PRODUCT FEATURES PRODUCT FEATURES OUTSTANDING PERFORMANCE The dryer features the largest capacity, quick drying times, quiet operation, and an energy-saving system. ARTISTIC DESIGN Modern front panel look and big clear glass door make your dryer look stylish EASY OF USE An entire selection of user-friendly functions makes operating the dryer easy.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, Injury to persons, or death. Your Safety and the safety of others is very important.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE BASIC SAFETY PRECAUTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: Items that have been soiled with •...
Page 6
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE ■ WhAT IS NOT COvEREd. Service trips to your home to instruct you on the product. If the product is connected to any voltage other than that shown on the rating plate. If the fault is caused by accidents, neglects, misuses of Acts of God.
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. GROUNdING INSTRUCTIONS This appliance must be grounded.
Page 8
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR INSTALLATION That the appliance must not •...
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE WARNING For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, injury to persons, or death. SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,...
Page 10
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE CAUTION These instructions are only valid if the following country code is on the appliance. If this code is not present on the appliance, it is necessary to refer to the technical instructions which will provide the necessary information concerning the modification of the appliance to the condition of use for the country Before installation, check that the local distribution conditions, nature of gas and pressure, and the adjustment of the appliance are compatible.
INTRODUCING YOUR DRYER INTRODUCING YOUR DRYER Specifications Model RP1329A7S Type Gas Dryer Specification Please refer to the rating label regarding detailed information Rating 220-240V~,50Hz 686 mm (P) x 764 mm (L) x 983 mm (T) (Single Dryer) Size 686 mm (P) x 764 mm (L) x 1954 mm (T) (Stack Dryer) Capacity 10.2 kg...
INTRODUCING YOUR DRYER Control panel features ■ OPL type - Stack Upper (RP1329A7S) 1. display LEd 3. Start/Pause button 2. Cycle button 4. Status LEd...
Page 13
INTRODUCING YOUR DRYER Status LEd display LEd Cycle button Start/Pause button display LEd Start/Pause button The Display shows the vend price, remaining time, and The Start LED flashes when the full vend price has been programming options. satisfied then the cycle has been chosen or the machine Error codes are also displayed here.
OPERATING YOUR DRYER OPERATING YOUR DRYER 1. Ready mode 4. Top off (To add more time) 1) Coin / Card type ■ After a debit card is inserted, the operating time can - The cycle LEDs flash at the same time, when the be increased to 10 minutes/10p (default), when the price of cycles are equal.
PROGRAMMING MODE PROGRAMMING MODE 1. Programming mode You can check machine information or change setting on Program setup or Diagnostic test. There are two methods that you can enter programming mode. ■ how to enter “Programming mode” ■ how to use button You can enter programming mode only for Idle state You can change Dryer vend price, cycle time and Cycle and pause state.
Page 16
PROGRAMMING MODE Card / Coin type ■ Algorithm Flow Chart shows how to control programming mode. ■ B efore program set, check the structure of programming mode. 1. Turn on/off toggle switch or Insert the service card to entering set up mode. 2.
Page 17
PROGRAMMING MODE OPL type ■ Algorithm Flow Chart shows how to control programming mode. ■ B efore program set, check the structure of programming mode. OPL/Coin Type 1) Push the High Temp. and Low Temp. button at the same time. 2) Push the Med Temp. button 3 times. 3) Push the Start button.
PROGRAMMING MODE PROGRAMMING MODE - Setup Mode Setup Mode : (display) ■ You can change dryer vend price, cycle time, and cycle parameters, etc. ■ Entering set up mode • Coin type - Turn on/off toggle switch. • Card type - Insert the service card. •...
PROGRAMMING MODE 2. how to change special price Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 3. how to enter the Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 21
PROGRAMMING MODE 3-1. Special price day setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 22
PROGRAMMING MODE 3-2. vend type setup - card type or coin type setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
Page 23
PROGRAMMING MODE 3-3. Top off apply or not setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 4. how to enter the special price day setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
Page 25
PROGRAMMING MODE 4-1. how to change sunday Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 5. Special price beginning time setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 6. Special price ending time setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 7. Regular priced dryer cycle time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 8. Special priced dryer cycle time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
PROGRAMMING MODE 9. value of coin 1 Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp.
Page 31
PROGRAMMING MODE 10. value of coin 2 (Set up for top off price and e-suds coin pulse) Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 11. Top off time Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 12. Beep volume Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. Press the Med Temp. or the Low Temp. button until appears in the display.
PROGRAMMING MODE 13. Time to keep the coin (Use only for coin type) Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
PROGRAMMING MODE 14. Product type setup – coin/card type or OPL setup Entering set up Button display mode. You will see LqC1 Press the high Temp. button. Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button.
PROGRAMMING MODE PROGRAMMING MODE - Test Mode diagnostic tests : (display) This program has been added for testing the dryer and detecting errors. Entering the test mode data Name Button display description Insert service card (card type)Turn on/off toggle switch (coin type) 1.
Page 37
PROGRAMMING MODE 2. Factory reset - EEPt After a factory reset, all values are reset to the default values. Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display. Press the Start button.
Page 38
PROGRAMMING MODE 3. Time Set Up Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. button until appears in the display. Press the Start button. The display cycles through 2000 --> 0101 --> Sat --> 0000. Press the Start button.
Page 39
PROGRAMMING MODE 4. Courtesy cycle Courtesy cycle is like a complimentary cycle given to the customer when the dryer goes out of order when the customer has made the payment to dry one’s clothes. Entering set up Button display mode. You will see LqC1 Press the Med Temp.
Page 40
PROGRAMMING MODE 5. Cycle Kill ■ Coin Entering set up Button display mode. You will see LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display. Press the Start button. Press the Med Temp. button until appears in the display.
Page 41
PROGRAMMING MODE PROGRAMMING MODE - Collect Mode Collect Information data : CLCt (display) The dryer collects the usage data so that the owner can check various information like number of various cycles used, how many times card or coins used, etc. Entering the collect mode data Name Button...
Page 42
PROGRAMMING MODE ■ Collect Mode data lists Abbreviation Meaning description Itnr Interval No Runs Itnr is not available in dryer. Ittb Interval Trouble Cycles Money inserted, but no run. ItPd Interval Power Downs No money, but ran. Interval Unauthorized Service Door Number of Unauthorized Service Door Itdd Openings...
Page 43
MAINTENANCE MAINTENANCE ■ Regular cleaning Cleaning the Lint Filter Always clean the lint filter after every cycle. WARNING To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Unplug the dryer before cleaning to avoid the risk of electric shock.
Page 44
Stack position dryer Washer dryer RP1329AN7S Fh069FdF Stack position RP1329A7S RP1329AN1 Fh069Fd2F Rv1329C7P 2. Sliding kit - Sliding kit is provided in the upper dryer. - Sliding kit includes the slide bracket(2), sliding pad(4), screw(10), machine screw(8). 1) Sliding bracket...
Page 45
STACK MACHINE INSTALLATION INSTRUCTIONS 4. Stacking the machine - Lift and stack the upper dryer on the lower washer. - Set the rear of the upper dryer and the rear of the lower washer in the same position. - Push the upper dryer matching the slide & stacking bracket to make upper and lower front parallel. 5.
ERROR MODE / POWER FAIL RECOVERY / DEFAULT DRYER SETTINGS ERROR MODE ■ M eaning of Error Codes that LEd displays during occurrence or problem. dryer error code PROBLEM POSSIBLE CAUSE SOLUTION It is displayed when thermistor is opened or Thermistor should be replaced.
Page 47
6. Damage or failure resulting from misuse, abuse, improper installation, repair, maintenance, or foreign objects placed in or connected to the Product. Improper repair to include use of parts not approved or specified by LG. 7. Damage or failure caused by unauthorized modification, accessories, alteration, or if it is used for other than in- tended purpose.
DAFTAR ISI DAFTAR ISI FITUR PRODUK 10. Nilai koin 2 (Mempersiapkan untuk top off harga dan e-suds koin nadi) 11. Waktu pengisian penuh 12. Volume bunyi alarm PETUNJUK KESELAMATAN 13. Waktu untuk menyimpan koin (Digunakan PENTING hanya untuk tipe koin) 14.
Page 51
FITUR PRODUK FITUR PRODUK KINERJA YANG LUAR BIASA Pengering ini memiliki kapasitas terbesar, waktu pengeringan yang cepat, pengoperasian yang tenang, dan lebih hemat energi DESAIN YANG ARTISTIK Tampilan panel depan yang modern dan pintu kaca bening yang jernih membuat mesin pengering Anda terlihat bergaya MUDAH DIGUNAKAN Seluruh pilihan fungsi yang mudah digunakan memudahkan pengoperasian pengering.
Page 52
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN PERINGATAN Demi keselamatan Anda, informasi dalam buku panduan ini harus diikuti untuk meminimalkan risiko kebakaran atau ledakan, sengatan listrik, atau agar tidak terjadi kerusakan properti, cedera pada orang, atau kematian. Keselamatan Anda dan keselamatan orang lain sangat penting.
Page 53
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN TINDAKAN PENCEGAHAN TERKAIT KESELAMATAN DASAR PERINGATAN Untuk mengurangi risiko kebakaran, sengatan listrik, atau cedera pada orang saat menggunakan mesin cuci, ikuti tindakan pencegahan dasar, termasuk yang berikut ini: PERINGATAN Barang yang kotor oleh zat seperti •...
Page 54
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN ■ APA yANG TIDAK TERCAKuP. Perjalanan servis ke rumah Anda untuk memberi Anda petunjuk tentang produk. Jika produk tersambung ke voltase selain yang ditunjukkan pada label spesifikasi. Jika kerusakan disebabkan oleh kecelakaan, kelalaian, penyalahgunaan. Jika kerusakan disebabkan oleh alasan kecuali untuk penggunaan domestik yang normal atau penggunaan sesuai dengan buku panduan pengguna.
Page 55
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN PERINGATAN Demi keselamatan Anda, informasi dalam buku panduan ini harus diikuti untuk meminimalkan risiko kebakaran atau ledakan, sengatan listrik, atau agar tidak terjadi kerusakan properti, cedera pada orang, atau kematian.
Page 56
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN PERINGATAN Demi keselamatan Anda, informasi dalam buku panduan ini harus diikuti untuk meminimalkan risiko kebakaran atau ledakan, sengatan listrik, atau agar tidak terjadi kerusakan properti, cedera pada orang, atau kematian.
Page 57
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN PERINGATAN Demi keselamatan Anda, informasi dalam buku panduan ini harus diikuti untuk meminimalkan risiko kebakaran atau ledakan, sengatan listrik, atau agar tidak terjadi kerusakan properti, cedera pada orang, atau kematian.
Page 58
PETUNJUK KESELAMATAN PENTING PETUNJUK KESELAMATAN PENTING BACA SEMUA PETUNJUK SEBELUM PENGGUNAAN PERHATIAN Petunjuk ini hanya berlaku jika kode negara berikut ada pada mesin. Jika kode ini tidak ada pada mesin, maka perlu mengacu petunjuk teknis yang akan memberikan informasi yang diperlukan mengenai modifikasi mesin dengan kondisi penggunaan untuk negara tersebut.
Page 59
MEMPERKENALKAN MESIN PENGERING ANDA MEMPERKENALKAN MESIN PENGERING ANDA SPESIFIKASI Model RP1329A7S Tipe Mesin Pengering Gas Spesifikasi Silakan lihat label spesifikasi mengenai informasi terperinci Catu Daya 220-240V~, 50Hz 686 mm (P) x 764 mm (L) x 983 mm (T) (mesin pengering tunggal)
Page 60
MEMPERKENALKAN MESIN PENGERING ANDA Fitur panel kontrol ■ Tipe OPL - Susun atas (RP1329A7S) 1. Tampilan LED 3. Tombol Start/Pause 2. Tombol Siklus 4. LED Status...
Page 61
MEMPERKENALKAN MESIN PENGERING ANDA LED Status LED Tampilan Tombol siklus Tombol Start/Pause LED Tampilan Tombol Start/Pause Tampilan menunjukkan harga vending, sisa waktu, dan LED Start berkedip saat harga vending penuh sudah opsi pemrograman. dilunasi kemudian siklus telah dipilih atau mesin dijeda. Kode kesalahan juga ditampilkan di sini.
Page 62
MENGOPERASIKAN MESIN PENGERING ANDA MENGOPERASIKAN MESIN PENGERING ANDA 1. Mode Siap 4. Pengisian penuh (untuk menambahkan lebih banyak 1) Tipe koin / kartu waktu) - LED siklus berkedip secara bersamaan, bila harga siklusnya sama. ■ Setelah kartu debit dimasukkan, waktu 2) Tipe OPL pengoperasian dapat dinaikkan menjadi 10 - LED siklus menyala bersamaan, dan ‘PUSH’...
Page 63
MODE PEMROGRAMAN MODE PEMROGRAMAN 1. Programming mode Anda dapat memeriksa informasi mesin atau mengubah pengaturan pada Penyiapan program atau Uji diagnostik. Ada dua metode untuk masuk ke mode pemrograman. ■ Cara masuk ke “Mode Pemrograman” ■ Cara menggunakan tombol Anda dapat masuk ke mode pemrograman hanya untuk Anda dapat mengubah harga vending Mesin pengering, keadaan diam dan jeda.
Page 64
MODE PEMROGRAMAN Tipe Kartu/Koin ■ Diagram alir algoritme menunjukkan bagaimana cara mengontrol mode pemrograman. ■ Sebelum program diatur, periksa struktur mode pemrograman. 1. Alihkan sakelar ke nyala/mati atau masukkan kartu layanan, untuk masuk ke mode penyiapan (atau ikuti petunjuk tipe OPL). 2.
Page 65
MODE PEMROGRAMAN Tipe OPL ■ Diagram alir algoritme menunjukkan bagaimana cara mengontrol mode pemrograman. ■ Sebelum program diatur, periksa struktur mode pemrograman. Cara masuk ke mode penyiapan. 1) Tekan tombol High Temp. and Low Temp. secara bersamaan. 2) Tekan tombol Med Temp. 3 kali. 3) Tekan tombol Start.
Page 66
MODE PEMROGRAMAN MODE PEMROGRAMAN - Mode Penyiapan Mode Penyiapan : (display) ■ Anda dapat mengubah harga vending mesin cuci, waktu siklus, dan parameter siklus, dsb. ■ Masuk ke mode penyiapan • Tipe koin - hidupkan / matikan sakelar toggle • Tipe kartu – Masukkan kartu layanan. •...
Page 67
MODE PEMROGRAMAN 2. Bagaimana cara mengubah harga spesial. Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 68
MODE PEMROGRAMAN " 3. Cara memasukkan " Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 69
MODE PEMROGRAMAN 3-1. Penyiapan hari harga spesial Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 70
MODE PEMROGRAMAN 3-2. Penyiapan tipe vending - penyiapan tipe kartu atau tipe koin Masuk ke mode pe- Button Display nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start.
Page 71
MODE PEMROGRAMAN 3-3. Penyiapan pengisian penuh berlaku atau tidak Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp.
Page 72
MODE PEMROGRAMAN 4. Cara memasukkan hari harga spesial Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 73
MODE PEMROGRAMAN 4-1. Cara mengubahnya menjadi hari Minggu Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 74
MODE PEMROGRAMAN 5. Penyiapan waktu awal harga spesial Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 75
MODE PEMROGRAMAN 6. Penyiapan waktu akhir harga spesial Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 76
MODE PEMROGRAMAN 7. Waktu siklus mesin pengering dengan harga reguler Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp.
Page 77
MODE PEMROGRAMAN 8. Waktu siklus mesin pengering dengan harga reguler Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp.
Page 78
MODE PEMROGRAMAN 9. Nilai koin 1 Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 79
MODE PEMROGRAMAN 10. Nilai koin 2 (Mempersiapkan untuk top off harga dan e-suds koin nadi) Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar.
Page 80
MODE PEMROGRAMAN 11. Waktu pengisian penuh Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 81
MODE PEMROGRAMAN 12. Volume bunyi alarm Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. atau Low Temp. sampai " "...
Page 82
MODE PEMROGRAMAN 13. Waktu untuk menyimpan koin (Digunakan hanya untuk tipe koin) Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start.
Page 83
MODE PEMROGRAMAN 14. Penyiapan tipe produk - tipe koin / kartu atau pengaturan OPL Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol High Temp. Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start.
Page 84
MODE PEMROGRAMAN MODE PEMROGRAMAN - MODE UJI uji diagnostik: " " (ditampilkan) Program ini telah ditambahkan untuk menguji mesin cuci dan mendeteksi kesalahan. Masuk ke mode uji Nama Data Tombol Tampilan Deskripsi 1. Masuk ke Masukkan kartu layanan (tipe kartu) mode pem- Alihkan saklar ke nyala/mati (tipe koin) rograman...
Page 85
MODE PEMROGRAMAN 2. Pengembalian ke pengaturan pabrik - EEPt Setelah pengembalian ke pengaturan pabrik, informasi mesin diubah ke nilai standar. Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display.
Page 86
MODE PEMROGRAMAN 3. Penyiapan waktu Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol Med Temp. atau Low Temp. sampai " “ muncul di layar. Tekan tombol Start. Layar akan memunculkan 2000 --> 0101 --> Sat --> 0000 secara bergantian berulang kali.
Page 87
MODE PEMROGRAMAN 4. Siklus gratis Siklus gratis seperti siklus ekstra yang diberikan kepada pelanggan ketika mesin cuci rusak dangkan pelanggan telah melakukan pembayaran untuk mencuci pakaian. Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Press the Med Temp. or the Low Temp. Button until appears in the display.
Page 88
MODE PEMROGRAMAN 5. Penghentian Siklus ■ Tipe koin Masuk ke mode pe- Tombol Tampilan nyiapan. Anda akan melihat LqC1 Tekan tombol Med Temp. atau Low Temp. sampai " " muncul di layar. Tekan tombol Start. Tekan tombol Med Temp. sampai muncul " "...
Page 89
MODE PEMROGRAMAN MODE PEMROGRAMAN - Mengumpulkan Mode Kumpulkan Data Informasi: CLCt (display) Pengering mengumpulkan data pemakaian sehingga pemiliknya bisa mengecek berbagai informasi seperti jumlah berbagai siklus digunakan, berapa kali kartu atau koin yang digunakan, dll. Memasuki mode pengumpulan Nama Data Tombol Tampilan Deskripsi...
Page 90
MODE PEMROGRAMAN ■ Daftar Data Mode Pengumpulan Singkatan Arti Deskripsi Itnr Interval Tanpa Operasi Itnr tidak tersedia pada mesin pengering. Ittb Interval Siklus Masalah Uang dimasukkan, tetapi tidak beroperasi. ItPd Interval Daya Mati Tidak ada uang, tetapi beroperasi. Interval Pembukaan Pintu Layanan Tanpa Jumlah Pembukaan Pintu Layanan Tanpa Itdd Wewenang...
Page 91
PEMELIHARAAN PEMELIHARAAN ■ Pembersihan secara teratur Membersihkan Filter Tiras Selalu bersihkan filter tiras setiap selesai siklus. PERINGATAN untuk mengurangi risiko kebakaran, sengatan listrik, atau cedera pada orang saat menggunakan mesin cuci, ikuti tindakan pencegahan dasar, termasuk yang berikut ini: • Cabut steker mesin pengering sebelum membersihkan untuk menghindari risiko sengatan listrik.
Page 92
Posisi susun Mesin Pengering Mesin Cuci Mesin Pengering RP1329AN7S FH069FDF Posisi susun RP1329A7S RP1329AN1 FH069FD2F RV1329C7P 2. Kit penggeser - Kit geser disediakan di pengering atas. - Kit geser mencakup braket geser (2), bantalan geser (4), sekrup (10), sekrup mesin (8).
Page 93
PETUNJUK PEMASANGAN MESIN SUSUN 4. Menyusun mesin - Angkat dan susun mesin pengering atas di atas mesin cuci bawah. - Atur bagian belakang mesin pengering atas dan bagian belakang mesin cuci bawah pada posisi yang sama. - Dorong mesin pengering atas yang cocok dengan braket geser & penyusunan agar bagian depan atas dan bawah menjadi sejajar.
Page 94
MODE KESALAHAN/PEMULIHAN KEGAGALAN DAYA/PENGATURAN STANDAR MESIN PENGERING MODE KESALAHAN ■ Arti Kode Kesalahan yang ditampilkan LED saat terjadinya masalah. Kode kesalahan mesin pengering Masalah Kemungkinan Penyebab Solusi Ditampilkan bila termistor terbuka atau men- Termistor harus diganti. galami korsleting Ditampilkan bila suhu termistor telah mening- Termistor harus diganti.
Page 95
13. Penggantian bola lampu, filter, atau komponen habis-pakai. 14. Aksesori dan perangkat lunak apa pun yang tidak disetujui atau ditentukan oleh LG termasuk, tetapi tidak terba- tas pada, penghitung jatuhan koin, mekanisme geser koin, brankas dan kunci koin, modul kartu debit dan kartu,...
Page 96
PT. LG Electronics Indonesia Gandaria 8 Office Tower Lt. 29 BC & 31 ABCD Jl. Sultan Iskandar Muda, Kebayoran Lama Utara - Kebayoran Lama, Jakarta Selatan - DKI Jakarta Raya, Indonesia TANDA PENDAFTARAN PETUNJUK PENGGUNAAN MANUAL DAN KARTU JAMINAN/GARANSI DALAM BAHASA INDONESIA BAGI PRODUK ELEKTRONIK...
