1.13 TABLES OF EQUIVALENT LENGTH FACTORS.

DUCT TYPE
Concentric pipe 80/125 Ø m 1
Concentric bend 90° 80/125 Ø
Concentric bend 45° 80/125 Ø
Terminal complete with concentric
horizontal intake-exhaust 80/125 Ø
Concentric horizontal intake-exhaust
terminal 80/125 Ø
Terminal complete with concentric verti-
cal intake-exhaust 80/125 Ø
Concentric vertical intake-exhaust
terminal 80/125 Ø
Equivalent length in
m of concentric pipe
80/125 Ø
1.0 m
Complete exhaust terminal 80 Ø, 1 m
1.9 m
1.4 m
5.5 m
4.7 m
Terminal complete with vertical
3.4 m
2.7 m
11
DUCT TYPE
Pipe 80 Ø, 1 m
Exhaust terminal 80 Ø
Bend 90° 80 Ø
45° 80 Ø Bend
exhaust 80 Ø
Equivalent length in
metres of pipe 80 Ø
Exhaust
1.0 m
Exhaust
2.6 m
Exhaust
1.6 m
Exhaust
2.1 m
Exhaust
1.3 m
Exhaust
m
3
