- Page 1 Directional Power Sensor Model 4043 Operation Manual ©Copyright 2019 by Bird Technologies, Inc. Instruction Book Part Number 920-4043 Rev. E The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
-
Page 2: Safety Precautions
Safety Precautions The following are general safety precautions that are not necessarily related to any specific part or procedure, and do not necessarily appear elsewhere in this publication. These precautions must be thoroughly understood and apply to all phases of operation and maintenance. WARNING Keep Away From Live Circuits Operating Personnel must at all times observe general safety precautions. -
Page 3: Safety Symbols
Safety Precautions Safety Symbols WARNING Warning notes call attention to a procedure, which if not correctly performed, could result in personal injury. CAUTION Caution notes call attention to a procedure, which if not correctly performed, could result in damage to the instrument. Note: Calls attention to supplemental information. -
Page 4: Safety Statements
Directional Power Sensor 4043 Safety Statements USAGE ANY USE OF THIS INSTRUMENT IN A MANNER NOT SPECIFIED BY THE MANUFACTURER MAY IMPAIR THE INSTRUMENT’S SAFETY PROTECTION. EL USO DE ESTE INSTRUMENTO DE MANERA NO ESPECIFICADA POR EL FABRICANTE, PUEDE ANULAR LA PROTECCIÓN DE SEGURIDAD DEL INSTRUMENTO. - Page 5 Safety Precautions SERVICE SERVICING INSTRUCTIONS ARE FOR USE BY SERVICE - TRAINED PERSONNEL ONLY. TO AVOID DANGEROUS ELECTRIC SHOCK, DO NOT PERFORM ANY SERVICING UNLESS QUALIFIED TO DO SO. SERVICIO LAS INSTRUCCIONES DE SERVICIO SON PARA USO EXCLUSIVO DEL PERSONAL DE SERVICIO CAPACITADO. PARA EVITAR EL PELIGRO DE DESCARGAS ELÉCTRICAS, NO REALICE NINGÚN SERVICIO A MENOS QUE ESTÉ...
-
Page 6: About This Manual
Chapter Layout Introduction — Describes the features of the 4043 Directional Power Sensor. Installation — Describes how to set up and prepare the 4043 Power Sensor for use. Maintenance — This section provides the specifications for the 4043 Power Sensor as well as a model identification table. -
Page 7: Table Of Contents
Bluetooth Communication Model Installation ......7 Pairing the 4043 Bluetooth Sensor with the Bird RF Meter App ..7 Bluetooth Power Sources . -
Page 8: Chapter 1 Introduction
Introduction Purpose and Function The Bird 4043 Series Directional Power Sensors are digital power sensors. The 4043 Series power sensors are typically used to measure forward and reflected average power on a 50 ohm RF transmission line with a maximum 500 watt forward and maximum 50 watt reflected power levels in a frequency band with an overall range of 144 to 940 MHz. -
Page 9: Chapter 2 Serial Communication Model
Chapter 2 Serial Communication Model The 4043 Sensors with an RS-485 serial bus are designed to transfer data to and from a CPM. The serial bus also serves as the power sensor’s power supply. Each sensor is equipped with two RJ-25 jacks for serial communications, RF input and output connectors, and a status indicator. -
Page 10: Serial Communication Power Sensor Installation
Directional Power Sensor 4043 Serial Communication Power Sensor Installation The Bird 4043 Series Directional Power Sensors are designed to be used for continuous power monitoring of Land Mobile Radio (LMR) systems. The 4043 can provide real-time RF forward and reflected power and VSWR measurements. - Page 11 7. Configure the sensor via CPM front panel. Refer to the CPM Operation Manual. 8. If additional 4043 power sensors will be connected, connect a data/power cable to the open RJ-25 jack, connect remaining end of cable to additional 4043 sensor.
-
Page 12: Chapter 3 Bluetooth Communication Model
Model The 4043 Sensors with Bluetooth communications interface are designed to connect to the Bird RF Meter App. Once connected, measurement data is transfered to the RF Meter App, the RF Meter App will display the current sensor measurements in numerical and graphical displays. For the sensor to function it must have batteries installed or an external power source connected. - Page 13 Bluetooth Communication Model The following power sources provide the required power to the Bluetooth 4043 sensor: Internal Batteries (customer supplied) - Power may be supplied by three AAA batteries. See "Bluetooth Power Sources" on page 8 DC power supply (12 VDC nominal (7-18 VDC), minimum 50 mA) to RJ25 - Power may be supplied from an external DC power supply through the RJ-25 jack.
-
Page 14: Bluetooth Communication Model Installation
Pairing the 4043 Bluetooth Sensor with the Bird RF Meter App First time pairing of a 4043 Sensor and a device running the Bird RF Meter App is accomplished by pressing the Pair button on the 4043 Sensor, then initiating the Bluetooth connection from within the RF Meter App. -
Page 15: Bluetooth Power Sources
Connect the positive 12 VDC (7-18 VDC) supply output wire to pin 1 of the RJ-25 plug and the ground wire to pin 2 (see Figure 5 2. Insert the RJ-25 plug into either RJ-25 connector on the 4043 sensor. 3. Follow the steps in "Maintenance" on page 9... -
Page 16: Chapter 4 Maintenance
Chapter 4 Maintenance There is no user maintenance for the 4043 power sensor, except battery replacement in the Bluetooth model, See "Bluetooth Power Sources" on page 8 battery replacement. Contact the Bird Service Center in the event the power sensor requires maintenance. -
Page 17: Chapter 5 Specifications
Chapter 5 Specifications Specification Value 144 to 940 MHz Frequency Range (model dependent) "Model Identification" on page 12 frequency range of each model. Forward Power Measurement Range 25 W to 500 W Reflected Power Measurement Range 2.5 W to 50 W RF Connectors Input Type-N (male), Type 4.3-10 (male) - Page 18 Directional Power Sensor 4043 Industry Canada RSS-210 modular certification BMD-300/BMD-301 IC: 12208A-04 BMD-350 IC: 12208A-05 EN 60950-1: 2011-01 3.1 (a): Health and Safety of the User EN 301 489-1 V1.9.2 & 3.1 (b): Electromagnetic Compatibility EN 301 489-17 V2.2.1 EN 300 328 V1.9.1 3.2: Effective use of...
-
Page 19: Model Identification
Specifications Model Identification... - Page 20 Directional Power Sensor 4043...
-
Page 21: Limited Warranty
Limited Warranty All products manufactured by Seller are warranted to be free from defects in material and workmanship for a period of one (1) year, unless otherwise specified, from date of shipment and to conform to applicable specifications, drawings, blueprints and/or samples. Seller’s sole obligation under these warranties shall be to issue credit, repair or replace any item or part thereof which is proved to be other than as warranted;...
