User and installation manual Contents Page 1.1. Check before taking a sauna bath 1.2. Sauna room 1.3. Operation of the sauna heater controls 1.4. Operation of the sauna heater controls 1. Preparing for sauna heater installation 2. Installation 3. Safety clearances for sauna heaters 1101 and 1105 – XX …….. 4.
User and installation manual WARNINGS 1.1. Check before taking a sauna bath The sauna room is suitable for taking a sauna bath. The door and the window are closed. The sauna heater is topped with stones that comply with the manufacturer's recommendations, the heating elements are covered with stones, and the stones are piled sparsely.
User and installation manual 1. Preparing for sauna heater installation Check the following before installing the sauna heater. - The ratio of the heater's input (kW) and the sauna room's volume (m ). Volume recommendations are presented in Tables 1, 2 and 3 on page 5, 6 and 7. The minimum and maximum volumes must not be exceeded. - The height of the sauna room must be at least 1900 mm or 2200 mm depending on the heater power.
User and installation manual 3. Safety clearances for sauna heaters 1101 and 1105 – XX (SKLE / Laava and SKLA / Magma) 40 mm > min 100mm 500 mm Figure 1. Installation location of the OLET 31 sensor Figure 2. Alternative installation location of 40 mm from the ceiling in the centre of the heater.
User and installation manual Sauna volum Minimum distances Power Adequate amount of stones Approx. kg 18 30 2100 1400 24 36 2100 1400 30 46 2200 1500 Table 2 Safety clearances 1101 – xx (SKLA / Magma) Note! Alternative installation location of the OLET 31 sensor on a ceiling in the centre above the heater.
User and installation manual Adequate amount Power Sauna room Safety clearances min of stones Volum Min height On the sides In front To the ceiling Approx. kg 8-13 1900 1150 10,5 9-15 1900 1150 12,0 10-18 2100 1350 15,0 14-24 2100 1350 Safety clearances to heater 1106 –...
User and installation manual 8. Using the contactor cases The contactor case 2005 – 50 (WE – 50), 2005 – 52 (WE - 52) as well as an additional contactor case 2005 – 51 (WE – 51) supplied with the second heater can be used with the following sauna heaters: - SKLE, LAAVA.…1105 - ….
The switch part is installed on the door frame and the magnet is installed on the door. The distance between the switch and the magnet is 18 mm. When the door switch is installed on the top part of the door, TylöHelo recommends using the TylöHelo model with product number 0043233, SSTL 8260371.
User and installation manual 12. Wiring diagram WE - 50 and 52 4172 354 SYWE 23 A WE - 50 and WE - 52 Contactor case diagram Figure 7 Wiring diagram for contactor box WE - 50 and 52...
User and installation manual 13. Wiring diagram WE - 51 Additional contactor case WE - 51 for controlling two Power group 2 sauna heaters. Figure 8 Wiring diagram for contactor box WE - 51...
User and installation manual 14. Principle diagram Terminal block Limiter Contactor box WE - 50 Sensor cable 1 Blue OLEA 103 2 White 3 Red 4 Yellow Control panel Contactor box 1601 – 31 WE - 50 1 Yellow 2 Green OLEA 103 3 Red 4 Black...
User and installation manual 15. Connection principle 400V – 415V 3N~ 2 power group 230V 3~ 2 power group OLET 31 Group 1 Group 2 Group 1 Group 2 OLET 31 Heater Heater N L1 L2 L3 N L1 L2 L3 N L1 L2 L3 N L1 L2 L3 N U V W...
User and installation manual Kiuas Teho Ryhmäteho Lämpövastukset Kiuas Teho Ryhmäteho Lämpövastukset Effekt Gruppeffekt Värmeelement 230V Effekt Gruppeffekt Värmeelement 230V Heater Input Group of power Heating elements Heater Input Group of power Heating elements Ofen Leistung Gruppe der leistung Heizelemente Ofen Leistung Gruppe der leistung Heizelemente...
User and installation manual 18. Installation of two SKLA/Magma heaters in a sauna room. Figure 14 Installation of two heaters in a sauna room. NOTE: When installed in parallel, the heaters must be spaced at least twice the A length between them.
