Important: Retain these instructions
These instructions shall be used by trained service
personnel only.
If the equipment is used in a manner not
specified by these instructions, the protection provided by the
equipment may be impaired.
ConTenTS
1
Box Contents .................................................................1
2
Installation .....................................................................1
3
Disposal .........................................................................4
1
Box ConTenTS
Installation
instructions
printed on box
2
InSTallaTIon
Dimensions
1
Requirements
2
-5 °C
to
+50 °C
(+23 °F)
(+122 °F)
Protection
-30 °C
to
+100 °C
(-22 °F)
(+212 °F)
TB/TC/S Strap-on Temperature Sensor Installation Instructions TG201240 Issue 2, 18-Dec-2015.
Strap-on Temperature Sensor
TB/TC/S
22.2 mm
(0.87")
Ø 15 to 140 mm
42.2 mm
(1.66")
(0.59 to 5.51")
5 %RH
95 %RH
H O
2
:IP42 as per IEC 529
Installation Instructions
https://partners.trendcontrols.com
60 mm
(2.36")
67 mm
(2.64")
lagging
100 mm or
greater
TB/TC/S
>=10d
mixing
d
1
