- Page 1 SHBW10000 ABUS Z-Wave 4in1 Sensor Important information and FAQs about this product and other products can be found on the website www.abus.com Version 1.3 Original operating instructions in English. Keep for future use!
- Page 2 ABUS Security Center is limited to the purchase price of the product.
- Page 3 Please ensure that the package also contains the DSK (Z-Wave Device Specific Key) – Card. This card shows the DSK of your ABUS Z-Wave Multisensor. Please keep it in a safe place. Any S2 (Security 2) certified Z-Wave Gateway will require this DSK to program your sensor.
- Page 4 English Information on handling batteries Make sure that batteries are kept away from small children. Children may put batteries in their mouths and swallow them. This can cause serious harm to their health. If this happens, consult a doctor immediately. ...
-
Page 5: Table Of Contents
English Table of contents Product introduction ......................... 6 1.1. Scope of Delivery........................6 1.2. Device features ........................6 1.3. Operating principle ........................6 1.4. Performance Features ......................7 1.5. Use in systems of different manufacturers ................7 Overview of functions ........................8 2.1. -
Page 6: Product Introduction
For inclusion / exclusion of the detector in a gateway, factory reset Mounting Plate For wall-mounting 1.3. Operating principle The SHBW10000 was developed for use in home automation systems that use the Z-Wave wireless standard. The multisensor has the following sensors: ... -
Page 7: Performance Features
English 1.4. Performance Features The ABUS Z-Wave SHBW10000...: …is a battery-operated 4in1-Multisensor …is Z-Wave PLUS compatible & certified …supports the Z-Wave S2 Standard (Security 2) …detects/measures motion/PIR, brightness, temperature and humidity …has a recognition range of max. 5 meters ... -
Page 8: Overview Of Functions
English 2. Overview of functions 2.1. Inclusion / Add Device Click the + (Add) button in your Z-Wave App and follow the further instructions Press the Button on the device once. The App will show if the Add device process was successful. -
Page 9: Mounting & Installation
English 2.2. Mounting & Installation Test the release behaviour at the desired mounting position in advance. Installation site: Optimum detection at an installation height of 180-240 Remove the safety strip from the battery compartment. Fix the Mounting plate on the wall by screws (recommended) or adhesive tape. -
Page 10: Exclusion / Remove Device
English 2.3. Exclusion / Remove Device Click the - (Remove) button in your Z-Wave App and follow the further instructions Press the Button on the device once. The App will show if the Remove device process was successful. Repeat the exclusion process if it was not successful. 2.4. -
Page 11: Wake-Up
English 2.5. Wake-up If included: The device sends a wake up notification command to the node devices which are connected by a wake up command. The LED will light up when information is received, and will go out when there is no exchange for 10 seconds. If not included: nothing 3. -
Page 12: Overview Configuration Parameter
English 3.2. Overview Configuration Parameter Z-Wave products can be used in the network immediately after inclusion. Through configuration settings, however, the behaviour of the device can be adapted even better to the requirements of the application and additional functions can be activated. Para- Byte- Default-Value... - Page 13 English The interval time of the humidity report. The value 0 disables the report. Adjustable from 0 - 2678400 in seconds Humidity report 7200 The value is always rounded up to the full Time minute. (e.g. 62 seconds -> value is rounded up to 120 seconds) (Hexadecimal: 0x00 –...
-
Page 14: Command Classes
English The threshold value serves as an additional condition for the time-based report. Brightness If the threshold value was not exceeded, the report time-based report is not sent. Threshold Adjustable from 1 - 65528 in Lux (Hexadecimal: 0x01 – 0xFFF8) The threshold value serves as an additional condition for the time-based report. -
Page 15: Technical Specifications
English 4. Technical Specifications Parameters Unit SHBW10000 Dimensions 51 x 51 x 68 Weight Operating Temperature °C 0 – 40 Max. Humidity IP Class Radio frequency 868,42 (Z-Wave PLUS, Europe) Modulation FSK (BFSK/GFSK) Transmission power < 4,5 Power supply 3 V DC...
