Connex
ProBP
®
A. Intended Use
1. The Connex ProBP 3400 can measure:
a. Systolic and diastolic blood pressure (Pediatrics and Adults)
b. Pulse rate
c. MAP (Mean Arterial Pressure) Display of this value is optional.
2.
The device is intended to be used by clinicians and medically qualified personnel. It is available for sale
only upon the order of a physician or licensed health care provider.
B. Battery
1. The device is powered by a lithium-ion rechargeable battery.
2. Prior to initial use, install and charge the battery for 6 hours.
3. A dead battery may result if the ProBP 3400 is left uncharged or unused for a long period of a time. If
this occurs, charge the battery for 6 hours by connecting the ProBP 3400 to an external power source.
C. Front Panel Buttons/Controls
Button
3400 Digital Blood Pressure Device Outline
™
Function
Power
Blood Pressure Start/Stop
Return Button
Select Button
Description
Turns device On or Off
Initiates or cancels a blood pressure cycle
Returns the user to the previous screen
Accepts the current option
1
Connex ProBP 3400 Trainer Outline
MC 8358
09/2011
Advertisement
Table of Contents
Related Manuals for Welch Allyn Connex ProBP 3400
Summary of Contents for Welch Allyn Connex ProBP 3400
- Page 1 3400 Digital Blood Pressure Device Outline ® ™ A. Intended Use 1. The Connex ProBP 3400 can measure: a. Systolic and diastolic blood pressure (Pediatrics and Adults) b. Pulse rate c. MAP (Mean Arterial Pressure) Display of this value is optional.
- Page 2 It should fit comfortably to allow no more than 1 to 2 fingers of space between the cuff and the arm. During the BP measurement cycle, the patient should not move the extremity and should remain quiet. 2. To initiate blood pressure measurements: Connex ProBP 3400 Trainer Outline MC 8358 09/2011...
- Page 3 Using Cavi-Wipes or Sani-Cloth Plus, wipe the surface of the device to remove all debris. ii. Allow the device surface to dry for a minimum of 10 minutes before using the monitor. c. 70% isopropyl alcohol Connex ProBP 3400 Trainer Outline MC 8358 09/2011...
- Page 4 Wipe the device with a clean cloth slightly dampened with a 10% bleach and 90% water solution. ii. Rinse with a clean cloth slightly dampened with clean water. iii. Allow the device surface to dry for a minimum of 10 minutes before using the device. Connex ProBP 3400 Trainer Outline MC 8358 09/2011...
