WIKA 53 Series Operating Instructions Manual
Bimetal thermometer
Hide thumbs
Also See for 53 Series:
- Operating instructions manual (68 pages) ,
- Operating instructions manual (64 pages) ,
- Operating instructions manual (18 pages)
Advertisement
Advertisement
Related Manuals for WIKA 53 Series
Summary of Contents for WIKA 53 Series
- Page 1 Operating instructions Betriebsanleitung Mode d'emploi Manual de instrucciones Bimetal thermometer, models 53, 54, 55 Bimetall-Thermometer, Typen 53, 54, 55 Thermomètre bimétalliques, types 53, 54, 55 Termómetro bimetálicos, modelos 53, 54, 55 Model A5301 Model S5412 Model R5502...
-
Page 2: Table Of Contents
Contents Contents General information Safety Specifications Design and function Transport, packaging and storage Commissioning, operation Maintenance and cleaning Dismounting, return and disposal WIKA operating instructions models 53, 54, 55... -
Page 3: General Information
The general terms and conditions, contained in the sales ■ documentation, shall apply. Subject to technical modifications. ■ Further information: ■ - Internet address: www.wika.de / www.wika.com - Relevant data sheet: TM 53.01, TM 54.01, TM 55.01 WIKA operating instructions models 53, 54, 55... -
Page 4: Safety
(thermowell, thermowell stem) with the medium must be tested. Non-observance can result in serious injury and/or damage to equipment. Further important safety instructions can be found in the individual chapters of these operating instructions. WIKA operating instructions models 53, 54, 55... - Page 5 WIKA operating instructions models 53, 54, 55...
-
Page 6: Specifications
Stainless steel 1.4571 connection Ingress protection IP 65 per EN 60529 / IEC 529 IP 66, liquid-filled For further specifications see WIKA data sheet TM 53.01, TM 54.01 or TM 55.01 and order documentation. WIKA operating instructions models 53, 54, 55... -
Page 7: Design And Function
Keep the packaging as it will provide optimum protection during transport (e.g. change in installation site, sending for repair). 5.3 Storage Permissible conditions at the place of storage: Storage temperature: -20 ... +60 °C WIKA operating instructions models 53, 54, 55... -
Page 8: Transport, Packaging And Storage
The use of liquid damping is always recommended for temperatures near the dew point (±1 °C around 0 °C). WIKA operating instructions models 53, 54, 55... -
Page 9: Commissioning, Operation
The working temperature of the thermal compound is -40 ... +200 °C. WIKA operating instructions models 53, 54, 55... -
Page 10: Maintenance And Cleaning
The indicator should be checked once or twice every year. To do this the instrument must be disconnected from the process and checked using a temperature calibrator. Repairs must only be carried out by the manufacturer. WIKA operating instructions models 53, 54, 55... -
Page 11: Dismounting, Return And Disposal
8.2 Return WARNING! Absolutely observe when shipping the instrument: All instruments delivered to WIKA must be free from any kind of hazardous substances (acids, bases, solutions, etc.). WIKA operating instructions models 53, 54, 55... - Page 12 / Service / Return 8.3 Disposal Incorrect disposal may endanger the environment. Dispose of instrument components and packaging materials in an environmentally compatible way and in accordance with the country- specific waste disposal regulations. WIKA operating instructions models 53, 54, 55...
