Important: Retain these instructions
UNPACKING
INSTALLATION
1
Dimensions
2 m (6'6") cable
2
Requirements
measurement range
/-40
-40 °C to +50 °C
(-40 °F to +122 °F)
/40
-10 °C to +40 °C
(+14 °F to +104 °F)
/110
-10 °C to +110 °C
(+14 °F to +230 °F)
/160
-10 °C to +160 °C
(+14 °F to +320 °F)
T/PC PRT Contact Temperature Sensor Installation Instructions TG100508A Issue 5, 28/08/09
PRT Contact Temperature Sensor
57 mm (2.24")
2 m (6'6") max
Installation Instructions
T/PC Installation
Instructions TG100508
97 mm (3.82")
0 %RH
95 %RH
Protection
:IP67, NEMA6
-40 °C to +50 °C
(-40 °F to +122 °F)
T/PC
1
Advertisement
Table of Contents
Related Manuals for TREND T/PC
Summary of Contents for TREND T/PC
-
Page 1: Installation Instructions
(+14 °F to +230 °F) /160 -10 °C to +160 °C (+14 °F to +320 °F) 2 m (6’6”) max -40 °C to +50 °C (-40 °F to +122 °F) T/PC PRT Contact Temperature Sensor Installation Instructions TG100508A Issue 5, 28/08/09... - Page 2 Caution: This unit contains static sensitive devices. Suitable anti-static precautions should be taken throughtout the operation to prevent damage to the units. BS EN100015/ 1 Basic Specification: protection of electrostatic sensitive devices. T/PC PRT Contact Temperature Sensor Installation Instructions TG100508A Issue5, 28/08/09...
- Page 3 AUX+ (+24V). Replace Connector Replace Lid Note that IP67 (NEMA6) rating is only achieved if the sensor is correctly installed with cable or conduit connection fully tightened. T/PC PRT Contact Temperature Sensor Installation Instructions TG100508A Issue 5, 28/08/09...
- Page 4 Division of Honeywell Technologies Sàrl, Z.A. La Pièce, 16, 1180 Rolle, Switzerland by its Authorized Representative. Trend Control Systems Limited reserves the right to revise this publication from time to time and make changes to the content hereof without obligation to notify any person of such revisions or changes.
