Shower ClearMirror
Installation Instructions
Shower ClearMirror Fog-free
Shower Mirrors
Models 16101-121224M, 122424M 161624M, 181824M, & Custom
June 2018
Only wire the Shower ClearMirror to the 24-volt plug-in power supply included with this
product. Install in accordance with all applicable safety, national and local electrical codes.
Read all instructions before using the Shower ClearMirror.
Advertisement
Table of Contents
Related Manuals for ClearMirror Shower ClearMirror Series
Summary of Contents for ClearMirror Shower ClearMirror Series
-
Page 1: Installation Instructions
Models 16101-121224M, 122424M 161624M, 181824M, & Custom June 2018 IMPORTANT INSTRUCTIONS Only wire the Shower ClearMirror to the 24-volt plug-in power supply included with this product. Install in accordance with all applicable safety, national and local electrical codes. Read all instructions before using the Shower ClearMirror. -
Page 2: General Guidelines
• SAVE THESE INSTRUCTIONS. Installation Activate the Shower ClearMirror by a switch. You may decide to connect it to another light or fan to ensure it is turned off when not in use. 1. Before installing ceramic tile, measure for desired Shower ClearMirror height from the finished shower floor. - Page 3 Observe electrical load requirements. Ensure total amperage does not exceed rating of the wall switch (i.e. 15-amp switch), circuit or existing wiring. Use minimum 18-gauge wire from transformer to Shower ClearMirror connection. 1. Run power supply wires from the provided low-voltage transformer to the opening at the mirror location.
- Page 4 Amazon or CR Laurence. This product does have a shelf life so we are not able to provide it with your shower mirror. Other mirror mastics will work but Gunther Premier Plus is recommended. See clearmirror.com/FAQ...
-
Page 5: Operating Instructions
OPERATING INSTRUCTIONS • The Shower ClearMirror assembly must be properly installed before it is used. • The Shower ClearMirror is to be installed flush with the tile with wiring fed from behind the full, wall-mounted assembly. • Be certain that the controls are operational per the instructions in that the bathroom light, ceiling fan or alternate switch power on and power off the Shower ClearMirror. - Page 6 WARRANTY INFORMATION NewHome Bath & Mirror, Inc. DBA ClearMirror and its affiliates will not warranty the labor or material costs for installation, replacement or use of ShowerLite when operated in an application that is lower than 50° F.
