3. PRODUCT OVERVIEW
3.2 TECHNICAL SPECIFICATIONS
Serial number format Home Advanced View
Maximum charge capacity
Standard configured charge capacity
Electric safety category
DC-fault current protection
Dimensions (H x W x D)
Weight
Standard colours
IEC-62262 IK code (robustness)
IEC-60529 IP code (protection class)
EN-50470 M-class
EN-50470 E-class
Certificates
kWh measurement
User interface

CONTINUED ON NEXT PAGE

INSTALLATIEHANDLEIDING – P7
INSTRUCTION MANUAL – P7 | P7
07 5 _ _ _ _ _
1-phase 32A (7,4 kW)*
3-phase 32A (22 kW)*
1-phase 16A (3,7kW)**
3-phase 16A (11kW)**
Class I & Class II ****
Built-in 6mA fault current protection
503.5 x 200 x 137 mm
± 4.2 kg
Rear side RAL 7031 (grey)
Front side RAL 9010 (white)
IK10
IP54 (for indoor and outdoor use)
M1
E2
IEC-61851-1
IEC-61851-22
EV-Ready & ZE-Ready
IEC-62262 -> IK10
IEC-60529 -> IP54
IEC-62955 -> 6mA DC-fault protection
MessEV & MessEG
MID certified (accuracy class B)
M&E certified
LED
LCD display
Proximity sensor-set
