SAT404
COIL NAILER
OWNER'S MANUAL
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAT404 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SGS SAT404

  • Page 1 SAT404 COIL NAILER OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
  • Page 2: Specification

    SPECIFICATION SAFETY INSTRUCTIONS 1. Read and understand tool labels and manual. Failure to follow warnings TOOL MODEL SAT404 could result in DEATH or SERIOUS INJURY. MAXIMUM OPERATING PRESSURE 115 PSI 2. Operator and others in work area MUST wear safety glasses.
  • Page 3: Safety Mechanism

    The tool must not cycle. Never use the tool if a cycle occurs. Hold the tool clear of the work-piece. The WCE should return to its original down position. Pull the trigger. The tool must not cycle. Never use the tool if a cycle occurs. WWW.SGS-ENGINEERING.COM PAGE 4 PAGE 5...
  • Page 4: Operating The Tool

    CLEAN THE TOOL. VAPORS IN THE TOOL WILL IGNITE AND CAUSE THE TOOL TO EXPLODE. Remove tar build up with kerosene #2 fuel oil or fuel. Dry off tool completely before use. DO NOT SOAK tool with cleaning solutions or damage may occur. WWW.SGS-ENGINEERING.COM PAGE 6 PAGE 7...
  • Page 5: Parts Diagram

    PARTS DIAGRAM PARTS LIST WWW.SGS-ENGINEERING.COM PAGE 8 PAGE 9...
  • Page 6: Troubleshooting

    Verify fasteners of correct size. frequently. Damaged fasteners. Replace fasteners. Magazine or nose screw Tighten screws. loose. Magazine is dirty. Clean screws. Driver is worn or damaged. Install Driver maintenance kit. Other Contact SGS Engineering. WWW.SGS-ENGINEERING.COM PAGE 10 PAGE 11...
  • Page 7 SGS ENGINEERING IS COMMITTED TO DESIGNING, MANUFACTURING, AND MARKETING PRODUCTS THAT MEET OR EXCEED THE NEEDS OF THE CUSTOMERS WE SERVE. SGS ENGINEERING CAN SUPPLY A LETTER OF INCORPORATION OR A DECLARATION OF CONFORMITY AND CE MARKING FOR PRODUCTS THAT CONFORM WITH EUROPEAN COM- MUNITY DIRECTIVES.
