SGS SSB400 Owner's Manual page 6

OPERATING AND MAINTAINING
1. All parts processed must be free of oil, grease and moisture. Make sure
parts are dry before putting into the cabinet for cleaning.
2. Set air pressure to 80 psi. For light gauge steel, aluminum, and other
more delicate parts, start at lower pressure and gradually increase the
pressure until the desired finish is achieved.
Warning: Do not connect to high pressure bottled gas.
3. Direct gun at parts at 45-60 degree angle with ricochet towards the back
of the cabinet. Hold gun approximately 6 inches form parts being blasted.
Warning: Gun must always be pointed away from the operator and towards
items being processed. Never blast with any of the cabinet doors open.
4. Media should be of good quality and dry. Moisture will cause the media
not to flow and will clog the metering valve and hopper.
5. After 10-12 hours of blasting time, the nozzle should be checked. If it
shows uneven wear it should be turned 1/4 turn every 10 hours of use.
6. Replace nozzle if it's measured 1/16 over its original size or if it shows
uneven wear. Adjust as needed for different media and conditions.
A properly working gun will pull 15-17 inches of mercury on manometer.
7. Clean dust from dust collector and clean filter as needed.
8. Air line should be more than 8mm (0.3"). All hoses should be rated for
125 psi (8.6 bar). An isolation valve should be installed.
9. Electric extension cords should be three wire grounded (wire size can
not be smaller than 3x1.5mm2 ).
10. Before starting inspect fittings and hoses for damage and water.
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
EC Declaration of Conformity
This is an important document and should be retained
MANUFACTURER'S NAME: SGS Engineering (UK) Ltd
SHOT BLASTER CABINET
TYPE OF EQUIPMENT:
SSB400
PART NUMBER:
APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:
2014/35/EU Low Voltage Directive
2014/30/EU EMC Directive
2012/19/EU WEEE Directive
2011/65/EU RoHS Directive
I, the undersigned, hereby declare that the equipment specified above
conforms to the above European Communities Directive(s) and
Standard(s).
PLACE:
Derby, UK
DATE:
24th NOV 2018
SGS Engineering (UK) Ltd
West Side Park
Raynesway
Derby, DE21 7AZ
(Signature)
Robert Wyatt
Company Secretary
