Summary of Contents for Martin M6
- Page 1 Martin M6™ Safety and Installation Guide...
-
Page 2: Table Of Contents
The Martin logo, the Martin name and all other trademarks in this document pertaining to services or products by Martin Professional A/S or its affiliates and subsidiaries are trademarks owned or licensed by Martin Professional A/S or its affiliates or subsidiaries. -
Page 3: Dimensions
Dimensions All dimensions are in millimeters © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide... - Page 4 © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide...
-
Page 5: Introduction
Introduction Thank you for purchasing the Martin M6™ Lighting Control System. The system offers a powerful lighting controller with all the features of the Martin M-Series™ with enhanced user interfaces, hardware controls and processing power. Please read this "Safety and Installation Guide" carefully. Visit the Martin™ website www.martin.com... -
Page 6: Technical Support
Technical Support Martin™ operates a complete network of support services around the world. Experts in programming and operating Martin™ control systems can be found in every timezone and every continent. Contact by email The best way to get questions answered or to report a problem is to email us @ controllersupport@martin.dk... -
Page 7: Safety Information
If you have questions about how to operate the product safely, please contact your Martin™ supplier or call the Martin™ 24-hour service hotline on +45 8740 0000. -
Page 8: Included Items
The software for the M6™ is available from the support website www.martin.com/controllersupport Please check periodically for new releases that may add new functionality or improvements. It is recommended to update to the latest release software before using the M6™ for the first time. Additional touchscreens The M6™... -
Page 9: Setup And Assembly
Do not transport the M6™ without the factory-provided flightcase or another professionally designed case solution. Only transport the flightcase laying flat with the factory label facing up and secure the M6™ safely. The flightcase must be lifted by two people. Do not lift it alone. -
Page 10: Power Connections
Power Connections The Martin M6™ accepts AC mains power at 100-240V 50/60Hz. Do not connect it to power outside this range. Damage resulting from incorrect connection is not covered under warranty. Only use a Neutrik Powercon NAC3FCA cable connector for power input. -
Page 11: Connections
These connections are suitable for Operating System installations. USB 2.0 (black) A USB 2.0 connector is placed next to each touchscreen surface. Do not exceed 500ma. These connections are NOT suitable for Operating System installations. © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide... -
Page 12: Back Panel
Back panel AC MAINS Input 1x Neutrik Powercon NAC3FCA © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide... - Page 13 RJ45 Ethercon Gigabit Network Remote Network RJ45 Ethercon Gigabit Network USB-A 2.0 (max 500ma) Screen Power 12V Power outlet for Martin M-Series BriteTouch screen only Display 1+2 DisplayPort Output © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide...
-
Page 14: Maintenance
Maintenance The Martin M6™ is designed as a rugged, roadworthy device. Occasional cleaning is the only service required of the user. For any other service-related concerns, please contact your Martin™ dealer or visit www.martin.com. Any service not described in this document must be carried out by a qualified Martin technician. -
Page 15: Specifications
Individual fade in/fade out times for all playbacks Manual override available at all times Live 0-1000% override of global cue timings Live programmer timing (“Sneak”) Cuelists can be executed in tracking or non-tracking mode © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide... - Page 16 13x Rotary Encoders 4x Linear Encoders with LED feedback Processor Hardware Industrial motherboard with Intel Core i7 Quad-Core processor 16 GB RAM 64 GB SSD storage drive Dedicated graphics processor © 2013 Martin Professional A/S Martin M6 Safety and Installation Guide...
- Page 17 Martin M6™ Screen Mounting Kit: P/N 91613109 Martin M6™ Flightcase (Replacement): P/N 91535080 Ordering Information Martin M6™ Console, 4 DMX Universes, with Flightcase: P/N 90737050 Martin M6™ 8 DMX Universes Package: P/N 39808034 Martin M6™ 16 DMX Universes Package: P/N 39808035 Martin M6™...
