Summary of Contents for Daikin RZQ71KAVLT
- Page 1 Si281314E REMOVAL PROCEDURE S E R V I C E M A N U A L 3 HP Class Outdoor Unit Inverter Pair Type...
-
Page 2: Outdoor Unit
Service Manual Removal Procedure Outdoor Unit Applicable Models Heat Pump RZQ71KAVLT... -
Page 3: Table Of Contents
Si281314E Table of Contents 1. Procedure to Remove Outside Panels and Related Parts ......2 2. Procedure to Remove Propeller Fan and Fan Motor ......3 3. Procedure to Remove Switch Box ............4 4. Procedure to Remove PCB Assy (1)............5 5. Procedure to Remove Assy (2) ...............6 6. -
Page 4: Procedure To Remove Outside Panels And Related Parts
Procedure to Remove Outside Panels and Related Parts Si281314E 1. Procedure to Remove Outside Panels and Related Parts Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the front panel 2 (the front panel of the... -
Page 5: Procedure To Remove Propeller Fan And Fan Motor
Si281314E Procedure to Remove Propeller Fan and Fan Motor 2. Procedure to Remove Propeller Fan and Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the front panel 2, following the procedure... -
Page 6: Procedure To Remove Switch Box
Procedure to Remove Switch Box Si281314E 3. Procedure to Remove Switch Box Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Remove the front panel, Fan motor (X106A) the suction grille, the top panel, the side panel, and the piping cover, following... -
Page 7: Procedure To Remove Pcb Assy (1)
Si281314E Procedure to Remove PCB Assy (1) 4. Procedure to Remove PCB Assy (1) Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Remove the top panel, the front panel 2, the side PCB for the display panel, and the piping... -
Page 8: Procedure To Remove Assy (2)
Procedure to Remove Assy (2) Si281314E 5. Procedure to Remove Assy (2) Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step 2. Remove the mounting Mounting plate for the plate for the electric Fixing screws electric component... -
Page 9: Procedure To Remove Assy (3)
Si281314E Procedure to Remove Assy (3) 6. Procedure to Remove Assy (3) Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step 3. Remove the assembly of Fixing screw the PCB (AIP) Remove the connectors... -
Page 10: Procedure To Remove Low Pressure Thermistor, Electronic Expansion Valve, And Others
Procedure to Remove Low Pressure Thermistor, Electronic Expansion Valve, and Others Si281314E 7. Procedure to Remove Low Pressure Thermistor, Electronic Expansion Valve, and Others Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. -
Page 11: Procedure To Remove Thermistor
Si281314E Procedure to Remove Thermistor 8. Procedure to Remove Thermistor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Remove the front panel 2, the right side panel, and the piping cover, following Thermistor the procedure indicated at... -
Page 12: Procedure To Remove Four Way Valve
Procedure to Remove Four Way Valve Si281314E 9. Procedure to Remove Four Way Valve Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Collect the refrigerant. Be sure to confirm that the Remove the outside Coil for the four... -
Page 13: Procedure To Remove Compressor
Si281314E Procedure to Remove Compressor 10.Procedure to Remove Compressor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Collect the refrigerant. Be sure to confirm that the Remove the outside Fixing plate for the stop valve refrigerant is completely... -
Page 14: Revision History
Revision History Month / Year Version Revised contents 06 / 2013 Si281314E First edition... - Page 15 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
