- Page 1 AC-MX82-AUHD/AC-MX82-AUHD-RM User Manual AC-MX82-AUHD preliminary AC-MX82-AUHD-RM (RM ~ Rack Mountable Version) Page 1...
-
Page 2: Easy To Use
• Perfect AVR Bypass deliver 18Gbps to Display and In The Box: uncompressed audio to AVR • Advanced EDID Management • AC-MX82-AUHD or AC-MX82-AUHD-RM • IR, RS-232 and LAN Control Options Matrix Switch • Digital Toslink Out (7CH PCM, DD, DD+, DTS, DTS-MA) •... - Page 3 AC-MX82-AUHD/AC-MX82-AUHD-RM Page 3...
- Page 4 AC-MX82-AUHD/AC-MX82-AUHD-RM Page 4...
-
Page 5: Device Overview
AC-MX82-AUHD/AC-MX82-AUHD-RM Device Overview: • Definition - Matrix switches provide the ability to route any input to any output or to multiple outputs at any time. Depending on the model, a matrix switch can route HD, UHD or AUHD content in this manner. -
Page 6: Connection Diagram
AC-MX82-AUHD/AC-MX82-AUHD-RM CONNECTION DIAGRAM AVR BYPASS Page 6... -
Page 7: Factory Reset
AC-MX82-AUHD/AC-MX82-AUHD-RM Auto Switching Logic: When the AC-MX82-AUHD is in "Auto" mode the logic is to switch to the most recently plugged in device based on a Hot Plug Event. You can have either HDMI OUTPUT set on auto individually or they can both be on together. -
Page 8: Edid Management
All LEDs flash one time. NOTE 2: We have a video available online or upon request if desired. Contact us or request at support.avproedge.com Use the chart below to pick your EDID: Page 8... -
Page 9: Web Interface
AC-MX82-AUHD/AC-MX82-AUHD-RM Web Interface Default IP = 192.168.001.239 Sense Switch: Use this area to route inputs to outputs HDMI Auto Switch: Use this to turn the HDMI Auto Switch Feature ON/OFF per output. Video Scaler Mode: This will set the scaler mode for OUTPUT 1, the options are: •... -
Page 10: Audio Status
AC-MX82-AUHD/AC-MX82-AUHD-RM Audio Status: Enable or Disable extracted Audio, the options are: • ON = Extracted audio ports are ON (Default) • OFF= Extracted audio ports are muted. Audio Binding: Bind the audio to a specific OUTPUT. The audio will always follow one output, this means the audio switches with the video of the output you designate, the options are: •... -
Page 11: Web Interface: System Settings
AC-MX82-AUHD/AC-MX82-AUHD-RM 1080P_2CH 1080P_3D_2CH_HDR 1080P_6CH 1080P_3D_6CH_HDR 1080P_8CH 1080P_3D_8CH_HDR 1080P_3D_2CH 4K30HZ_3D_2CH_HDR 1080P_3D_6CH 4K30HZ_3D_6CH_HDR 1080P_3D_8CH 4K30HZ_3D_8CH_HDR 4K30HZ_3D_2CH 4K60HzY420_3D_2CH_HDR 4K30HZ_3D_6CH 4K60HzY420_3D_6CH_HDR 4K30HZ_3D_8CH 4K60HzY420_3D_8CH_HDR 4K60HzY420_3D_2CH 4K60HZ_3D_2CH_HDR 4K60HzY420_3D_6CH 4K60HZ_3D_6CH_HDR 4K60HzY420_3D_8CH 4K60HZ_3D_8CH_HDR 4K60HZ_3D_2CH User EDID 1 4K60HZ_3D_6CH User EDID 2 User EDID 3 4K60HZ_3D_8CH Copy from Out1... - Page 12 We recommend using either the MyUART (RS-232 - free) or Hercules (TCP/IP - free) apps as they are very easy to use for sending commands to the machine. MyUART download available on AVProEdge.com/Drivers For TCP/IP control commands use Telnet Port 23.
- Page 13 AC-MX82-AUHD/AC-MX82-AUHD-RM Page 13...
-
Page 14: Rs-232 Wiring Diagram
AC-MX82-AUHD/AC-MX82-AUHD-RM RS-232 Wiring Diagram: Page 14... -
Page 15: Maintenance
AC-MX82-AUHD/AC-MX82-AUHD-RM Maintenance To ensure reliable operation of this product as well as protecting the safety of any person using or handling this device while powered, please observe the following instructions. • Use the power supplies provided. If an alternate supply is required, check voltage, polarity and that it has sufficient power to supply the device it is connected to. -
Page 16: Warranty
Warranty If your product does not work properly because of a defect in materials or workmanship, AVProEdge (referred to as “the warrantor”) will, for the length of the period indicated as below, (Parts/Labor (10) Years), which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. -
Page 17: Troubleshooting
AC-MX82-AUHD/AC-MX82-AUHD-RM Copied from MX42 - REVIEW Troubleshooting • Verify Power - The LEDs on the front of the matrix should be lit up when power is applied. Check power supply connections to device and power • Verify Connections - Check all cables are properly connected •... - Page 18 AC-MX82-AUHD/AC-MX82-AUHD-RM _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ Page 18...
- Page 19 AC-MX82-AUHD/AC-MX82-AUHD-RM _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ Page 19...
- Page 20 AC-MX82-AUHD/AC-MX82-AUHD-RM Thank you for choosing AVProEdge! Please contact us with any questions. We are happy to be of service! A V P r oE d g e 2 2 2 2 E 5 2 n d S t N ~ S i o u x F a l l s , S D 5 7 1 0 4 1 - 8 7 7 - 8 8 6 - 5 1 1 2 ~ 6 0 5 - 2 7 4 - 6 0 5 5 s u p p o r t @ a v p r o e d g e .
