EUTHANEX SMARTBOX PRODIGY EA-3300TS Manual page 7

4. Place the Euthanex Lid on the cage. To properly make the connection, pull back the coupler and slide
it over the male stem. The coupler will snap back into place and secure the connection. The system is
ready for operation.
5. Attach the heated regulator to the CO
tank threads before attaching regulator. Use a wrench to tighten the mounted regulator. Set for 20
PSI out.
We recommend setting the incoming pressure to 20 PSI but do not exceed 35 PSI. The unit will
work on low incoming pressure but may result in the inability to achieve higher output flow
rates.
Note: The EA‐550 Electrically Heated Regulator is recommended to operate the system. Using a non‐
heated regulator will likely result in frozen CO
Setup is now complete.
The image cannot be display ed. Your computer may not hav e enough memory to open the image, or the image may hav e been corrupted. Restart y our computer, and then open the file again. If the red x still appears, y ou may hav e to delete the image and then insert it again.
Set for 20 PSI out.
tank. It is recommended that Teflon tape be used on the CO
2
Mounted Heated Regulator
lines.
2
7
2
