Product Specifications

Division
Applicable
Access methods
Power Source
Emergency Power
Temperature Alarm Temperature sensor
Material
Type of product
Outbody
Installation Guide
* Components of the product may be changed depending
on installation environment.

Main Parts and Functions (Outside)

Main Parts and Functions (Inside)

Normal wooden door
Password
Smart Key(CDL-100WL) Up to 30 smart keys available
Fingerprint (CDL-800WL) Up to 100 fingerprints available
DC 6V
DC 9V
Auxiliary battery
Out body
In body
CDL-100WL(Smart Key, Anti-fireproof type, Non-key type, Master key door lock)
CDL-800WL(Fingerprtint, Anti-fireproof type, Non-key type, Master key door lock)
Inbody
User Manual
Thickness 35mm~55mm
4~12digit nember(up to 4 password available)
LR6 1.5V AA Alkaline batteries(4ea)
Alkaline battery(optional)
MICRO USB 5PIN
60'C ± 10'C
AL,ZN,ABS,PC
AL,ZN,ABS,PC
Mortise
Batteries Outdoor Shaft
Smart card
Name
No.
Outdoor handle and number
1
plate
Input for smart key
（CDL-100WL）
2
Input for fingerprints
（CDL-800WL)
3 Door open indicator
4 [Start] button
5 Emergency Power Teminal
6 Micro USB 5PIN
No. Name
1 Battery Cover
2 [Regi s trati o n] Button
3 Doubl e Lock Button
4 I n ner Handl e
Contents
Striker Screw
Feature
Able to enter numbers when registering/changing
access code.
Use to open/close the door from outside
Able to register smart keys and open the door
with the register smart keys
Able to register fingerprints and open the door
with the register fingerprints
Able to check whether the door is opened（CDL-
800WL)
Make Led on nember plate to be turned on.
When the batteries run out comlpetely, please
contact the 9v battery to emergency power
terminal and the power will be on
When the batteries run out comlpetely, please
contact the auxilliary battery to emergency power
terminal and the power will be on
Feature
Cover to protect battery and [Regi s trati o n] button
To regi s ter/change smart key, f i n gerpri n t or
access code
To l o ck the door and make i t l o cked f r om the
ousi d e such as at ni g ht ti m e
To open/cl o se the door at i n si d e
