Installation/dimensions
MBS 4201
MBS 4251
DIN3852-E-G1/4
G1/2 A (EN 837)
Gasket: DIN 3869-14-NBR
1/4 18 NPT
© Danfoss | DCS (im) | 2017.07
MBS 4701
MBS 4751
ISO 6149-2
1/2 - 14 NPT
M14 x 1.5-6g
incl. O-ring NBR
Dimensioned sketch -
Example
MBS 4201
MBS 4251
ø33.5
2 x ø5.4
M10 x 1
20
30.7
Flange connection
IC.PI.P20.C7.02 | 520B7682 | 5
