Le Preamp Model Channel A Channel B Cold Fusion Hot Fusion
Le Lead PC 11
Le Bass PC 16
Please note that bypassing a preamp does not send any PC message. The default MIDI channel is
OMNI and the Multi-channel mode is ON.

7.2 MIDI programming

It is possible for the advanced user to change the MIDI configuration of Le Preamp, thanks to the
setup configurator that you can start simply by pressing A while powering on Le Preamp. The
configurator uses your Le Preamp LEDs and tube window color to guide you through the process.
There are 7 pages on the menu and therefore 7 tube window colors.
Page # 1
MIDI
Function
Monitor
Color White
You can navigate through the pages using the A switch, and you enter a page using the B
switch. Once you entered a page you cannot go out, you will have to restart the configurator to
access another page. On each page, a modified parameter is instantaneously stored. The storing
process is validated by a fast flashing of the product's LEDs.

7.3 MIDI Monitor

The MIDI monitor uses the LEDs to display the type of message and the channel used by the emitter.
It is a powerful tool to help you debug a MIDI configuration issue. If you find that the MIDI behavior of
Le Preamp is not what you expected, this short guide will help you fix the issue.
Flash
Meaning
Color
No MIDI Message
No Light
received
MIDI message is not a
Red
PC
MIDI message not on
Yellow
the active MIDI channel
MIDI message on the
Green
active MIDI channel
http://wiki.two-notes.com/
PC 12
PC 17
2 3
MIDI MIDI
Learn Channel
Green Yellow
What to do?
Control the connection between the MIDI output of your MIDI
controller and the MIDI input of Le Preamp. Control and
eventually change the MIDI cable. Make sure the MIDI controller
is configured to send MIDI messages.
Make sure your MIDI controller is sending PC messages.
Set your MIDI controller to the same MIDI channel as your
preamp, or set the preamp to OMNI.
Configure your MIDI controller PC so it matches the default Le
Preamp MIDI mapping. Or use the MIDI Learn function on Le
Preamp so the MIDI PC you send triggers one of its functions.
PC 13 PC 14
PC 18 PC 19
4 5
PC Multi-channel
Number mode
Red Purple
6 7
Factory Firmware
Reset Version
Blue Turquoise
