Summary of Contents for mastro 65 Series
- Page 1 Mastro mbH ¤ Hüserstraße 53 +49 (0) 23 81/ 973 71– 0 59075 Hamm / Germany +49 (0) 23 81/ 973 71– 88 w w w . m a s t r o s h o p . c o m...
- Page 2 Cod. 252.168.11 FRY – TOP GAS - SERIES 65 MOD. 65-40 FTG 65-40 FTRG 65-40 FTGS 65-70 FTG 65-70 FTRG 65-70 FTGS 65-70 FTRRG 65-40 FTG – CR 65-40 FTRG – CR 65-70 FTG – CR 65-70 FTRG – CR 65-70 FTRRG –...
-
Page 3: Table Of Contents
INDEX Warnings Compliance with “EEC” Directives for gas appliances Installation diagrams Technical data table / Fry-Top Gas characteristics Instructions for the qualified installer Appliance installation Laws, technical regulations and general rules Discharge of fumes for type ”A” appliances Checking for gas leaks Maintenance Conversion for use with a different type of gas / Fry-Top Changing spare parts... -
Page 4: Warnings
THIS APPLIANCE HAS BEEN MADE FOR COOKING FOOD AND MUST ONLY BE USED BY PROFESSIONALLY SKILLED PERSONNEL IN THE WAY DESCRIBED IN THIS INSTRUCTION MANUAL. WARNINGS • Read this handbook through carefully as it provides important information for safe installation, use and maintenance. •... -
Page 5: Gas Characteristics
TECHNICAL DATA TABLE FRY -TOP TOTAL GAS DIAMETER OF NOZZLES IN BURNERS TOTAL CONSUMPTION HUNDREDTHS OF A MILLIMETRE X POWER POWER NATURAL NATURAL MODEL G30 – G31 G30 – G31 No. x kW kg/h 30mbar 37mbar m³/h 20 mbar 65-40 FTG 65-40 FTRG 65-40 FTG-CR 1 x 5.7... -
Page 6: Instructions For The Qualified Installer
INSTRUCTIONS FOR THE QUALIFIED INSTALLER APPLIANCE INSTALLATION • Take the unit out of the packaging. Check that it is in good condition. If in doubt, do not use it and contact professionally qualified personnel. Always place the unit under an aspiration hood. After installation, it will need to be levelled by using the feet. -
Page 7: Checking For Gas Leaks
CHECKING FOR GAS LEAKS Once installed, check there are no gas leaks from the pipe joints by using a soapy water solution. • You will know if there are leaks by the foamy bubbles that form. Never use bare flames to check for leaks. -
Page 8: Changing Spare Parts
• Regulating the minimum flame: remove the cock knob (8), use a screwdriver to turn the cock (6) adjustment screw (7) until you get the minimum flame required. • Adjustment of minimum (Fig.2): (machines set up to use LPG and changed over to natural gas) Remove the knob (8) from the cock and use a screwdriver on the adjustment screw (7) to tighten it all the way down. -
Page 9: Turning The Normal Fry-Top Pilot On
INSTRUCTIONS FOR THE USER TURNING THE NORMAL FRY-TOP PILOT ON Push the knob (8) and turn it counter clockwise round to the pilot position (spark symbol). Simultaneously press the piezoelectric lighter knob and button and the pilot burner will light. Keep the knob pressed for 10 to 15 seconds and then let it go. - Page 10 INSTRUCTIONS FOR USE OF THE THERMOSTATIC MULTIGAS COCK PEL 25 ST FOR THE CHROME FRY-TOP To light the burner, connected to the cock, push the knob until it will go no further and then turn it in the direction of the arrow, round to the “PILOT”...
-
Page 11: Maintenance, Cleaning And Care
MAINTENANCE, CLEANING AND CARE Always disconnect the appliance from the gas supply before embarking on any maintenance work. FRY – TOP MAINTENANCE There is very little maintenance to do thanks to the correct way the appliances have been made. However, we do advise having the systems checked by qualified personnel at least twice a year. -
Page 12: Exploded Functional Parts Table
EXPLODED FUNCTIONAL PARTS TABLES 10.1 Exploded tables of normal Fry-Tops Mod. 65-40 FTG 65-40 FTRG FIG. 1 65-40 FTGS 65-70 FTG 65-70 FTRG 65-70 FTGS 65-70 FTRRG FIG. 3 FIG. 2 PILOTA CHIUSO VEILLEUSE FERME' MINIMUM MAXIMUM GESCHLOSSEM ZÜNDFLAMME HOOG LAAG PILOT CLOSED... -
Page 13: Exploded Tables Of Chromed Fry-Tops
10.2 EXPLODED TABLES OF CHROMED FRY-TOPS FIG. 2 BILD 2 MOD. 65-40 FTG-CR 65-40 FTRG-CR 65-70 FTG-CR 65-70 FTRG 65-70 FTRRG-CR 10 11 7 6 19 FIG. 5 BILD 5 POSIZIONE CHIUSO (SPEGNIMENTO) FERME' GESCHLOSSEM. CLOSED. DICHT POSIZIONE PILOTA (ACCENSIONE) VEILLEUSE.
