UNIT DESCRIPTION
The DLM Wireless photo sensor is a wireless battery
powered light sensor intended for operation with Wireless
room controllers. It is an open loop photo sensor that
measures daylight in foot candles to automatically switch or
dim zones of lighting. The sensor sends light level signals to
LMRC-611MCC room controllers to adjust connected lighting
loads.
Sensor Installation and Configuration Overview
1. Mount the photosensor so that the Daylight Viewing
Port directly views the daylight entering the space
through a window or a skylight. See Placement
Guidelines and Mounting the Photosensor.
2. Turn ON power to the room controller.
3. Use LMCS-100 or the DLM Configuration App software
to complete the configuration process. The LMDL-600
will not operate properly until the configuration and
calibration is successful.
4. Ensure there is a minimum 5fc of ambient light in the
space.
5. From LMCS or the App, select the room network
you'd like to calibrate and select the LMDL to start the
calibration process. You will need a light level meter in
order to record the fc data of the space for each prompt
in the software. Place the light meter at the task level.
6. After following the software prompts, once calibrated,
you can adjust switch overrides and other features by
selecting the LMRC that the LMDL is paired to.
Application Note: Depending on external factors (such as
environment, fixture location and dimming curve of the load)
an adjustment factor may be needed to achieve the target
light level after calibration. If the calibrated LMDL and fixture
combination outputs less light than the target light level
(set in the LMRC parameter), adjust the 'target light level'
parameter by increasing to an appropriate amount.
IMPORTANT: You must wake the device (press the Config
button) before commissioning. If the LMDL is paired to a
secure room with LMCS, LMCS is required to calibrate
the sensor. If the LMDL is paired to a secure room with
the DLM Configuration App, please calibrate with the DLM
Configuration App.
Wattstopper
DLM Wireless Photosensor with IPv6/Bluetooth
Installation Instructions • Instructions d'Installation • Instrucciones de Instalación

SPECIFICATIONS

Light sensor range .................................................................. 1 to 1,500 fc
Power Supply .......................... Battery powered, CR123A Lithium Ion, 3 VDC
Connection to DLM Network ... Wireless via LMRC-611MCC room controllers
Wireless Hardware
Radios: ................................................................ Two IEEE 802.15.4
Frequency: ............................................................................. 2.4Ghz
Antennas: ................................ IPv6 Mesh and Bluetooth low energy
Wireless Standards
Radio 1: .........................................................IPv6 Mesh (6LoWPAN)
Range: .......................................................................up to 60 ft.
Radio 2: ............................................................ Bluetooth low energy
Range: .......................................................................up to 30 ft.
Wireless Encryption
AES-128 bit symmetric key, randomly generated per PAN
Shared via secured DTLS only
Environment:
Operating Temperature .....................................32° to 104°F (0° to 40°C)
Storage Temperature .......................................23° to 140°F (-5° to 60°C)
Relative Humidity ...........................................5 to 95% (non condensing)
Other:
Plenum Rating ................................................................................ UL2043
Compliance/Regulatory
FCC, RoHS,
Bluetooth certified
UL and cUL listed (E101196)
Patent Pending
WIRELESS DLM CONNECTION
LMBR-650
For networking
and managing
rooms, floors,
and building
(optional)
LMRC-611MCC
Wireless
Dimmer and/or
Scene Switch
Sensor Params
LMPX-600
LMPC-600
Mode Auto On
Blink On
Load Type Dim
DLM Configuration App
on a mobile device
®
® Low Energy Technology
IPv6 Mesh for secure
networking of DLM
rooms and devices
over 6LoWPAN
Secure Bluetooth
low energy
communication for
mobile App support
LMDL-600
Wireless
Photosensor
NOTE: The LMDL cannot be
used in a Hybrid DLM Room.
The LMDL must be used with
wireless room controllers.
