- Page 1 Si211309E REMOVAL PROCEDURE S E R V I C E M A N U A L 3 HP Class Indoor Unit Non-Inverter Pair Type...
-
Page 2: Indoor Unit
Service Manual Removal Procedure Indoor Unit Applicable Models Heat Pump FAY71F(A)VE... -
Page 3: Table Of Contents
Si211309E Table of Contents 1. Procedure to Remove Air Filter...............2 2. Procedure to Remove Slide Panel, Operation Display Cover, and Front Grille ..................3 3. Procedure to Remove Electrical Parts Box ..........4 4. Procedure to Remove PCB..............5 5. Procedure to Remove Swing Louvre Unit ..........6 6. -
Page 4: Procedure To Remove Air Filter
Procedure to Remove Air Filter Si211309E 1. Procedure to Remove Air Filter Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step Hold the air filter tabs with your hands and pull out. -
Page 5: Procedure To Remove Slide Panel, Operation Display Cover, And Front Grille
Si211309E Procedure to Remove Slide Panel, Operation Display Cover, and Front Grille 2. Procedure to Remove Slide Panel, Operation Display Cover, and Front Grille Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. -
Page 6: Procedure To Remove Electrical Parts Box
Procedure to Remove Electrical Parts Box Si211309E 3. Procedure to Remove Electrical Parts Box Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗Remove the left and right The left and right side panels side panels, operation display have to be taken off in order to... -
Page 7: Procedure To Remove Pcb
Si211309E Procedure to Remove PCB 4. Procedure to Remove PCB Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗Remove the outer panels according to the procedure for removing the electrical parts box. -
Page 8: Procedure To Remove Swing Louvre Unit
Procedure to Remove Swing Louvre Unit Si211309E 5. Procedure to Remove Swing Louvre Unit Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗Remove the electrical parts box according to its removal procedure. -
Page 9: Procedure To Remove Fan Motor
Si211309E Procedure to Remove Fan Motor 6. Procedure to Remove Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗Remove side panels and Use 2.5 mm hexagon nut driver. other external casing, and electrical parts box according to their removal procedures. -
Page 10: Procedure To Remove Drain Pan
Procedure to Remove Drain Pan Si211309E 7. Procedure to Remove Drain Pan Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗If removing the drain pan: The bottom panel is fastened to Carry out pump down, the unit installation plate by 3... - Page 11 Si211309E Procedure to Remove Drain Pan Step Procedure Points Remove the air Center of air discharge section discharge unit. also screw fastened. (7 screws) Remove the drain pan. 1 Pull left side toward yourself. 2 Move the drain hose to the right until it comes off.
-
Page 12: Procedure To Remove Heat Exchanger
Procedure to Remove Heat Exchanger Si211309E 8. Procedure to Remove Heat Exchanger Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗Before dismounting a heat exchanger, make sure to Top plate proceed pump down refrigerant to outdoor unit and... -
Page 13: Procedure To Remove Fan Rotor
Si211309E Procedure to Remove Fan Rotor 9. Procedure to Remove Fan Rotor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Step ∗Remove the heat exchanger You can also remove the according to its removal auxiliary electric heater without procedure. - Page 14 Revision History Month / Year Version Revised contents 06 / 2013 Si211309E First edition...
- Page 15 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
