- Page 1 SHHP75 FLOOR STANDING HYDRAULIC PRESS OWNER’S MANUAL 75 TON MAX CAPACITY FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
-
Page 2: Specification
Do not use the press to compress springs or any other item that could disengage and cause a potential hazard. Use a qualified person to maintain the press in good condition. Keep it clean for safe and optimum performance. WWW.SGS-ENGINEERING.COM PAGE 2... - Page 3 SAFETY INSTRUCTIONS Do not exceed the rated capacity. Never apply excessive force to a work piece and always use the pressure gauge to accurately determine the applied load. Use this press for the purpose which it is intended. Do not use it for any purpose it is not designed to perform.
-
Page 4: Before First Use
Close the release valve BEFORE FIRST USE Before first use of this press purge any air from the hydraulic system. Check all parts and conditions – if there is any broken part stop using the press and contact sgs engineering immediately. WWW.SGS-ENGINEERING.COM... -
Page 5: Maintenance
OPERATING INSTRUCTIONS Place the heel block on the press bed frame, then insert the work piece onto the heel block. Close the release valve by turning it clockwise until it is firmly closed. Pump the handle until the serrated saddle nears the work piece. Align the work piece and ram to ensure centre-loading. - Page 6 STRETCH WASHER 15 CONNECTION BAR BEARING 6202-2Z SHORT ROLLER SHAFT BOLT M6X10 CYLINDER PIPE RAM FIXUP ASSEMBLY PRESSURE GAUGE OIL PIPE BED FRAME PIN PLASTIC SUPPORT BEAM MANOMETER CONNECTOR BOLT M12X35 O-RING 5X1.8 STRETCH WASHER 12 HEXAGONAL M20X2 WWW.SGS-ENGINEERING.COM PAGE 6...
- Page 7 PAGE 7...
- Page 8 O-RING RELEASE VALVE ASSEMBLY O-RING HANDLE SOCKET HANDLE SOCKET PIN TORSION SPRING PIN AIR PUMP BOLT O-RING 8.5X2.65 PLASTIC TUBE WASHER SPRING FOR SAFETY VALVE PRESSURE BOARD AIR PUMP SEAL KIT BALL 10,0000 G200 FASTEN BOLT M12X12 WWW.SGS-ENGINEERING.COM PAGE 8...
- Page 9 ITEM DESCRIPTION STRAIGHT CONNECTOR RAM UNIT O-RING B10X95 RETURN SPRING GUIDE SLEEVE PISTON HEAD Y-RING FOR PISTON Y-TYPE CUP HEAD O-RING 76.5X2.5 HATCH SEAL PISTON ROD GUIDE SLEEVE O-RING 145X5.3 O-RING 92.5X5.3 FLAT WASHER BOLT M10X80 SEAL KIT ZG1/2 BOLT M10X10 SHAFT STEEL BALL 6,000 G200...
- Page 10 SGS Engineering is committed to designing, manufacturing, and market- ing products that meet or exceed the needs of the customers we serve. SGS engineering can supply a letter of incorporation or a declaration of conformity and CE marking for products that conform with European com- munity directives.
- Page 11 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Hydraulic Press TYPE OF EQUIPMENT: SHHP75 PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
