APPLICATION
AR luminaires are designed for use indoors, outdoors, wet locations, areas containing moisture, dirt,
corrosion, vibration and rough usage. This luminaire is certi ed by NSF for use in Splash-zone and
Non-Food areas of food processing locations as de ned in NSF-2. The AR luminaire has been certi ed for
use on marine vessels inside, outside, and in other severely wet saltwater environments.
Certi ed to:
Housing:
Input Voltage:
Electrical Ratings:
Connections:
Temperature Range:
Ingress Protection:
MADE IN CANADA
TM
UL 1598, UL 1598A, and UL 8750;
CSA 22.2 No. 250.0 and CSA22.2 No. 250.13
ABS Listed
Copper-free Cast Aluminium with Polycarbonate lens
Based on luminaire su x in table below: Su x - AC: 120-277 VAC | Su x - HV: 347-480 VAC
INPUT RATED WATTAGE
LUMINANCE
VOLTAGE [Watts]
AC
AR10
HV
AC
AR15
HV
AC
AR20
HV
AC
AR25
HV
AC
AR30
HV
2 x 3/4" NPT Conduit | Black: Line | White: Neutral | Green: Ground
Optional: Purple: 0-10V Dimming (+) | Grey: 0-10V Dimming (-)
For connections use wire rated to a minimum of 90°C. Class 1 Wiring only.
Dimming control wires must be rated 300V minimum for luminaires with su x AC,
600V minimum for luminaires with su x HV.
AR10, 15, 20, 25 AC Models: -40°C to +55°C
AR10, 15, 20, 25 HV Models: -40°C to +50°C
AR30 AC, HV Optical models: -40°C to +45°C
AR30 AC Flood model: -40°C to +40°C
AR30 HV Flood model: -40°C to +45°C
IP66/67 | Suitable For Wet Locations. Marine Outside Type (Salt Water)
