FIELD ADJUSTMENT GUIDE
Tillage
Short Disk
Date: October 6, 2016
Document #
TLUS120C-0001A
Models Affected:SD2600, SD3000, SD3300
General Information
Proper servicing and adjustment is key to the long life of all farm equipment. With careful and systematic
inspection of equipment, costly maintenance, time and repair can be avoided. The following information
will assist with recommended servicing and adjustments:
48687
1 of 5
Document
#TLUS120C-0001A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GREAT PLAINS Short Disk SD2600
Summary of Contents for GREAT PLAINS Short Disk SD2600
- Page 1 FIELD ADJUSTMENT GUIDE Tillage Short Disk Date: October 6, 2016 Document # TLUS120C-0001A Models Affected:SD2600, SD3000, SD3300 General Information Proper servicing and adjustment is key to the long life of all farm equipment. With careful and systematic inspection of equipment, costly maintenance, time and repair can be avoided. The following information will assist with recommended servicing and adjustments: 48687 1 of 5...
- Page 2 Ensure that the safety lights and chain are hooked up. Great Plains hydraulic hoses have colored coded han- dle grips to help hook up hoses to the tractor remotes. Hoses with the same color use the same remote.
- Page 3 Hydraulic Leveling Fore and Aft: Fore/Aft leveling in the field should be done with the hydraulic level (if equipped), otherwise use the hitch turnbuckle for adjustment. 1) With the hitch turnbuckle set, the fore/aft can be adjusted hydraulically to compensate for differing field conditions.
- Page 4 (Old) Disc Scraper Adjustment: 3/8 inch (9.5 mm) Prior to first use, and periodically thereafter, inspect all gap min. disc scrapers for proper gap and adjust as needed. Reverse scraper blades when the specific adjustment is no longer possible. Replace the scrapers when 1/8 inch either side can no longer be adjusted to the proper (3.2 mm)
- Page 5 Rolling Basket Adjustment (Optional): The seedbed conditioner basket is designed to firm/ consolidate the soil and is not recommended for work- ing in wet conditions. 1) Springs (10) are factory set at: Model # Spring Length SD2600 14.88 inches (378 mm) SD3000 14.75 inches (375 mm) SD3300...
