LEGRAND Kenall TEKDEK TD17 Series Installation Instructions Manual

TEKDEK LED
™
Luminaire for Parking Garages
TD17 SERIES
SAFETY RECOMMENDATION
SAFETY RECOMMENDATION
A 1/16" diameter aircraft cable with end-loop (not included) is recommended for
A 1/16" diameter cable with end-loop (not included) is recommended
attaching the xture structural to the upper structural.
for attaching the fi xture structural to the upper structural
1/16" DIA. AIRCRAFT CABLE
(SUPPLIED BY OTHERS)
www.kenall.com | P: 800-4-Kenall | F: 262-891-9701 | 10200 55th Street Kenosha, Wisconsin 53144, USA
This product complies with the Buy American Act: manufactured in the United State swith more than 50% of the component cost of US origin It may be covered by patents
found at www.kenall.com/patents. Content of speci cation sheets is subject to change; please consult www.kenall.com for current product details. ©2019 Kenall Mfg. Co.
INSTALLATION INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should
always be followed, including the following:
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND
OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
CE PRODUIT DOIT ÊTRE INSTALLÉ EN CONFORMITÉ AVEC LE CODE DE
L'INSTALLATION PAR UNE PERSONNE QUI connaît BIEN LA CONSTRUCTION ET
LE FONCTIONNEMENT DU PRODUIT ET LES RISQUES ENCOURUS.
DISCONNECT POWER TO ALL CIRCUITS BEFORE WIRING FIXTURE. INSTALL IN
ACCORDANCE WITH ALL NATIONAL, STATE, AND LOCAL CODES. DO NOT
CONNECT TO AN UNGROUNDED SUPPLY. READ ALL FIXTURE MARKINGS AND
LABELS TO ENSURE CORRECT INSTALLATION OF FIXTURE. SUPPLEMENTAL
INSTRUCTIONS MAY BE LOCATED ON THE FIXTURE, IN ADDITION TO THIS
INSTRUCTION SHEET, REGARDING ORIENTATION, OR MOUNTING RESTRICTIONS.
SAVE THESE INSTRUCTIONS
AIRCRAFT CABLE ATTACH
TO UPPER STRUCTURAL
SCREW (SUPPLIED BY OTHERS)
1
F-4260_091118
