3. PRODUCT OVERVIEW

3.2 TECHNICAL SPECIFICATIONS

Identification
Communication backoffice
Communication Smart Meter
Backoffice protocol
Stand-by consumption
Operating temperature range
Operating humidity range
Operating air pressure range
Maximum mounting height socket
Advised mounting height socket
Mounting position
Function for ventilation according to IEC-61851
* The maximum charge capacity of the charge point depends on several factors. This includes; local rules & regulations,
the type of EV, the grid connection at your location and the electricity usage of your building.
**Contact NewMotion for changing charge capacity.
***Contact NewMotion for further information: +44 20 3868 1036 and press option 1.
**** Product is tested and certified for both Class I & Class II. Method of mounting dictates which class is applicable;
Mounted on wall = Class II, mounted on the metal pole with Protective Earth connection = Class I.
INSTALLATIEHANDLEIDING – P8
INSTRUCTION MANUAL – P8 | P8
RFID (NFC) Mifare 13.56 MHz
IEC 14443A
IEC 14443B
Plug & charge (through online portal)
GPRS 2G (minimal -80dBm Vodafone Partners)
Ethernet connection (DHCP, TCP 443, TCP80, TCP21)
GPRS 2/3/4G with mobile router***
Straight RJ12 (6P6C) wired CAT5 (max20m) - DSMR > 4.0
OCPP protocol
3-6W
-30°C to +40°C
5% to 95%
860 hPa to 1060 hPa
1.5 meter above ground
1 meter above ground
Vertical and upright postion only
Not supported
