Summary of Contents for Stahl Hotronix Dual Air Fusion

  • Page 1 Dual Air Fusion ™ O P E R A T O R’ S M A N U A L...

  • Page 2: Safety Instructions

    S a f e t y I n s t r u c t i o n s When using your heat press, basic precautions should always be followed, including the following: Read all instructions. Use heat press only for its intended use. To reduce the risk of electric shock, do not immerse the heat press in water or other liquids.

  • Page 3: Table Of Contents

    HOTRONIX DUAL AIR FUSION ® ™ Ta b l e o f C o n t e n t s Safety Instructions Machine View Touch Screen Guide Operating Instructions 6-18 Connecting the System Start Up/Shut Down Print Screen 8-10 Passwords Setup Menu 11-17 Preset Setup...

  • Page 4: Machine View

    HOTRONIX DUAL AIR FUSION ® ™ M a c h i n e V i e w Print Buttons Casters Alignment Lasers (Optional) Bellow Circuit Breakers & IEC Inlet Air Connect Air Hose Foot Pedal Power Cord ON/OFF Switch Quick Release Button Touch Screen Upper Platen Lower Platen A...

  • Page 5: Touch Screen Guide

    HOTRONIX DUAL AIR FUSION ® ™ To u c h S c r e e n G u i d e Navigation Most screens have a Cancel or Back button to close the current screen without saving any changes and will return the user to the previous screen. (Fig.1) Some screens may present a list of items.

  • Page 6: Operating Instructions

    HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s The Hotronix Dual Air Fusion ® ™ Operating Instructions are designed with the user in mind. Carefully read and follow the step-by-step instructions for best results.

  • Page 7: Start Up/Shut Down

    HOTRONIX DUAL AIR FUSION ® ™ Start Up/ Shut Down To start your Dual Air Fusion ™ The power switch is located on the top of the control housing. (2.1) During the startup, a splash screen is shown for approximately 3 seconds.

  • Page 8: Print Screen

    HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s Print Screen start up has completed. This screen provides all the printing functions. Presets Saved Presets are displayed at the top of the Print Screen.
  • Page 9 HOTRONIX DUAL AIR FUSION ® ™ Print Screen Cont. Target Settings Cont. To change your Pressure Settings, press the Target Pressure display and a pop up menu will be displayed. Press the down or up arrows to decrease or increase the pressure (Press and hold to change values faster).

  • Page 10: Passwords

    HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s Print Screen Cont. Auto Shuttle Mode With Auto Shuttle Mode enabled, your Dual Air Fusion ™...

  • Page 11: Setup Menu

    HOTRONIX DUAL AIR FUSION ® ™ S e t u p M e n u Preset Setup After your password is entered in the setup menu, press the Preset Setup icon. (5.1). This option will allow you to edit, delete, and create new Presets.
  • Page 12 HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s Preset Setup Cont. To Create a New Preset (Continued): Note: A DELETE button will appear after saving if you do not want to save.

  • Page 13: Date & Time Setup

    HOTRONIX DUAL AIR FUSION ® ™ S e t u p M e n u Date & Time Setup The Date and Time Setup feature allows you to program the Month, Day, Year, Hour and Minute (displayed in the lower right corner of the Print Screen). To set the Date and Time, press the Date &...

  • Page 14: Auto On And Off Setup

    HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s Auto On and Off Setup of the week. In the Setup Menu, Select the Auto On/Off Button.

  • Page 15: Passwords Setup

    HOTRONIX DUAL AIR FUSION ® ™ S e t u p M e n u Passwords Setup (Manager Level Only) When logged in at a “Manager Level”, Passwords may be changed In the Setup menu. This will allow you to control who can access additional features in the Setup menu such as Passwords, Language, System, and Laser Setup.

  • Page 16: Language Setup

    HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s Language Setup (Manager Level Only) When logged in at a “Manager Level”, the display Language may be changed in the Setup menu. Choose from eight languages: English, Deutsch, Espanol, Francais, Italiano, Japanese, Pyccko, and Chinese.

  • Page 17: System Setup

    HOTRONIX DUAL AIR FUSION ® ™ S e t u p M e n u System Setup (Manager Level Only) When logged in at the “Manager Level”, system functions such as Power Save Status, Auto Shuttle, Foot Switch, and Key Touch Frequency can be turned on, off, or adjusted in the Setup menu.

  • Page 18: Prepare To Print

    HOTRONIX DUAL AIR FUSION ® ™ O p e r a t i n g I n s t r u c t i o n s Prepare to Print To begin Printing/Pressing, start by verifying that you have the proper settings selected in the Print Screen: (13.1) Do you have the correct preset selected? Note: You may also manually adjust your desired Time, Temperature and Pressure settings (refer to Target Settings on pg 8-9).

  • Page 19: Replacing Parts

    HOTRONIX DUAL AIR FUSION ® ™ P a r t s R e p l a c e m e n t L i s t Item # Part Name Part # Qty. Control Housing 1-2197-1 Switch On/Off Lighted 1-2087 Quick Release Button 1-2270 Switch, Print, Canada...
  • Page 20 HOTRONIX DUAL AIR FUSION ® ™ P a r t s L o c a t i o n G u i d e S E R V I C E H O T L I N E : 8 0 0 . 7 2 7 . 8 5 2 0...
  • Page 21 HOTRONIX DUAL AIR FUSION ® ™ H O T R O N I X . C O M...

  • Page 22: Electrical Schematic

    HOTRONIX DUAL AIR FUSION ® ™ E l e c t r i c a l S c h e m a t i c Control Board Out to Left Print Switch 220V Version Out to Right Print Switch Triac Out to Air Regulator White Black...

  • Page 23: Contact

    C o n t a c t u s ® Stahls’ Hotronix One Industrial Park Carmichaels, PA 15320 U.S.A. Technical Support 800 . 727 . 8520 Monday - Friday 8am - 7pm EST Customer Service 800 . 727 . 8520 Monday - Friday 8am - 5pm EST Replacement Parts...
  • Page 24 Proudly made in the U.S.A. One Industrial Park . Carmichaels, PA 15320, U.S.A. Tech Support - Customer Service - Replacement Parts: 800 . 727 . 8520 Web: Hotronix.com...
