Page 1
Stopper II Heated Enclosure ® STI-1200A-HTR STI-1200A-HTR240 (Outdoor Models) Compliant · Maintains initiating device temperature with external temperatures to -70°F Compliant (-57°C). Independently tested to -102°F (-73°C). · Protects initiating devices for addressable units to UL 38 Standards. · The clear, protective polycarbonate cover is UV-stabilized against discoloration.
Page 2
8. Replacement of heater assembly and gasket is required five years from installation date. Contact STI to order replacement Heater Kit STI-HK3. 9. All field wiring within this enclosure must be rated for a minimum operating range of 0ºC - 110ºC.
MOUNTING SURFACE Installation Instructions Mount Enclosure back box - Refer to Fig 1 1. Set heater assembly with cover aside. Press (4) plastic tabs into slots on back box and drill (4) 1/4” (6.4mm) diameter holes in mounting surface for plastic anchors provided. Attach back box to wall using (4) #10 x 1-1/2”screws provided.
Page 5
COVER AND HEATER ASSEMBLY WARM AIR DUCT (DO NOT COVER WITH PULL STATION) #6-32 x 1 in. PAN HIGH VOLTAGE TERMINAL BLOCK HEAD SCREW (4) PROVIDED SLIDE PLATE 3/8 in. STANDOFF #8-32 x 3/8 in. (4) PROVIDED FLAT HEAD SCREW DUAL MONITOR ADDRESSABLE MODULE (NOT INCLUDED)
Schematic Diagrams HIGH VOLTAGE CIRCUIT 2 AMP CIRCUIT BREAKER OPEN @ 120 ˚ F (40 ˚ OVERTEMP SAFETY CLOSE @ 80 ˚ F (27 ˚ CLOSE @ 40 F (4 ˚ ˚ CONTROL OPEN @ 65 F (18 ˚ ˚ CHASSIS 110 OR 240 VAC EARTH GROUND...
