Aeotec WallSwipe User Manual

For nano

Download this manual

WallSwipe for Nano user guide.

Modified on: Thu, 14 Mar, 2019 at 4:19 PM

Aeotec WallSwipe.

Aeotec WallSwipe has been crafted to connect directly to any Aeotec Nano (Switch, Dimmer, Dual Nano Switch) products

as an add-on external switch or dimmer

. It is powered by Aeotec's technology. You can find

(http://aeotec.com/z-wave-plus)

out more about WallSwipe

by following that link.

(https://aeotec.com/z-wave-wall-switch)

The technical specification of WallSwipe

(https://aeotec.freshdesk.com/solution/articles/6000178990-wallswipe-technical-

can be viewed at that link.

specification-)

Familiarize yourself with your WallSwipe.

Page 1 Modified on: Thu, 14 Mar, 2019 at 4:19 PM Aeotec WallSwipe. Aeotec WallSwipe has been crafted to connect directly to any Aeotec Nano (Switch, Dimmer, Dual Nano Switch) products as an add-on external switch or dimmer . It is powered by Aeotec’s technology. You can find (http://aeotec.com/z-wave-plus)
Page 2: Important Safety Information
Keep product away from open flames and extreme heat. Avoid direct sun light or heat exposure. WallSwipe is intended for indoor use in dry locations only. Do not use in damp, moist, and / or wet locations. Requirements.
Page 3: Quick Start
These button functions will work the same across all Nano versions (Dimmer, Switch, Dual Nano Switch). General button functions. There are various functions you can do with Wallswipe, this will allow you to unpair, pair, or even factory reset your Nano without having to remove Nano from your wall.
Page 4 In order to perform a continuous tap, the below button tap must be done within a second: 1. Tap the top 50% of WallSwipe first 2. Then tap the bottom 50% of WallSwipe second Control guide for Nano. Nano Dimmer.
Page 5 Tap and swipe up Sets brightness higher by 10% Tap and swipe down Sets brightness lower by 10% (Gesture) Swipe up Turns Nano Dimmer on to the last dim level. (Gesture) Swipe down Turns Nano Dimmer off. Nano Switch. A singular LED will change between red and blue to determine the state of Nano Switch. •...
