Page 1: Technical Data
technical data FAQ-BVV1B Wall Mounted Unit Split Sky Air... -
Page 2: Table Of Contents
• Indoor Units • R-410A • FAQ-BVV1B TABLE OF CONTENTS FAQ-BVV1B Features ............. 2 Specifications . -
Page 3: Features
R - 4 • Lightweight and compact • Daikin remote controls give you easy control at your fingertips. • Ideal for shops, restaurants or offices requiring maximum floor space • The wired remote control provides you with a schedule timer, for furniture, decorations and fittings enabling to program the air conditioning daily or weekly. -
Page 4: Specifications
• Indoor Units • R-410A • FAQ-BVV1B Specifications 2-1 FOR INDOOR UNITS ONLY FAQ71BVV1B FAQ100BVV1B Nominal Input Cooling 0.068 0.101 Heating 0.068 0.101 2-2 TECHNICAL SPECIFICATIONS FAQ71BVV1B FAQ100BVV1B Casing Colour White Material Resin Dimensions Packing Height Width 1147 1740 Depth... -
Page 5: Electrical Specifications
• Indoor Units • R-410A • FAQ-BVV1B Specifications 2-2 TECHNICAL SPECIFICATIONS FAQ71BVV1B FAQ100BVV1B Standard Item Installation and operation manual Accessories Quantity Item Paper pattern for installation Insulation tape Installation panel Screws Insulation for fitting Notes The sound pressure level is measured via a microphone at 1m distance of the unit. -
Page 6: Safety Device Settings
• Indoor Units • R-410A • FAQ-BVV1B Safety device settings FAQ71-100B Model Safety devices FAQ71B FAQ100B − − Fuse − − Fan motor thermal fuse (°C) FAQ∼B OFF: 130±5 − Fan motor thermal protector (°C) ON: 83±20 DU423-9101L • Split Sky Air • Indoor Units... -
Page 7: Options
• Indoor Units • R-410A • FAQ-BVV1B Options Optional accessories FAQ71B FAQ100B Remote control Wired BRC1D528 Infrared type Heat pump BRC7EA618 BRC7CA510W Cooling only BRC7EA619 BRC7CA511W Wiring adapter for electrical appendices (2)* *KRP4AA51 Installation box for adapter PCB KRP4AA93 Central remote control DCS302CA51 Electrical box with earth terminal (3 blocks) KJB311AA... -
Page 8: Control Systems
• Indoor Units • R-410A • FAQ-BVV1B Control systems BRC1D527 5 x 10 (Round end slit) 6.5 x 9 (Round end slit) HoleJ5 5 x 7 (Round end slit) Cover closed 3TW23651-2 Cover open • Split Sky Air • Indoor Units... -
Page 9: Dimensional Drawing & Centre Of Gravity
• Indoor Units • R-410A • FAQ-BVV1B Dimensional drawing & centre of gravity 6 - 1 Dimensional drawing unit (mm) FAQ71B Piping direction approx. 400 Dimensions for full open front panel Name plate 120 or less Piping direction Piping direction Note) 2 2500 or more For installation in high... -
Page 10: Piping Diagram
• Indoor Units • R-410A • FAQ-BVV1B Piping diagram FAQ71-100B Refrigerant pipe connection port diameters Indoor heat exchanger Model FAQ71, 100B J 9.5 J 15.9 Field piping J9. 5C1220T-0 To outdoor unit Field piping J15.9C1220T-0 Indoor unit Check valve Flare connection Screw connection Flange connection Pinched pipe... -
Page 11: Wiring Diagram
• Indoor Units • R-410A • FAQ-BVV1B Wiring diagram 8 - 1 Wiring diagram Receiver / display unit (attached to infrared remote control) FAQ71B Notes To outdoor unit 1. D : Terminal, F : Connector, : Field wiring 2. In case using central remote control, connect it to the unit in accordance with the attached instruction Note) 4 manual. -
Page 12: External Connection Diagram
• Indoor Units • R-410A • FAQ-BVV1B Wiring diagram 8 - 2 External connection diagram V1, Model V3, Model Power supply Power supply 1∼50Hz 1∼50Hz 220V-240V 230V Main switch Main switch Fuse Fuse NOTES Line voltage wiring Control circuit wiring All wiring, components and materials to be produced on the site must comply with the applicable local and national codes. -
Page 13: Sound Data
• Indoor Units • R-410A • FAQ-BVV1B Sound data 9 - 1 Sound level data Sound pressure level 230V Sound power level Model 50Hz Measuring location Cooling Heating Cooling Heating FAQ71B 43/37 43/37 45/41 45/41 FAQ100B 59/53 59/53 61/57 61/57 Microphone •... -
Page 14: Sound Pressure Spectrum
• Indoor Units • R-410A • FAQ-BVV1B Sound data 9 - 2 Sound pressure spectrum FAQ71B (Cooling/Heating) FAQ100B (Cooling) H (230V) L (230V) H (230V) L (230V) approximate threshold hearing approximate for continuous threshold hearing noise for continuous noise 4D038512C Octave band center frequency (Hz) 4D027787B Octave band center frequency (Hz) -
Page 15: Air Flow Pattern
• Indoor Units • R-410A • FAQ-BVV1B Air flow pattern FAQ71B Cooling - air velocity distribution Air flow direction: 10° (downward) FAQ71B Cooling - air temperature distribution Air flow direction: 10° (downward) 4D039573B • Split Sky Air • Indoor Units... -
Page 16: 10 Air Flow Pattern
• Indoor Units • R-410A • FAQ-BVV1B Air flow pattern FAQ100B Cooling - air velocity distribution Air flow direction: 10° (downward) FAQ100B Cooling - air temperature distribution Air flow direction: 10° (downward) 4D028547B • Split Sky Air • Indoor Units... -
Page 17: 10 Air Flow Pattern
• Indoor Units • R-410A • FAQ-BVV1B Air flow pattern FAQ71B Heating - air velocity distribution Air flow direction: 65°C (downward) FAQ71B Heating - air temperature distribution Air flow direction: 65°C (downward) 4D039574B • Split Sky Air • Indoor Units... -
Page 18: 10 Air Flow Pattern
• Indoor Units • R-410A • FAQ-BVV1B Air flow pattern FAQ100B Heating - air velocity distribution Air flow direction: 65°C (downward) FAQ100B Heating - air temperature distribution Air flow direction: 65°C (downward) 4D028548B • Split Sky Air • Indoor Units... -
Page 19: Installation
