BIRD 5009 Operation Manual

Directional power sensors

Advertisement

Directional Power Sensors
Operation Manual
Model 5009, 5010B, and 5014
©Copyright 2017
by Bird Technologies Inc.
Instruction Book Part Number 920-5010S Rev. E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5009 and is the answer not in the manual?

Questions and answers

Summary of Contents for BIRD 5009

  • Page 1 Directional Power Sensors Operation Manual Model 5009, 5010B, and 5014 ©Copyright 2017 by Bird Technologies Inc. Instruction Book Part Number 920-5010S Rev. E...
  • Page 2: Safety Precautions

    Bird Directional Power Sensors Safety Precautions The following are general safety precautions that are not necessarily related to  any specific part or procedure, and do not necessarily appear elsewhere in this  publication. These precautions must be thoroughly understood and apply to all  phases of operation and maintenance. WARNING Keep Away From Live Circuits Operating Personnel must at all times observe general safety precautions. Do  not replace components or make adjustments to the inside of the test  equipment with the high voltage supply turned on. To avoid casualties, always  remove power. WARNING Shock Hazard Do not attempt to remove the RF transmission line while RF power is present. WARNING Do Not Service Or Adjust Alone Under no circumstances should any person reach into an enclosure for the  purpose of service or adjustment of equipment except in the presence of  someone who is capable of rendering aid. WARNING Safety Earth Ground An uninterruptible earth safety ground must be supplied from the main  power source to test instruments. Grounding one conductor of a two  conductor power cable is not sufficient protection. Serious injury or death can  occur if this grounding is not properly supplied. WARNING Resuscitation Personnel working with or near high voltages should be familiar with modern  methods of resuscitation. WARNING Remove Power Observe general safety precautions. Do not open the instrument with the  power on.
  • Page 3: Safety Symbols

    Safety Precautions Safety Symbols WARNING Warning notes call attention to a procedure, which if not correctly performed,  could result in personal injury. CAUTION Caution notes call attention to a procedure, which if not correctly performed,  could result in damage to the instrument. Note: Calls attention to supplemental information. Warning Statements The following safety warnings appear in the text where there is danger to  operating and maintenance personnel, and are repeated here for emphasis. WARNING Leaking RF energy is a potential health hazard. DO NOT connect or disconnect  equipment from the transmission line while RF power is being applied. Severe  burns, electrical shock, or death can occur. On page 2. WARNING Never attempt to connect or disconnect RF equipment from the transmission  line while RF power is being applied. Leaking RF energy is a potential health hazard. On page 5. WARNING RF voltage may be present in RF element socket. Keep element in socket  during operation. On page 5.
  • Page 4: Caution Statements

    Bird Directional Power Sensors Caution Statements The following equipment cautions appear in the text and are repeated here for  emphasis. CAUTION If the element cannot be fully inserted into the socket, do not force it. This  may damage the element. On page 2. Safety Statements USAGE ANY USE OF THIS INSTRUMENT IN A MANNER NOT SPECIFIED BY THE MANUFACTURER MAY IMPAIR THE INSTRUMENT’S SAFETY PROTECTION. EL USO DE ESTE INSTRUMENTO DE MANERA NO ESPECIFICADA POR EL FABRICANTE, PUEDE ANULAR LA PROTECCIÓN DE...
  • Page 5 Safety Precautions SERVICE SERVICING INSTRUCTIONS ARE FOR USE BY SERVICE - TRAINED PERSONNEL ONLY. TO AVOID DANGEROUS ELECTRIC SHOCK, DO NOT PERFORM ANY SERVICING UNLESS QUALIFIED TO DO SO. SERVICIO LAS INSTRUCCIONES DE SERVICIO SON PARA USO EXCLUSIVO DEL PERSONAL DE SERVICIO CAPACITADO. PARA EVITAR EL PELIGRO DE DESCARGAS ELÉCTRICAS, NO REALICE NINGÚN SERVICIO A MENOS QUE ESTÉ...
  • Page 6 Bird Directional Power Sensors RF VOLTAGE MAY BE PRESENT IN RF ELEMENT SOCKET - KEEP ELEMENT IN SOCKET DURING OPERATION. DE LA TENSION H.F. PEAT ÊTRE PRÉSENTE DANS LA PRISE DE L'ÉLÉMENT H.F. - CONSERVER L'ÉLÉMENT DANS LA PRISE LORS DE L'EMPLOI. HF-SPANNUNG KANN IN DER HF-ELEMENT-BUCHSE ANSTEHEN - ELEMENT WÄHREND DES BETRIEBS EINGESTÖPSELT LASSEN.
  • Page 7: About This Manual

    About This Manual About This Manual This manual covers the operating and maintenance instructions for the  following models: 5009 5010 B 5014 5010 T Changes to this Manual We have made every effort to ensure this manual is accurate. If you discover any  errors, or if you have suggestions for improving this manual, please send your  comments to our Solon, Ohio factory. This manual may be periodically updated.  When inquiring about updates to this manual refer to the part number and  revision on the title page. Chapter Layout Introduction — Describes the features of the Directional Power Sensor and  Element Types. Installation — Describes how to connection and install the Directional Power  Sensor into the system that is being monitored. Specifications — Describes the basic information, settings, and ranges of the  Digital Power Sensor.
  • Page 8: Table Of Contents

    Chapter 3 Specifications........8 5009 Specifications  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  8 5010B, 5010T Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...
  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Description The DPS Power Sensors are intended for use in coaxial transmission lines of 50  ohm nominal impedance. The sensors utilize elements in order to make power  measurements. Each element has an arrow on it that represents the direction in  which it measures power. The elements ignore power in the opposite direction  with a directivity of at least 25 dB. The DPS series can make power  measurements using either 43 type or APM/DPM elements, and the readings  available vary, based on which elements are being used. Since the DPS uses two elements, it can measure the quality of the system by  comparing the forward and the reflected power. This is usually presented in the  form of VSWR (voltage standing wave ratio) or Return Loss. Element Types 43 Type Elements The 43 type elements are normally used to measure peak power. These  elements can measure the peak power of a system with an accuracy of +/‐8% of  full scale as long as the signal meets the following requirements:  At least 15 pulses per second (PPS  Minimum pulse width of 15 µs (800 ns if frequency is greater than 100  MHz)  Minimum Duty Cycle of 0.01%  In addition, 43 type elements can be used to measure average power in signals  with a peak‐to‐average ratio close to 1, like a CW or FM signals. In these cases,  the average power is measured with an accuracy of +/‐ 5% of full scale. APM/DPM Elements The APM/DPM elements are used to measure true average power. True average  power means the sensor provides equivalent heating power of the signal,  regardless of modulation or number of carriers. These elements can measure  average power with an accuracy of +/‐5% of reading from full scale down to  2.5% of full scale.  Note: The equivalent heating power is dependent on the duty  cycle of a signal. If a system puts out 50 watts with a 50% duty ...
  • Page 10: Element Orientation

    Bird Directional Power Sensors Element Orientation WARNING Leaking RF energy is a potential health hazard. DO NOT connect or disconnect  equipment from the transmission line while RF power is being applied. Severe  burns, electrical shock, or death can occur. The forward element and the reflected element must be of the same series  (APM or 43). The power rating of the forward element must be 10x the power  rating of the reverse element. Insert the forward element into the forward socket with its arrow pointing in the  direction of forward power. Insert the reflected element into the reflected  socket with its arrow pointing in the direction of reverse power. Element Contact Alignment Continuous insertion or rotation of the element might cause a slight change in  the position of the contact spring in the element socket. If the contact spring  changes position, erratic power readings may be experienced. The position of the contact spring may be adjusted with a small screwdriver to  reestablish contact. CAUTION If the element cannot be fully inserted into the socket, do not force it. This  may damage the element. Perform the following steps to adjust the contact spring: 1. Using a small flat head screwdriver, place the flat side of the screwdriver  behind the contact bar as indicated and bend the contact bar so that the  contact rests in the center of the slot adjacent to the element socket.
  • Page 11 Introduction 2. After centering the contact, bend the contact bar slightly toward the center  of the element socket bore, so that the profile of the element contact is  visible when viewing the element socket from the top of the socket bore. Note: If the contact is accidentally moved too far, the element will  not slide into the socket. Move the contact back into the recessed  area and repeat the process.
  • Page 12: Chapter 2 Installation

    Chapter 2 Installation Unpacking and Inspection 1. Carefully inspect shipping container for signs of damage.   If the shipping container is damaged, do not unpack the unit.  Immediately notify the shipping carrier and Bird Technologies.  If the shipping container is not damaged, unpack the unit. Save  shipping materials for repackaging. 2. Inspect unit for visual signs of damage.  Note: If there is damage, immediately notify the shipping carrier  and Bird Technologies.
  • Page 13: Connecting The Directional Power Sensor (Dps)

    Installation Connecting the Directional Power Sensor (DPS). WARNING Never attempt to connect or disconnect RF equipment from the transmission  line while RF power is being applied. Leaking RF energy is a potential health hazard. WARNING RF voltage may be present in RF element socket. Keep element in socket  during operation. 1. Do one of the following: To connect a 5009 DPS: Note: Only use DPM elements in the 5009 DPS.
  • Page 14 Bird Directional Power Sensors  Connect one end of data cable to the RJ‐25 connector on the 5009.  Connect the other end of the data cable to one of the channel  input connectors on a Bird Channel Power Monitor. Figure 1 5009 Cable Connection b. To connect a 5010B or 5010T DPS:  Connect the DPS to the “Sensor” serial port on the Bird Digital  Power Meter using the sensor cable provided. Figure 2 5010 Cable Connection To connect a 5014 DPS: Note: There are currently three connection options for the 5014  DPS.  Connect the DPS to a USB port on a PC using the sensor cable pro‐ vided.Use VPM3 software to communicate with the DPS.  Connect the DPS to the “Sensor” USB port on a Bird Digital Power  Meter using the sensor cable provided.   Connect the DPS to an Android device using an OTG cable and USB  Cable. Use the Bird RF Meter App to communicate with the DPS.
  • Page 15 Installation Figure 3 5014 Cable Connections 2. Connect the RF line to the DPS so that the arrow on the sensor points  towards the load, see "Element Orientation" on page 2.  Note: The arrow on the forward element should point towards  the load.  Note: The arrow on the reflected element should point towards  the source.  Note: Both elements must be either APM/DPM or 43 types, do  not mix elements. 3. Refer to DPM/VPM3/CPM manuals for setup parameters for the desired  measurement.  Note: Use the forward element’s power rating when setting up  the device.
  • Page 16: Chapter 3 Specifications

    Chapter 3 Specifications 5009 Specifications Sensor Type Thruline two‐element line section DPM elements ONLY Elements Select two elements from the same series, with RFL  power 1/10 of FWD power. Frequency Range  2 – 1000 MHz Average Power Measurements DPM Elements, Forward or Reflected Direction Power Measurement  0.1 W to 1 kW Range Power Measurement  ± 5% of full scale average power (95% c.l.) Accuracy Match Measurement  Match Range Return Loss 0 to 20 dB  0.1 to 1 Rho ( ) 1.22 to 99.99 VSWR Twice the Avg Power Uncertainty Uncertainty (Calculated from forward and reflected uncertainty) Settling Time, Max 2.5 seconds Impedance, Nominal...
  • Page 17 Specifications Temp, Storage –40 to +75 °C (–40 to +167 °F) Humidity, Max 95% (non‐condensing) Altitude, Max 3,000 m (10,000 ft.) 5.0” x 2.4” x 2.0” Dimensions, Nominal (130 x 60 x 50 mm) Weight, Nominal 0.9 lb. (0.4 kg) 1 Exact value depends on element selected...
  • Page 18: 5010B, 5010T Specifications

    Bird Directional Power Sensors 5010B, 5010T Specifications Sensor Type Thruline two‐element line section Elements Select two elements from the same series, with   RFL power 1/10 of FWD power.   5010B APM or 43 series elements 5010T APM elements only Frequency Range  2 – 3600 MHz Average Power Measurement APM Elements, Forward or Reflected Direction 0.1 W to 1 kW Power Measurement Range  ± 5% of reading (95% c.l.) Accuracy  Peak/Average Ratio, Max 10 dB Detector Response (5010T only) 230 ms 43 Elements, Forward or Reflected Direction Power Measurement Range 0.1 W to 10 kW Power Measurement Accuracy ± 5% of full scale average power (95% c.l.) Peak Power Measurement  43 Elements only, Forward direction only ...
  • Page 19 Specifications Input VSWR, Max. 1.05:1 up to 1 GHz 30 dB Directivity, Typical  RF Connectors QC Type (N(F) normally supplied) Interface Connector DB‐9 Power Supply From host instrument via cable Mechanical Shock and Vibration In accordance with MIL‐PRF‐28800F Class 3 CE compliant. Refer to DOC for specific  standards. Recommended Calibration Interval 1 year Temp, Operating –10 to +50 °C (+14 to +122 °F) Temp, Storage –40 to +75 °C (–40 to +167 °F) Humidity, Max 95% (non‐condensing) Altitude, Max 3,000 m (10,000 ft.) 5.0” x 2.4” x 2.0” Dimensions, Nominal (130 x 60 x 50 mm) Weight, Nominal 0.9 lb. (0.4 kg) 1 Exact value depends on element selected 2 Above 35 °C or below 15 °C add 2%...
  • Page 20: 5014 Specifications

    Bird Directional Power Sensors 5014 Specifications Sensor Type Thruline two‐element line section APM or 43 series elements. Select two  Elements elements from the same series, with RFL power  1/10 of FWD power. 2 – 3600 MHz Frequency Range  Average Power Measurement  APM Elements, Forward or Reflected Direction 0.1 W to 1 kW Power Measurement Range ± 5% of reading (95% c.l.) Accuracy  Peak/Average Ratio, Max 10 dB 43 Elements, Forward or Reflected Direction Power Measurement Range 0.1 W to 10 kW ± 5% of full scale average power  Power Measurement Accuracy (95% c.l.) Peak Power Measurement  43 Elements only, Forward direction only  Pulse Width, Min 2 – 25 MHz 15 µs 25 – 100 MHz 1.5 µs > 100 MHz 800 ns Rep. Rate, Min 15 pps...
  • Page 21 Specifications 30 dB Directivity, Typical RF Connectors QC Type (N(F) normally supplied) Interface Connector USB 2.0 Type B Power Supply From host instrument via cable Mechanical Shock and Vibration In accordance with MIL‐PRF‐28800F Class 3 CE compliant. Refer to DOC for specific  standards. Recommended Calibration Interval 1 year Temp, Operating –10 to +50 °C (+14 to +122 °F) Temp, Storage –40 to +75 °C (–40 to +167 °F) Humidity, Max 95% (non‐condensing) Altitude, Max 3,000 m (10,000 ft.) 5.0” x 2.4” x 2.0” Dimensions, Nominal (130 x 60 x 50 mm) Weight, Nominal 0.9 lb. (0.4 kg) 1 Exact value depends on element selected 2 Above 35 °C or below 15 °C add 2%...
  • Page 22: Customer Service

    Bird Directional Power Sensors Customer Service Any maintenance or service procedure beyond the scope of those in this chapter  should be referred to a qualified service center. If the unit needs to be returned for any reason, request an Return Material  Authorization (RMA) through the Bird Technologies website. All instruments  returned must be shipped prepaid and to the attention of the RMA number. Bird Service Center 30303 Aurora Road Cleveland (Solon), Ohio 44139‐2794 Fax: (440) 248‐5426 E‐mail: bsc@birdrf.com For the location of the Sales Office nearest you, visit our Web site at: http://www.birdrf.com...
  • Page 23: Limited Warranty

    Limited Warranty All products manufactured by Seller are warranted to be free from defects in  material and workmanship for a period of one (1) year, unless otherwise  specified, from date of shipment and to conform to applicable specifications,  drawings, blueprints and/or samples. Seller’s sole obligation under these  warranties shall be to issue credit, repair or replace any item or part thereof  which is proved to be other than as warranted; no allowance shall be made for  any labor charges of Buyer for replacement of parts, adjustment or repairs, or  any other work, unless such charges are authorized in advance by Seller. If Seller’s products are claimed to be defective in material or workmanship or  not to conform to specifications, drawings, blueprints and/or samples, Seller  shall, upon prompt notice thereof, either examine the products where they are  located or issue shipping instructions for return to Seller (transportation‐charges  prepaid by Buyer). In the event any of our products are proved to be other than  as warranted, transportation costs (cheapest way) to and from Seller’s plant, will  be borne by Seller and reimbursement or credit will be made for amounts so  expended by Buyer. Every such claim for breach of these warranties shall be  deemed to be waived by Buyer unless made in writing within ten (10) days from  the date of discovery of the defect. The above warranties shall not extend to any products or parts thereof which  have been subjected to any misuse or neglect, damaged by accident, rendered  defective by reason of improper installation or by the performance of repairs or  alterations outside of our plant, and shall not apply to any goods or parts  thereof furnished by Buyer or acquired from others at Buyer’s request and/or to  Buyer’s specifications. Routine (regularly required) calibration is not covered  under this limited warranty. In addition, Seller’s warranties do not extend to the  failure of tubes, transistors, fuses and batteries, or to other equipment and parts  manufactured by others except to the extent of the original manufacturer’s  warranty to Seller. The obligations under the foregoing warranties are limited to the precise terms  thereof. These warranties provide exclusive remedies, expressly in lieu of all other  remedies including claims for special or consequential damages. SELLER NEITHER  MAKES NOR ASSUMES ANY OTHER WARRANTY WHATSOEVER, WHETHER EXPRESS,  STATUTORY, OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND  FITNESS, AND NO PERSON IS AUTHORIZED TO ASSUME FOR SELLER ANY  OBLIGATION OR LIABILITY NOT STRICTLY IN ACCORDANCE WITH THE FOREGOING.
