZATIONAL MEASURES These Operating Instructions are to be kept with the machine, and...
  • Page 8 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 From time to time the working practices of the operators are to be checked by a supervisor, especially regarding awareness of safety and hazards. Operators must tie back long hair, and not wear loose clothing or jewelry including rings.
  • Page 9 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 2.3 PERSONNEL SELECTION AND QUALIFICATION Fundamental duties: Work on the machine may only be undertaken by trained personnel. Only trained personnel may be employed. Note the statutory minimum age.
  • Page 10 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 Check the machine visually for any damage and defects at least once a day. In the event of operational malfunctions the machine must be shut down immediately and secured.
  • Page 11 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 2.5 SPECIAL WORK WITHIN THE SCOPE OF USE OF THE EQUIPMENT AND MAINTENANCE ACTIVITIES AS WELL AS REPAIRS DURING OPERATION Mechanical servicing work: Put the machine in the Safety off position as described in Section 2.6 before carrying out any service work on the machine.
  • Page 12 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 Observe the local waste disposal regulations; in uncertain situations ask the next higher authority. Do not use any aggressive cleaning materials. Only use lint-free cleaning cloths. Always verify that any bolted connections that were loosened during service and maintenance work are properly secure and tight.
  • Page 13 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 2 SAFETY INSTRUCTIONS APRIL 2009 2.7 GENERAL SAFETY CONSIDERATIONS Any machine, if it is not used according to regulations, may be hazardous during operation, set-up and servicing. The machine owner is responsible for compliance with the safety regulations...
  • Page 14 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 CONTENTS – SECTION 3 Range of application Scope of supply Description of the machine Operating elements Electric components Upper part Lower part Tensioner upper belt Tensioner lower belt 3.10 Pulley 3.11 Center pulley...
  • Page 15 SECTION 3 GENERAL APRIL 2009 3.1 RANGE OF APPLICATION Typical ranges of applications for the BMG-535 are for example: • To remove undulated concrete surfaces • To prepare the surface for coatings • To polish the surface • To remove coating defects •...
  • Page 16 Pulley Dust Control Seal Wheel The BMG-535 has a working width of 535 mm and gives excellent performance due to its economic efficiency and easy handling. The machine is capable of leveling uneven and undulating floors. This process is suitable for an optimization of surfaces prior to blast cleaning.
  • Page 17 3.4 OPERATING ELEMENTS Fig. 3.2 Before Switching on the BMG-535, the front part of the grinding machine must be lifted by pushing the handgrip (1) down toward floor level till the front of the machine is approximately 4 inches (10 cm) from the ground.
  • Page 18 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.5 ELECTRIC COMPONENTS The Pushbutton mounted on the Steering Handle is used to control all elements of the machine. The Control Panel contains the main disconnect, safety switch, and hour meter.
  • Page 19 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 Emergency Stop This red mushroom-shaped switch when pressed will immediately cut off the power supply to the panel and motor and bring the machine to rest. To restart the machine the switch must be reset.
  • Page 20 APRIL 2009 3.6 UPPER PART The upper part of the BMG-535 is where the drive system for the machine is located. The rotational drive is powered through a speed reduction drive belt and pulley system, which also gives rotation to the grinder head and drive to the center pulley.
  • Page 21 APRIL 2009 3.7 LOWER PART The lower part of the BMG-535 is where the drive pulleys and the diamond tool holders are fitted. On the driving pulley, there is a coupling which is driven by the electric motor. Between the driving pulley and the driven pulley, there is the main drive belt.
  • Page 22 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.8 TENSIONER UPPER BELT The upper belt tensioner keeps the upper belt tight. By taking off the cover of the upper part, the tensioner can be accessed. Fig. 3.6 Axle Flat Head Socket Cap Screw Retaining ring ...

  • Page 23: Table Of Contents

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.9 TENSIONER LOWER BELT The lower belt tensioner keeps the lower belt tight. By taking off one of the two inspection hole covers at the bottom of the lower plate the tensioner can be accessed.
  • Page 24 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.10 TOOLING DRIVE PULLEY There are three pulleys in the machine. Under these pulleys the diamond discs are fixed. The pulley is driven by the driving pulley through a belt. The pulley is fixed on the lower housing with screws.
  • Page 25 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.11 CENTER PULLEY The center pulley will slow down the speed of the lower housing. The six head cap screws connect the pulley with the lower housing. Fig. 3.9 Sprocket...
  • Page 26 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.12 CONTRA PULLEY The contra pulley gives a reduction of speed to the lower housing. The belt pulley is driven by a belt from the motor pulley. Fig. 3.11 Axle...

  • Page 27: Axle

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.13 DRIVING PULLEY On the driving pulley shaft, there is a coupling which is driven by the electric motor. The driving pulley drives the three pulleys with a belt. The pulley is fixed on the lower housing with screws.

  • Page 28: Flat Washer, Wide

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.14 DIAMOND TIPPED CUTTING TOOL HOLDER The diamond tool holder is connected under the pulley by three bolts. There are 3 soft buffers so the energy from the diamond disc will be softened.
  • Page 29 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 3.15 DIAMOND TOOLING There are three types of tooling that can be put under the diamond tooling. The three types are: Diamond Segments Polycrystalline (PCD) Diamond Segments Polishing Resins Diamond Segments The diamond tools are designed for use on concrete floors.
  • Page 30 Only use genuine parts. Generally the grinding machine BMG-535 requires very little special attention regarding its maintenance. Verify that any wastes or fiber residues do not remain in the area of the grinding disc.
  • Page 31 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 3 GENERAL APRIL 2009 ________________________________________________________________ Notes ________________________________________________________________ Grinding & Polishing...
  • Page 33 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 4 TRANSPORT ARRIL 2009 CONTENTS – SECTION 4 Unit specifications Manual mode of moving the machine Transport with cranes or lifts Transport of the machine with vehicle Operation of the machine while grinding 4.1 UNIT SPECIFICATIONS...
  • Page 34 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 4 TRANSPORT ARRIL 2009 4.2 MANUAL MODE OF MOVING THE MACHINE To move the machine, press down the handgrips of the machine (see fig.3.2) until the front part rises off the ground and the machine is well balanced. It can now be pushed around on its wheels.

  • Page 35: Initial Operation

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 4 TRANSPORT ARRIL 2009 4.3 TRANSPORT WITH CRANES OR LIFTS If the machine is to be transported by a crane or a fork lift, verify that the lifting strap(s) has sufficient capacity to support the weight of the machine. The gross weight is shown in Section 4.1 Unit specifications and also on the serial number...

  • Page 36: Operation

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 5 INITIAL OPERATION APRIL 2009 CONTENTS – SECTION 5 Preparation for initial operation Initial operation Grinding & Polishing...

  • Page 37: Maintenance

    Use hose clamps at the connections. • Make sure the dust bin of the dust collector unit is empty. If problems with the BMG-535 arise during the assembly or start- up, call a qualified person for help. Work on electrical equipment may only be undertaken by qualified personnel .
  • Page 38 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 5 INITIAL OPERATION APRIL 2009 5.2 INITIAL OPERATION Fig. 5.1 Switching on the grinding machine: • Make sure the motor is connected to the plug on the bottom of the panel with the supplied cord.
  • Page 39 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 5 INITIAL OPERATION APRIL 2009 • Using the “FWD/REV” selector switch (5) determine the head rotation direction. • Press the green “START” button (6) to start the machine. • Now let down the grinding disc on the surface gently and begin the grinding work. Move the machine slowly forward or reverse to start grinding or polishing.
  • Page 40 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 5 INITIAL OPERATION APRIL 2009 ________________________________________________________________ Notes ________________________________________________________________ Grinding & Polishing...
  • Page 41 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 6 OPERATION APRIL 2009 CONTENTS – SECTION 6 Operation Switching-off the machine Trouble shooting Safety shutdown Restarting after a fault Proceedings- before and after a stationary period Grinding & Polishing...
  • Page 42 Regular inspection is necessary to prevent unplanned down time of your grinding machine. See Section 7 Maintenance. Pay attention to following aspects during operation of the BMG-535. Before beginning the grinding work, verify that all bolted connections are properly secured and tight.
  • Page 43 APRIL 2009 The process described in Section 5.2 “Initial Operation” shall be followed during the normal start up of the BMG-535 for daily operation. If there are any doubts as to how to start up the machine, read Sections 5.1 and 5.2 of this operating manual.
  • Page 44 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 6 OPERATION APRIL 2009 6.3 TROUBLE SHUTDOWN In case of emergency or operating trouble, such as vibrations or loud noises, switch the machine off immediately by pushing the Emergency Stop (E-Stop) button on the operator control panel (8) .
  • Page 45 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 6 OPERATION APRIL 2009 6.6 PROCEEDINGS – BEFORE AND AFTER STATIONARY PERIOD Before a long stationary period: If the grinding machine will be out of action for a long period of time, protect the machine during storage per the following: •...
  • Page 46 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 6 OPERATION APRIL 2009 ________________________________________________________________ Notes ________________________________________________________________ Grinding & Polishing...
  • Page 48 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 CONTENTS – SECTION 7 Recommendations Maintenance and inspection list Repairing Grinding tool replacement / assembly Upper Part Lower part Pulley maintenance Other maintenance Recommended Spares for Stock 7.10 Influences on the Grinding Pattern...
  • Page 49 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.1 RECOMMENDATIONS Prior to any repair work on the machine and its drives, secure the machine against unintentional activation. Put the machine in its safety off position. Section 2.6 Failures due to inadequate or incorrect maintenance may generate very high repair costs and potentially long periods of down time for the machine.
  • Page 50 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.2 MAINTENANCE AND INSPECTION LIST Operating hours/time period Inspection points, and maintenance instructions 12 hours after repairing Check all accessible screw connections for tightness. Daily and prior to starting work Verify all safety devices are working correctly.
  • Page 51 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.3 REPAIRING As previously mentioned in Section 5.1 Initial operation, we recommend conducting initial repair work on the machine with the support of personnel, by taking this advice, maintenance personnel get the opportunity to be trained by an expert on the machine.
  • Page 52 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.4 GRINDING DISC REPLACEMENT/ASSEMBLY Prior to any repair work being carried out on the machine or its drives, secure the machine against unintentional activation. See Section 2.6. Fig. 7.1 Disassembly: Make sure that the power supply is disconnect from the electrical inlet (1).
  • Page 53 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 Prior to any repair work being carried out on the machine or its drives, secure the machine against unintentional activation. See Section 2.6. Fig. 7.2 Disassembly: 1. Unscrew the bolts (1) on the topside, to enable the protection cover (2) to be removed.
  • Page 54 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.6 LOWER PART Prior to any repair work being carried out on the machine or its drives, secure the machine against unintentional activation. See Section 2.6. Fig. 7.3 Disassembly: 1. Disassemble the diamond tool holders (1) and take off the v-seal (2).
  • Page 55 MODEL BMG-535 GRINDER 7.7 TOOLING DRIVE PULLEY OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 Prior to any repair work being carried out on the machine or its drives, secure the machine against unintentional activation. See Section 2.6. Disassembly: 1. Take off the retaining ring (1).
  • Page 56 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.8 OTHER MAINTENANCE Check the dust seals for wear and replace them at the time when they no longer provide a good seal against dust emissions from the machine. This will ensure that there is no damage caused to the surrounding workspace and consequently saves additional cleanup charges from the job client.
  • Page 57 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 7 MAINTENANCE APRIL 2009 7.9 RECOMMENDED SPARES FOR STOCK It is highly recommended, that having the following spare parts on stock will avoid unplanned downtime and/or long equipment downtime that may result from waiting for spare parts to ship.
  • Page 58 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 8 MAINTENANCE APRIL 2009 CONTENTS – SECTION 8 Directions for electrical engineering Electrical Schematic - 230V / 50 and 60 HZ Control Panel Layout and Device Settings - 230V / 50 and 60 HZ...
  • Page 59 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 8 MAINTENANCE APRIL 2009 8.1 DIRECTIONS FOR ELECTRICAL ENGINEERING Work on electrical equipment or operating materials may only be performed by a skilled electrician or by trained persons under the guidance and supervision of a skilled electrician as well as in accordance with the electrical engineering regulations.
  • Page 60 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 8 MAINTENANCE APRIL 2009 8.2 ELECTRICAL SCHEMATICS - 23OV / 50 AND 60 HZ Grinding & Polishing...
  • Page 61 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 8 MAINTENANCE APRIL 2009 8.3 CONTROL PANEL LAYOUT FOR 23OV / 50 AND 60 HZ Grinding & Polishing...
  • Page 62 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 8 MAINTENANCE APRIL 2009 ITEM NUMBER DESCRIPTION P005037 ENCLOSURE W/ BACKPANEL P004841 DISCONNECT, COMPLETE, BACK PANEL MOUNTED P005033 MANUAL STARTER P004828 CONTACTOR P004781 MOTOR PROTECTOR, AUX CONTACT P004822 CONTACTOR, AUX CONTACT, TOP MOUNT P004893...

  • Page 64: Fault Diagnosis

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 9 FAULT DIAGNOSIS APRIL 2009 CONTENTS – SECTION 9 Troubleshooting - grinding machine Troubleshooting - electrical system Grinding & Polishing...
  • Page 65 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 9 FAULT DIAGNOSIS APRIL 2009 9.1 TROUBLESHOOTING – GRINDING MACHINE Prior to any repair work on the machine or its drives, the machine must be secured against unintentional activation. Put the machine in its Safety off position. See section 2.6.
  • Page 66 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 9 FAULT DIAGNOSIS APRIL 2009 9.2 TROUBLESHOOTING – ELECTRICAL SYSTEM Work on electrical equipment or operating materials may only be performed by a skilled electrician or by trained persons under the guidance and supervision of a skilled electrician as well as in accordance with the electrical engineering regulations.
  • Page 67 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 9 FAULT DIAGNOSIS APRIL 2009 ________________________________________________________________ Notes ________________________________________________________________ Grinding & Polishing...

  • Page 68: Spare Parts

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 CONTENTS – SECTION 10 10.1 Spares Parts - BMG-535 Grinding & Polishing...
  • Page 69 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 10.1 SPARE PARTS – BMG-535 Frame Assembly Grinding & Polishing...

  • Page 70: Socket Head Cap Screw

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Frame Assembly ITEM NO. PART NUMBER DESCRIPTION QTY. PG-10306 MAIN FRAME ASSEMBLY PG-10305 POWERBOX FRAME ASSEMBLY BG005341 STEER PA-10868 HANDLE BUSHING BG11757 BG11750 PIN, KNURLED HANDLE PG-10334 WATER TANK, IMPERIAL...
  • Page 71 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Upper & Lower Assemblies Combined Grinding & Polishing...

  • Page 72: Socket Head Cap Screw

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Upper & Lower Assemblies Combined ITEM NO. PART NUMBER DESCRIPTION QTY. PG-10297 UPPER ASSEMBLY PG-10299 LOWER ASSEMBLY PA-10249 MACHINED COUPLING BG005311 MOTOR SEAT BG005310 FLANGE, MOTOR SEAT PA-10858 MOTOR COUPLING...
  • Page 73 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Upper Assembly Grinding & Polishing...

  • Page 74: Holder

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Upper Assembly PART ITEM NO. DESCRIPTION NUMBER BG005309 MOTOR PLATE ASSEMBLY BG005313 HOLDER BG007834 LOWER PLATE UPPER DRIVE PG-10044 TENSIONER UPPER BELT PG-10300 CENTER PULLEY ASSEMBLY PG-10301 CONTRA PULLEY ASSEMBLY...
  • Page 75 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Lower Assembly Grinding & Polishing...

  • Page 76: Tensioner

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Lower Assembly PART ITEM NO. DESCRIPTION NUMBER BG005314 ADAPTER RING BG005322 HOUSING BG005324 LOWER PLATE BG005326 RING BG005327 COVER BG005350 INSPECTION COVER BG11829 V-RING SEAL BG11849 V-RING SEAL BG11928...
  • Page 77 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Upper Belt Tensioner Grinding & Polishing...

  • Page 78: Axle

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Upper Belt Tensioner ITEM NO. PART NUMBER DESCRIPTION QTY. BG005831 TENSION PLATE BG005830 AXLE BG11911 BEARING CP-10040 RETAINING RING, 20MM, EXT 800790 M10X1.5X30MM SOCKET HEAD CAP SCREW 800791 FLAT WASHER, M10, NARROW 800792 M10 X 1.5 X 30MM FLAT HEAD SOCKET CAP SCREW...
  • Page 79 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Lower Belt Tensioner Grinding & Polishing...

  • Page 80: Bearing

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Lower Belt Tensioner ITEM NO. PART NUMBER DESCRIPTION BG005332 HOLDER, LOWER BELT TENSIONER BG005333 TENSIONER, LOWER BG005337 AXLE, LOWER TENSIONER BG11792 BEARING BG005336 PULLEY BG11793 RETAINING RING, 35MM, INTERNAL...

  • Page 81: Pulley

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Tooling Pulley Assembly Grinding & Polishing...

  • Page 82: Retaining Ring

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Tooling Pulley Assembly ITEM NO. PART NUMBER DESCRIPTION QTY. PA-10921 AXLE, TOOLING DRIVE, IMPERIAL BG11817 BEARING BG005317 BEARING HOUSE BG11801 RETAINING RING, 30MM, EXTERNAL BG11814 RETAINING RING, 62MM, INTERNAL...
  • Page 83 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Center Pulley Grinding & Polishing...

  • Page 84: Retaining Ring

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Center Pulley ITEM NO. PART NUMBER DESCRIPTION QTY. PA-10875 SPROCKET BG005306 PULLEY BG11984 BEARING CP-10045 RETAINING RING, EXTERNAL, 50MM CP-10044 RETAINING RING, INTERNAL, 90MM CP-10053 V-SEAL Grinding & Polishing...
  • Page 85 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Contra pulley Grinding & Polishing...

  • Page 86: Operating Manual April

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Contra Pulley ITEM NO. PART NUMBER DESCRIPTION QTY. BG005301 AXLE, CONTRA PULLEY CP-10047 RETAINING RING, INTERNAL, 52MM BG11881 BEARING CP-10051 RETAINING RING, EXTERNAL, 25MM PA-10928 PULLEY CP-10280 BUSHING, TAPER LOCK...
  • Page 87 MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Driving Pulley Grinding & Polishing...

  • Page 88: Bearing

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Driving pulley ITEM NO. PART NUMBER DESCRIPTION QTY. PA-10922 AXLE, DRIVING PULLEY, IMPERIAL BG11801 RET RING, 30MM, EXTERNAL BG11800 BEARING BG11814 RET RING, 62MM, INTERNAL BG005321 BEARING HOUSE BG005315...

  • Page 89: April

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Diamond Plate Holder Grinding & Polishing...

  • Page 90: Flat Head Socket Cap Screw

    MODEL BMG-535 GRINDER OPERATING MANUAL SECTION 10 SPARE PARTS APRIL 2009 Diamond Plate Holder ITEM NO. PART NUMBER DESCRIPTION QTY. BG11809 TOOL HOLDER BG11811 CENTERING STAR 800811 M6 X 1.0 X 12MM FLAT HEAD SOCKET CAP SCREW BG11808 MAGNET HOLDER...
