In the event of a breakdown
Model C
1. Daytime running lamps/sidelamps (LED).
2. Direction indicators (WY21W).
3. Dipped beam headlamps (H7-55W).
4. Main beam headlamps (HB3-65W).
5. Front foglamps (P21W).
Opening the bonnet/Access to bulbs
With the engine warm, proceed with
caution – Risk of burns!
Take care with objects or clothing that
could be caught in the blades of the
engine fan – Risk of strangulation!
208
Direction indicators (halogen
headlamps)
Rapid flashing of a direction indicator
lamp (left or right) indicates that one of
the bulbs on the corresponding side has
failed.
F Turn the bulb holder a quarter turn anti-
clockwise.
F Pull the bulb and bulb holder assembly
rearwards.
F Replace the bulb.
To refit, carry out these operations in reverse
order.
Amber coloured bulbs, such as the
direction indicators, must be replaced
by bulbs with identical colour and
specifications.
Main beam headlamps (halogen
headlamps)
F Remove the protective cover.
F Disconnect the bulb connector.
F Turn the bulb holder anti-clockwise.
F Remove the bulb and replace it.
To refit, carry out these operations in reverse
order. When refitting, close the protective cover
very carefully to guarantee the sealing of the
lamp.
