Cat. No. 01023094
Rev. D 05/03/13
DCO # 013581
Installation,
Operation and
Service
Instructions
CULLIGAN
®
Series E2 Plus
Reverse Osmosis Water Treatment
Systems
Models from 2011
©2013 Culligan International Com pa ny

Advertisement

Table of Contents
loading

Related Manuals for Culligan E2 Plus Series

Summary of Contents for Culligan E2 Plus Series

  • Page 1 Cat. No. 01023094 Rev. D 05/03/13 DCO # 013581 Installation, Operation and Service Instructions CULLIGAN ® Series E2 Plus Reverse Osmosis Water Treatment Systems Models from 2011 ©2013 Culligan International Com pa ny...
  • Page 2 We encourage Culligan users to learn about Culligan products, but we believe that product knowledge is best obtained by consulting with your Culligan dealer. Untrained individuals who use this manual assume the risk of any resulting property damage or personal injury.

  • Page 3: Table Of Contents

    Installation Operation Instructions Culligan ® Series E2 Plus Reverse Osmosis Water Treatment Systems Models From 2011 Contents Introduction ................ Features ................Series E2 Plus Specifications ..........Unit Configurations ............RO Installation ..............Operation ................. Initial Startup..............Accessories ..............Service and Maintenance ..........
  • Page 4 This page intentionally left blank. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...

  • Page 5: Introduction

    Introduction Read this Manual First Before you operate the Culligan® Series E2 Plus reverse osmosis systems, read this manual to become familiar with the device and its capabilities. Culligan Series E2 Plus reverse osmosis systems are designed to meet the needs of applications for high quality water.

  • Page 6: Features

    The Aqua-Cleer Series Reverse Osmosis systems are the direct result of Culligan’s long time experience in membrane applications around the world. From process water for any size business to treating water for an entire city, Culligan has the knowledge and the range of products you need to get the job done.

  • Page 7: Series E2 Plus Specifications

    Series E2 Plus Specifications NOTE “E2 Plus International Specifications” on page 39 details informations regarding 50Hz units. E2 Plus-2 E2 Plus-3 E2 Plus-4 E2 Plus-5 E2 Plus-6 Model Part Number 01022839 01022840 01022841 01022842 01022843 Nominal Capacity, GPD* 4000 5800 7500 9000 10000...

  • Page 8: Unit Configurations

    Flow Meters Water and Recirculation Front Panel Control Valves Assembly Prefilter Throttling Pump Valve Figure 1. E2 Plus RO front view. Motor Inlet Pump Prefilter Figure 2. E2 Plus RO rear view. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...

  • Page 9: Ro Installation

    RO Installation Unpacking the RO This manual, the warranty, and registration card are packed in the control assembly box. Please complete the registration card and mail it promptly. NOTICE Examine each unit component carefully to check for loose or damaged parts. Report any apparent or concealed shipping damage to the freight carrier immediately.
  • Page 10 CENTER PORT CENTER PORT OF END CAPS. OF END CAPS. OF END CAPS. OFF-CENTER PORT OF END CAPS MODEL E2-4 Plus Figure 3. E2 Plus Module Tubing, two to four membranes. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 11 CENTER PORT OF END CAPS. OFF-CENTER PORT OFF-CENTER PORT OF END CAPS OF END CAPS MODEL E2-5 Plus CENTER PORT OF END CAPS. OFF-CENTER OFF-CENTER PORT PORT OF END OF END CAPS CAPS MODEL E2-6 Plus Figure 4. E2 Plus Module Tubing, five or six membranes. WARNING! The system must be grounded.

  • Page 12: Feed Water Connections

    5) with the addition of a pressure switch which needs to be wired to the control panel (see page 27 for RO standard wiring). A pressurized water storage kit is available under part number D1018976. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 13 Non-Pressurized Product Water Storage Tank Connect the product tubing to a bulkhead fitting at the top of the storage tank. CAUTION! The highest point of the tubing should not be higher than four feet above the top of the reverse osmosis modules, or the elements may be damaged. Depending on the type of application, a level control may be required to turn the unit off when the storage tank is full.

  • Page 14: Operation

    Operation CP Controller Board The CP controller board controls the Culligan E1, M1, and E2 commercial RO product lines. This board requires no pro- gramming and has the following capabilities: • 208-230 VAC single-phase motor up to 1 HP •...

  • Page 15: Initial Startup

    Depending on the feed water quality, it may be possible to operate the unit with a lower concen- trate flow rate, which would decrease operating costs. Refer to the printout from the Culligan® CAAP® (Computer Aided Application Program) software, which indicates maximum allowable recovery.

  • Page 16: Normal Operation

    If any changes are noticed, the product flow should be normalized to determine if cleaning is required (see “Product Flow Calculations” on page 13). Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 17 100 gpd, or 18% (100/570) = 0.18. The elements should be cleaned. 10. If the problem cannot be corrected with the troubleshooting guide and assistance is required, please have the following information available when calling the Culligan dealer: • Product flow rate •...

  • Page 18: Accessories

    When using pressurized storage, you must use a pressure switch that provides a closed signal when the tank is below the shut off pressure, such as the switch provided in the Pressurized Water Storage Kit. CAUTION! Do not apply power to these terminals. Use dry contacts only. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 19 Pretreatment Lockout The controller allows an external contact closure to cause the RO to go into a “pre-treat lockout” condition. This signal is Normally Closed. When OPEN it indicates that the system should STOP because a piece of pretreatment equipment is in a regeneration state.
  • Page 20 Relay to CP: Connect a pair of wires from the PRE-TREAT terminals on the CP board to terminals 2 and 4 on the relay. Remove the installed jumper wire when making this connection. GBE SOFTENER/FILTER CP CONTROLLER AUX OUT 4 Relay Figure 8. GBE to CP relays. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 21 Flush Modes Line Pressure Front Side Flush Prior to Startup When main power is first applied to the CP controller, the controller will first wait for a one-hour delay and will then open the RO inlet solenoid valve and waits for an additional period of one minute. During this minute, feed water under line pressure enters the RO, passes thru the pump and flushes through the upstream (feed water side) of the membranes and then passes to drain.

  • Page 22: Service And Maintenance

    Service and Maintenance Serial Numbers The Culligan units have a serial number located directly behind the electronic controller on the side panel. Do not remove or destroy these serial number labels. The serial number must be referenced if the RO system requires repairs or parts replacement under warranty.
  • Page 23 Unit running but poor quality A. Low pump pressure. A. See 2. (less than 95% rejection) B. Module failure. B. Replace modules. Check product line over pressurization. C. Concentrate throttling valve C. Throttle valve down. open. D. Poor seal on endcap or D.

  • Page 24: Membrane Replacement

    Refer to the section on Initial Startup for information on flushing the shipping solution form the new elements. NOTE Do not forget to enter the new values for flow, pressure, temperature, and TDS. Screws Retaining Rings End Cap O-Rings Housing Membrane Brine Seal Figure 9. Series membrane. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 25 Testing Modules If the product flow calculations show a loss of flow, or the product quality has become poor, one or more elements will require cleaning or replacement. Because poor performance might be due to only one element, test the product flow and quality from individual housings.
  • Page 26 Tubing 1/2” O.D. to connect cleaning adapter ahead of Pre-filter. A pH meter. A pre-filter cartridge (P/N 00955004). Before proceeding record the “NOW” values in Table Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 27 Prepare the Equipment for Cleaning Turn the unit power off. Place the solution tank on the tank stand. Connect the tubing to the cleaning adapter then place the other end of the tubing at the bottom of the solution tank. NOTICE The tubing length should be as short as possible to prevent excessive pressure drop.
  • Page 28 The temperature of the chemical solution will rise as it is recirculated. If the temper- ature exceeds 95°F, turn the unit power off and allow the solution to cool to prevent damage to the RO elements. Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 29 Compare these values with the “new” and “now” values to determine if cleaning has been successful. If cleaning has not been successful, contact the service department at Culligan International Company for suggestions on alternate cleaning chemicals. If cleaning has been successful, note which chemicals were effective. Use the same chemical(s) when the unit is cleaned again.

  • Page 30: Flow Diagram

    Flow Diagram Process Flow Diagram Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...

  • Page 31: Wiring Diagram

    Wiring Diagram Series E2 Plus Wiring Diagram GREEN GREEN 115/230 PRESSURIZED VOLTAGE 115V/230V, STORAGE KIT SELECTOR WHITE 60Hz/50Hz,1PH D1013880 BLACK INCOMING POWER WHITE BLACK POWER CORD, MOTOR WHITE BLACK CABLE, SOLENOID PRETREATMENT LOCKOUT SWITCH A NORMALLY CLOSED switch is required. This switch is OPEN during regeneration, but is A NORMALLY CLOSED Level CLOSED at all other times.

  • Page 32: E2 Plus Ro Parts Diagrams And Lists

    01021928 01021928 01021928 Membrane, 4”x40” 01024290 01024290 01024290 01024290 01024290 Cartridge Filter, 5 micron, 10” BB 00403232 Gate Valve 01021544 Controller 01024598 Piping Feed 01022959 Piping Concentrate 01022958 Piping Product 01021941 Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 33 Front Panel Assembly, 208-230V/ 60 Hz, U.S. Figure 12. E2 Plus front panel assembly. Item Part No. Description — 01022957 FRONT PANEL ASSEMBLY E2 PLUS RO — FRONT PANEL E2 PLUS 01022959 PIPING ASSEMBLY E2 PLUS FEED 01022958 PIPING ASSEMBLY E2 PLUS CONCENTRATE 01022978 Pressure Gauge,0-200 PSI,2-1/2",1/4"CBM 01022233 ROTAMETER 0-10 GPM 01024598 Assembly, CP+ Control, E2+...
  • Page 34 Bushing,3/4x1/4,TxT,PVC Sch.80 — Bushing,3/4x1/2,SxT,PVC Sch.80 — Elbow,3/4",SxS,PVC Sch.80 — Elbow,3/4",TxT,PVC Sch.80 — ADAPTER HOSE BARB 3/4" X 3/4" NPTE — Fitting,Male Connector,1/2Tx1/2NPTE,PI 01021543 Check Valve — Nipple,1/2xClose,PVC Sch.80,TBE — Fitting,Stem Elbow,1/2Tx1/2Stem,PI Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 35 Product Assembly, 208-230V/ 60 Hz, U.S. Figure 14. E2 Plus product piping assembly. Item Part No. Description Quantity — 01021941 Piping Assembly Product — Tee, Threaded, .50 PVC Sch.80, NPT — Nipple,1/2xClose,PVC Sch.80,TBE — Nipple,1/2x5,PVC Sch.80,TBE — Fitting,Male Adaptor,1/2" Cat. No. 01023094 E2 Plus RO Parts Diagrams and Lists...
  • Page 36 E2 Plus concentrate piping sub-assembly. Item Part No. Description Qty. — 01022958 Piping Assembly E2 Plus Concentrate 01021539 Valve,Needle,1/2" Brass — Fitting,Male Connector,1/2Tx1/2NPTE,PI — Fitting,Stem Elbow,1/2Tx1/2Stem,PI — Fitting,Union Tee,1/2T,PI 00901801 Tubing,1/2",PE,Natural Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 37 Membrane Vessel, 208-230V/ 60 Hz, U.S. SCREWS RETAINING RINGS END CAP O-RINGS GASKET END NOTE: 1 Does NOT Include 2 Figure 16. E2 Plus membrane vessel. Item Part No. Description Per Vessel 01021540 Housing, Filter, FRP 4" End Port 01024290 Membrane, 4"x40"...
  • Page 38 .75 x .75 NPT Fitting, Barbed — Elbow, 3/4", TxT, PVC Sch.80 — Nipple, 3/4x3, PVC Sch.80, TBE — Decal, Flow Arrow — Decal, Culligan Script 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 39 Fitting, Union Tee, 1/2T, PI 01008007 Element RO 4" Dia. x 40" — Decal, Flow Arrow — Decal, Culligan Script 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 E2 Plus RO Parts Diagrams and Lists...
  • Page 40 — Nipple, 3/4x3, PVC Sch.80 TBE 01008007 Element RO, 4" Dia x 40" — Decal, Culligan Script — Decal, Flow Arrow 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 41 Fitting, Union Tee, 1/2T, PI — Fitting, Union Elbow, 1/2T, PI 01008007 Element RO, 4" Dia x 40" — Decal, Culligan Script — Decal, Flow Arrow 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 E2 Plus RO Parts Diagrams and Lists...
  • Page 42 — 01024598 Controller, CP Plus, Assembly 01024191 Enclosure, Global Control 01023445 Plug, Watertight, .625 Dia. 01024179 Cord, NEMA, 5-15 14/3, 108"L 01016142 Locknut, 1/2", Nylon 01014886 Plug Dome .875 Hole HEYC Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...

  • Page 43: Appendix A Series E2 Plus International

    Appendix A Series E2 Plus International E2 Plus International Specifications E2 Plus-2 E2 Plus-3 E2 Plus-4 E2 Plus-5 E2 Plus-6 Model Part Number 01023850 01023851 01023852 01023853 01023854 Nominal Capacity, GPD* 3360 4870 6300 7560 8400 Dimensions, Series E2 Plus Units Width - in [mm] 25.8 [655.3] Depth - in [mm]...
  • Page 44 Filter Array, 3-1 01021928 01021928 01021928 Membrane, 4”x40” 01024290 01024290 01024290 01024290 01024290 Cartridge Filter, 5 micron, 10”BB 00403232 Gate Valve 01021544 Controller 01024598 Piping Feed 01022959 Piping Concentrate 01022958 Piping Product 01021941 Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 45 Front Panel Assembly, 220V/ 50 Hz, International Figure 23. E2 Plus front panel assembly. Item Part No. Description — 01022957 FRONT PANEL ASSEMBLY E2 PLUS RO — FRONT PANEL E2 PLUS 01022959 PIPING ASSEMBLY E2 PLUS FEED 01022958 PIPING ASSEMBLY E2 PLUS CONCENTRATE 01022978 Pressure Gauge,0-200 PSI,2-1/2",1/4"CBM 01022233 ROTAMETER 0-10 GPM 01024598 Assembly, CP+ Control, E2+...
  • Page 46 Bushing,3/4x1/4,TxT,PVC Sch.80 — Bushing,3/4x1/2,SxT,PVC Sch.80 — Elbow,3/4",SxS,PVC Sch.80 — Elbow,3/4",TxT,PVC Sch.80 — ADAPTER HOSE BARB 3/4" X 3/4" NPTE — Fitting,Male Connector,1/2Tx1/2NPTE,PI 01021543 Check Valve — Nipple,1/2xClose,PVC Sch.80,TBE — Fitting,Stem Elbow,1/2Tx1/2Stem,PI Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 47 Product Assembly, 220V/ 50 Hz, International Figure 25. E2 Plus product piping assembly. Item Part No. Description Quantity — 01021941 Piping Assembly Product — Tee, Threaded, .50 PVC Sch.80, NPT — Nipple,1/2xClose,PVC Sch.80,TBE — Nipple,1/2x5,PVC Sch.80,TBE — Fitting,Male Adaptor, 1/2" Cat.
  • Page 48 E2 Plus concentrate piping sub-assembly. Item Part No. Description Qty. — 01022958 Piping Assembly E2 Plus Concentrate 01021539 Valve,Needle,1/2" Brass — Fitting,Male Connector,1/2Tx1/2NPTE,PI — Fitting,Stem Elbow,1/2Tx1/2Stem,PI — Fitting,Union Tee,1/2T,PI 00901801 Tubing,1/2",PE,Natural — Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 49 Membrane Vessel, 220V/ 50 Hz, International SCREWS RETAINING RINGS END CAP O-RINGS GASKET END NOTE: 1 Does NOT Include 2 Figure 27. E2 Plus membrane vessel. Item Part No. Description Per Vessel 01021540 Housing, Filter, FRP 4" End Port 01024290 Membrane, 4"x40"...
  • Page 50 .75 x .75 NPT Fitting, Barbed — Elbow, 3/4", TxT, PVC Sch.80 — Nipple, 3/4x3, PVC Sch.80, TBE — Decal, Flow Arrow — Decal, Culligan Script 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 51 Fitting, Union Elbow, 1/2T, PI — Fitting, Union Tee, 1/2T, PI 01008007 Element RO 4" Dia. x 40" — Decal, Flow Arrow — Decal, Culligan Script 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 Series E2 Plus International...
  • Page 52 — Nipple, 3/4x3, PVC Sch.80 TBE 01008007 Element RO, 4" Dia x 40" — Decal, Culligan Script — Decal, Flow Arrow 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
  • Page 53 Fitting, Union Tee, 1/2T, PI — Fitting, Union Elbow, 1/2T, PI 01008007 Element RO, 4" Dia x 40" — Decal, Culligan Script — Decal, Flow Arrow 01024102 Saddle Strap Kit (2 straps, 2 saddles, 4 screws) Cat. No. 01023094 Series E2 Plus International...
  • Page 54 Controller, CP Plus, Assembly 01024191 Enclosure, Global Control 01023445 Plug, Watertight, .625 Dia. 01024179 Cord, NEMA, 5-15 14/3, 108"L 01016142 Locknut, 1/2", Nylon 01014886 Plug Dome .875 Hole HEYC 01022319 Cord, M2, Motor Power Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...

  • Page 55: Appendix B Basic Principles

    Appendix B Basic Principles Reverse Osmosis In order to understand reverse osmosis, we must first define osmosis. Osmosis is the passage of a liquid through a semi-permeable membrane. A semi-permeable membrane is a membrane which allows one component of a solution to pass through it and not the others.
  • Page 56 *Short term cleaning is acceptable for pH ranges between 2.0/12.0. Additional treatment is required when chloramines are present and the pH levels exceed 9.0. NOTICE In some applications, a water softener is not required. Consult an independently operated Culligan dealer for further information on these special applications. Cat. No. 01023094...

  • Page 57: Index

    Index Symbols Level Control Limits, Feed Water 208-230V/ 60 Hz, U.S. 28, 29, E2-2 Plus 34, Line Pressure Front Side Flush 30, 31, 32, 33, 34, 35, 36, E2-3 Plus 36, Every Two Hours of Contin- E2-4 Plus 34, 35, 46, uous Make Water 220V/ 50 Hz, International 40, 41, E2-5 Plus 35, 36, 47,...
  • Page 58 208-230V/ 60 Hz, U.S. Wiring for Hi-Flo® 2e, Hi-Flo® Series E2 Plus Major Components 55e, CSM Softeners and Fil- and Water Connections, ters with MVP controls 220V/ 50 Hz, International Series E2 Plus Specifications Cat. No. 01023094 Culligan® Series E2 Plus Reverse Osmosis...
