  • Page 1 ® RF Directional Thruline Precision Power Sensors 4028 Series Operation Manual ©Copyright 2017 by Bird Technologies, Inc. Instruction Book Part Number 920-4028S Rev. H...
  • Page 2: Specifications

    Specifications CAUTION Changing the sensor’s connectors will invalidate calibration data, and may reduce the maximum power rating of the unit. Frequency Range 4028A250K 250 – 400 kHz 4028A400K 400 – 550 kHz 4028A2M 1.5 – 2.5 MHz 4028A3M 2.5 – 3.5 MHz 4028A4M 3.5 –...
  • Page 3 Impedance, Nominal 50 ohms Max. Allowable Terminating VSWR 2.00:1 Calibration Frequencies, †† Typical (MHz) 4028A250K 0.25, 0.40 4028A400K 0.40 4028A2M 1.8, 2.0, 2.17 4028A3M 2.5, 3.2, 3.5 4028A4M 3.5, 4.0 4028A10M 10.0, 13.56, 15.0 4028A25M 25.76, 27.12, 28.48 4028A120M 110.0, 120.0, 130.0 4028B2M 1.8, 2.0, 2.2 4028B3M...
  • Page 4 Weight, Nominal 4028B10M, 4028C10M 5 lb. 2 oz. (2.33 kg) 4028A250K, 400K 1 lb. 13 oz. (0.8 kg) All other models 3 lb. 9 oz. (1.6 kg) †. For rated accuracy, no more than 1% AM; Harmonics –50 dBc or less. Derate accuracy by 2% for temperatures outside 25 ±...
  • Page 5 Special Lifetime Warranty Series 4028 Power Sensor Head In addition to its standard warranty, the Bird Electronic Corporation warrants its Series 4028 Thruline® Power Sensor Heads for lifetime to original purchaser. This extended warranty is against burnout. For the warranty to apply, the...
