  • Page 1 Operating instructions Adora N integrated, design-integrated, fully integrated Dishwasher...
  • Page 2 GS60NZic 41052 (EURO 60) GS60NZdi 41063 GS60NZdic 41063 GS60NZVi 41075 GS60NZVic 41075 GS60NZGi 41076 GS60NZGic 41076 GS60NZGVi 41077 GS60NZGVic 41077 GS60NZGdi 41078 GS60NZGdic 41078 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2019...

  • Page 3: Table Of Contents

    Contents Safety precautions  4 Trouble-shooting  27 Error messages.............   27 Appliance description  8 Other possible problems........  29 Construction ............ 8 Unsatisfactory washing results......  29 Operating and display elements...... 9 In the event of a power failure ......  30 Programme overview  10 Accessories and spare parts...

  • Page 4: Safety Precautions

    Safety precautions ▪ If the mains cable of this ap- Read the operating instructions be- fore using the appliance for the first pliance is damaged, it must time. be replaced by the manufac- General safety precautions turer or its Customer Services or a similarly qualified person ▪...
  • Page 5 1 Safety precautions ▪ The appliance is only suitable Instructions for use for washing household dishes Switching off the power to the appli- and cutlery with water and ance disables the built-in overflow protection system. standard dishwasher deter- Dishwasher detergents are strongly gent.
  • Page 6 1 Safety precautions Transport and installation Notes on using the operating instructions Front Graphical operating instructions can be downloaded on the internet from www.vzug.ch. Symbols used Denotes important safety precau- tions. Tilt max. 90° to the right! Failure to observe said precautions can Transport the appliance in an upright posi- result in injury or in damage to the appli- tion only! Transporting it in any other posi-...
  • Page 7 Using for the first time The appliance must be installed and connected to the electricity supply by a quali- fied fitter/electrician in accordance with the separate installation instructions. Before operating the newly installed appliance for the first time, the following steps should be taken: Before using for the first time ▸...

  • Page 8: Appliance Description

    3 Appliance description Appliance description Construction Baskets Spray arms Cutlery basket Rinse agent reservoir Operating and display elements * Quick operating instructions Detergent dispenser Salt reservoir Filter system Integrated appliances (operating elements are located on the outside of the appliance door): Door handle Operating and display elements Fully integrated and design integrated appliances...

  • Page 9: Operating And Display Elements

    3 Appliance description Operating and display elements Integrated appliances: Fully integrated and design integrated appliances: Buttons Programme sym- Additional function bols symbols /Indicator symbols Programme selec- Automatic Energy saving tion Eco programme Quick wash/ Rinse agent Glass care refill indicator Delayed start Intensive «All in 1»...

  • Page 10: Programme Overview

    4 Programme overview Programme overview Programme Programme time and energy consumption can be reduced by selecting the additional function. Eco programme: The most efficient programme in terms of water and en- ergy consumption for normally dirty dishes (declaration programme). Automatic: Optimum cleaning with minimal water and energy consumption. Not for burnt-on or dried leftovers.

  • Page 11: Operation

    5 Operation Operation Preparing the appliance ▸ Remove any coarse or hard pieces of food or foreign objects (such as toothpicks) left on the dishes. ▸ Load the baskets. After loading, check that the spray arms can turn freely. Dish washing tips General notes ▪...

  • Page 12: Loading Tips For The Upper Basket

    5 Operation Loading tips for the upper basket ▸ Arrange smaller items such as saucers, glasses, cups and dishes. ▸ If using the fold-down racks 1, stagger the items. ▸ Rest glasses on the fold-down glass holder 2. Glass holder Particularly suitable for tall glasses.
  • Page 13 5 Operation Easy prongs For placing drinking glasses, baby bottles, vases and carafes anywhere in the basket. ▸ Put easy prong 1 over basket prongs. ▸ Use 2 easy prongs for wider vessels. Racks The racks 1 can also be used as glass holders.

  • Page 14: Loading Tips For The Lower Basket

    5 Operation Adjusting the upper basket The height of the upper basket can be adjusted by around 2–4 cm (depending on model). It can be inclined in various ways. ▸ To raise: Hold the upper basket at the sides by the grips 1 and raise it into the position required.
  • Page 15 5 Operation Easy prongs For placing drinking glasses, baby bottles, vases and carafes anywhere in the basket. ▸ Put easy prong 1 over basket prongs. ▸ Use 2 easy prongs for wider vessels. Cleaning baking and steaming trays The upper basket has to be removed for larger trays.
  • Page 16 5 Operation Cutlery basket To avoid injury, place knives and cutlery with sharp edges or points into the cut- lery basket in such a way that they do not stick out (points facing downwards). Do not drop or insert knives, forks or other sharp items in the opening of the door lock.

  • Page 17: Detergent

    5 Operation Detergent Choice of detergent Never use washing-up liquid. Heavy foaming can cause malfunctions. Strictly ob- serve the dosage instructions printed on the packaging and contact the detergent manufacturer if you have any questions. Using too high or low a dosage can cause damage to the appliance.
  • Page 18 5 Operation Adding the detergent No detergent must enter the opening of the door lock. This can cause the door lock to malfunction. Powder ▸ Open the detergent dispenser by push- ing the release catch in the direction of the arrow. ▸...

  • Page 19: Selecting A Programme

    5 Operation Selecting a programme ▸ Press the button repeatedly until the required pro- gramme symbol flashes. ▸ Select any additional function(s), if required. ▸ Close the appliance door. Integrated appliances: The programme starts in 15 seconds. Fully integrated and design integrated appliances: The programme starts immediately.

  • Page 20: Delayed Start

    5 Operation Delayed start The delayed start allows you to wash during off-peak hours (e.g. at off-peak electricity rates). It can be set within 15 seconds of selecting a programme. A delayed start of between 1 and 9 hours can be set. Setting ▸...

  • Page 21: Aborting A Programme Before Time

    5 Operation Aborting a programme before time The dishes and water may be hot. Scalding hazard! ▸ Integrated appliances: Press the button first. The programme is interrupted for 5 seconds. ▸ Open the appliance door carefully. The programme symbol flashes. ▸...

  • Page 22: User Settings

    6 User settings User settings Overview of user settings Hold the button depressed for 5 seconds. Off Acoustic signal * Low** High All in 1 Off** Water hardness Off Level 1 Level 5** Level 9 Off Rinse agent dosage Level 1 Level 4** Level 9 Drying Plus...

  • Page 23: Acoustic Signal

    6 User settings Acoustic signal Only present on fully and design-integrated appliances. Display on operating panel: The acoustic signal can be turned off Factory setting: or on. In the event of a malfunction, an Possible settings: acoustic signal is emitted even in the off mode.

  • Page 24: Dryplus

    6 User settings DryPlus Display on operating panel: If DryPlus is turned on, the drying tem- Factory setting: perature is increased. This extends the Possible settings: drying time. ▪ ▪ RinsePlus If RinsePlus is turned on, the amount Display on operating panel: of water used with each programme is Factory setting: Possible settings:...

  • Page 25: Care And Maintenance

    7 Care and maintenance Care and maintenance Cleaning the interior and exterior Cleaning the interior Using the correct dosage of detergent will automatically clean the interior of the appli- ance. The appliance should be additionally cleaned twice a year with dishwasher cleaner.

  • Page 26: Cleaning The Filter System

    7 Care and maintenance Cleaning the filter system Only use soft materials for cleaning beneath the filter system. Never use metal ob- jects. An incorrectly assembled filter system can cause the appliance to malfunction. ▸ Open the appliance door and pull out the lower basket. ▸...

  • Page 27: Filling With Rinse Agent

    8 Trouble-shooting Filling with rinse agent Never fill the rinse agent reservoir with detergent! Wipe away any spilt rinse agent. Risk of foaming. Follow the manufacturer’s safety instructions and warnings. Rinse agent prevents water spotting after final rinsing (rinsing with rinse agent). When the supply of rinse agent is exhausted, the refill indicator flashes.
  • Page 28 8 Trouble-shooting Display Possible cause Solution alternate. ▪ Water tap is turned off. ▸ Fix problem or wait until water sup- ▪ Water inlet filter is ply is restored. blocked. ▸ Cancel the error message by press- ▪ Interruption in the water ing the button.

  • Page 29: Other Possible Problems

    8 Trouble-shooting Other possible problems Problem Possible cause Solution The appliance will ▪ There could be several reas- ▸ Close the appliance door. not start. ons for this. ▸ Insert plug into mains socket. ▸ Check the fuse or circuit breaker.

  • Page 30: In The Event Of A Power Failure

    8 Trouble-shooting Problem Solution There are streaks ▸ Reduce the rinse agent dosage setting. or milky spots on ▸ If not using detergent, set to in the user settings. the dishes. The dishes are ▸ Refill the rinse agent. wet and dull or ▸...

  • Page 31: Accessories And Spare Parts

    9 Accessories and spare parts Accessories and spare parts Please give product family of the appliance and exact designation of the accessory or spare part when ordering parts. Accessories «Small» cutlery basket «Large» cutlery basket Cup support Vario cutlery basket insert Lower basket for glasses Racks...

  • Page 32: Technical Data

    10 Technical data Set of 4 easy prongs Spare parts Filter system Technical data Dimensions SMS 55 SMS 55 EURO 60 EURO 60 Extra height Extra height Appliance height 762 mm 827 mm 762 mm 827 mm (incl. slide plate 3 mm) Appliance height – 848–893 mm 783–828 mm 848–893 mm (incl.

  • Page 33: Consumption Data

    10 Technical data 10.1 Consumption data Pre-rinsing Drying Cleaning Duration Intermediate rinsing Water Rinsing with rinse agent Energy The stated programme times and consumption values serve as a guide. The values can also vary according to the selection of additional functions, the load, the degree of soil- ing of the load, the type and amount of cleaner, the water inlet temperature, the electrical connection and specific programme sequences (e.g.
  • Page 34 11 Disposal Disposal 11.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 11.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
  • Page 35 SN: ______________________________ Appliance: ________________________ Your repair order You can find the telephone number of the nearest V-ZUG service centre to you under www.vzug.com →Service →Service hotline. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 36 ▸ Close the appliance door. The programme starts immediately, or after 15 seconds (depending on model). ▸ When a 3× acoustic signal is emitted or the display goes out (depending on model), open the appliance door and unload the dishes. 1027805-R04 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug info@vzug.com, www.vzug.com...
