Summary of Contents for Reiner jetStamp 1025

  • Page 2: Table Of Contents

    4.6.2 Install softw are ................................24 4.7 Firmware update ........................... 25 V The PCset graphic software application 5.1 Get jetStamp 1025 ready for PCset graphic ........................... 26 5.2 Starting the software ........................... 27 © ERNST REINER GmbH & Co. KG...
  • Page 3 Context menu numbering machine object ................................. 57 5.7.3.2 5.7.4 Barcode ................................58 Presettings ................................. 58 5.7.4.1 Consecutive numbering/dating ................................. 61 5.7.4.2 Context menu barcode object ................................. 62 5.7.4.3 Generate graphic ................................. 62 5.7.4.4 © ERNST REINER GmbH & Co. KG...
  • Page 4 ........................... 75 VIII Technical Data and Accessories 8.1 Type Plate ........................... 76 8.2 Technical Data ........................... 77 8.3 Transport and Disposal ........................... 78 8.4 Accessories ........................... 78 IX Contact X Operating instructions Index © ERNST REINER GmbH & Co. KG...

  • Page 5: I Your Jetstamp 1025

    Your jetStamp 1025 Your jetStamp 1025 © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 6: Operating Elements

    PCset graphic Hilfe jetStamp 1025 Operating elements © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 7 Your jetStamp 1025 © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 8 Locking mechanism print cartridge Seal tip Print cartridge contacts Nozzles print cartridge Description Operating status LED Permanently lit "green" Device is active. Short flashing in 4 seconds interval Device is in energy-saving mode. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 9: Display And Button Functions

    Mains adapter connected Battery level Battery is charging B Set print image Menu bar with menu items and commands Home Access to the main menu. Next page Forward/back through print images or menu. © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 10 Returns to the previous display (submenu / main menu / exit from main menu). Selection Enters the selected menu Confirms entries and completes function settings. Four push-buttons Each button is always assigned to the menu item or command displayed in the menu bar above © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 11: Main Menu

    Settings 1.3.1 Quick functions Test print By selecting the jetStamp 1025 executes a test print of the selected print image. Rep. last print image By selecting the jetStamp 1025 executes the last executed imprint again. Reset numb. machine By selecting the jetStamp 1025 resets the numbering machine.

  • Page 12: Change Position

    Date/Time Factory settings 1.3.6.1 Signals Warning sounds By selecting the jetStamp 1025 switches the acoustic signals on/off in case of warnings. Error sounds By selecting the jetStamp 1025 switches the acoustic signals on/off in case of device errors. Button sounds By selecting the jetStamp 1025 switches the button sounds on/off.

  • Page 13: Date/Time

    Your jetStamp 1025 Lock device after Setting the time after which the jetStamp 1025 is locked again. 1.3.6.4 Date/Time Change clock Setting the time of the jetStamp 1025. Summertime Setting the summer time. 1.3.6.5 Factory settings Reset By selecting the jetStamp 1025 is reset to the delivery state.

  • Page 14: Important Notes

    PCset graphic Hilfe jetStamp 1025 Important Notes Before commissioning of the jetStamp 1025, always read the operating instructions and in particular the safety notes with care. This prevents insecurities in handling of the marking devices and connected safety risks to keep you safe and avoid damage to the device.

  • Page 15: Your Safety

    Warnings of dangers that may lead to property damage if not observed. You are asked to perform actions here. Notes and advice to make handling your jetStamp 1025 even easier. Notes on instruction videos. © ERNST REINER GmbH & Co. KG...

  • Page 16: Safety Notes On Rechargeable Batteries

    Type usage Use only the supplied mains adapter or a PC USB port to charge the batteries. Only use rechargeable batteries (four each) of the type nickel metal hydride (REINER item number: 946 192 - 000) of the type AA.

  • Page 17: Safety Notes

    Safe handling of print cartridges Possible blindness due to eye contact with ink. Do not point the jetStamp 1025 nozzles against people's faces! Damage to health caused by ingestion of ink. Do not swallow! Keep the print cartridge out of the reach of children! ©...

  • Page 18: Prepare And Commission

    Firmware update Commissioning The device may only be switched off via the ON/OFF button Switching off by removing the rechargeable battery can lead to data loss. Insert rechargeable batteries Charge rechargeable batteries © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 19: Insert Rechargeable Batteries

    Open flap for battery and print cartridge compartment Push the battery compartment locking upwards until the locking can be opened. Open battery compartment Ensure correct polarity and insert batteries. Close battery compartment © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 20: Charge Rechargeable Batteries

    Connect the mains adapter of the device to the connection socket provided for the mains adapter and connect it to the mains. Green charging indicator lights up. Charging is complete when the charging indicator is off. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 21: Insert Print Cartridge

    Press function button for print cartridge Print carriage moves to the right into the change position. Open flap for battery and print cartridge compartment Push the print cartridge locking slightly upwards and open it. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 22: Execute Test Print

    Execute test print Possible blindness due to eye contact with ink. Execute test print Fig. The jetStamp 1025 is delivered with several pre-programmed sample print images. Switch on the device via the ON/OFF button The operating status LED lights up green.

  • Page 23: Saved Print Images

    To activate Bluetooth, press the Home button, select Bluetooth on display in the menu - Bluetooth -and select Activate Bluetooth To establish the Bluetooth connection with the device, follow the instructions "Establish Bluetooth connection". © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 24: Install Pcset Graphic Software

    If the installation program does not start automatically, start the file "Setup_PCsetgraphic.exe". Follow the instructions of the installation program. You can also download the software on our homepage in the products area jetStamp 1025 by clicking Downloads - Software PCset graphic.

  • Page 25: Firmware Update

    Ensure that the PCset graphic is installed on your PC but not opened before the firmware update is started. While the firmware update is being installed, the jetStamp 1025 must not be switched off or removed from the supply voltage.

  • Page 26: The Pcset Graphic Software Application

    PCset graphic Hilfe jetStamp 1025 The PCset graphic software application Get jetStamp 1025 ready for PCset graphic Starting the software Operator interface Establish Bluetooth connection Example workflow: Generate print image Objects settings External print triggering Supported REINER devices - jetStamp 1025...

  • Page 27: Starting The Software

    To turn on the device, press the ON/OFF button The operating status LED lights up green. The PC recognises the jetStamp 1025 as a new USB device. The device driver software is installed automatically. Starting the software Double-click the REINER PCset graphic icon The PCset graphic software is started.

  • Page 28: Menu Bar

    Displays an overview of the print images in the device. Print image management Search for REINER Bluetooth Searches for REINER Bluetooth devices. devices Last opened Displays the most recently opened print images. Exit Exits the PCset graphic. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 29: Edit

    Settings for date/time objects can be configured. Numbering machine Settings for numbering machine objects can be configured. Barcode Settings for barcode objects can be configured. 5.3.1.5 Format Opens the settings of the selected object. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 30: Extras

    Help with detailed configuration instructions and the operating instructions in electronic form. Info Release notes for the software. If the jetStamp 1025 is connected, information on model, serial number, firmware version and device options are also displayed. 5.3.2 Toolbar Toolbar Menu command Description Reset the display.

  • Page 31: Grid

    The PCset graphic software application Displays the device settings. Device settings Transfer The displayed print image is transferred to the device. The current print image on the jetStamp 1025 is shifted backwards. Upload Load the current print image of the jetStamp 1025 for editing.

  • Page 32: Objects

    Various barcode formats are available in the format settings (refer to "Presettings"). Graphic After inserting a graphic object, a file selection window opens. Select the desired graphic and confirm with "Open". 5.3.4 Device safety Device safety Unlock device Lock device © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 33: Device Safety

    Print images cannot be transmitted and printed without entering a password. Device safety is activated. Print images can be transmitted and printed without entering a password. Set password Disable password protection Forgotten password © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 34: 5.3.4.1.1 Set Passw Ord

    To ensure the safety of the device deactivate in the menu bar the tabSelect "Extras" and "Device safety Click on Set password". Click on "Deactivate password protection". In the toolbar the symbol changes from © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 35: 5.3.4.1.3 Forgotten Passw Ord

    The PCset graphic software application 5.3.4.1.3 Forgotten passw ord When resetting the password, the jetStamp 1025 is reset to the factory setting. All saved print images are deleted. The password can only be reset when the jetStamp 1025 has no device error.

  • Page 36: Device Settings

    In the status indicator and in the toolbar the symbol changes from 5.3.5 Device settings The device settings can only be selected when a jetStamp 1025 is connected to the PC. Click on the symbol. The device settings are opened. Print settings...

  • Page 37: Signals

    The print cartridge never moves onto the seal. Time after the print cartridge enters the Depending on the time set, the print cartridge moves capping station back onto the seal after a printing process. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 38: Status Indicators

    Connection is established via Connection is established via Bluetooth Indicates the fill level of the print Ink level indicator cartridge in % Indicates the state of charge of Charge indicator the battery © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 39 Online Bluetooth Device is connected via Bluetooth Offline - Device not switched on - USB cable not plugged in - Rechargeable battery empty Here you will find hints for Device messages troubleshooting © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 40: Device Messages

    Insert print cartridge correctly Please remove the print - Print cartridge not inserted cartridge and re-insert it correctly Charge battery Please recharge battery - Rechargeable battery empty Inserting/replacing the battery - No battery/defective battery © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 41 If the error remains after activation, have the device inspected by the REINER support. Warnings displayed in a message box Warnings Cause Correction Check device/connections and Transfer error Device defective or missing try again connection © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 42: Enable Print Image Preview In Windows Explorer

    The Windows Explorer offers the possibility to preview files. The following illustrations show how the preview can be switched on: Figure 1 Print image preview in Windows Explorer Figure 2 Print image preview in the Open dialogue © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 43: Establish Bluetooth Connection

    All devices found, as well as all devices that have already been connected to the PCset graphic, are displayed with model and serial number. If the jetStamp 1025 is not found, a new search run can be started with the "Search again" button.

  • Page 44: Example Workflow: Generate Print Image

    RPSG files ("Menu commands"). Configure print image Transfer print image to jetStamp 1025 Print the print image Number of imprints 5.6.1 Configure print image Insert text and date/time...

  • Page 45: Transfer Print Image To Jetstamp 1025

    Click on the transfer icon If the transfer was successful, the following message appears after a few seconds: Confirm the message with OK. The print image is stored in the jetStamp 1025 and can be printed. 5.6.2.1 Replace print image...

  • Page 46: Print The Print Image

    PCset graphic Hilfe jetStamp 1025 Confirm the message with OK. The print image is stored in the jetStamp 1025 and can be printed. 5.6.3 Print the print image Possible blindness due to eye contact with ink. Print the print image Fig.

  • Page 47: Number Of Imprints

    The PCset graphic software application 5.6.4 Number of imprints The number of possible imprints with a full print cartridge is displayed by positioning the mouse pointer on the print image number. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 48: Objects Settings

    If the grid is enabled, the font size is adjusted. Example: If a grid of 40 pixels is set, the text object has a height of 40 pixels. Presettings Context menu text object Generate graphic © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 49: Presettings

    Context menu text object If a text object is inserted ("Objects"), the configuration corresponds to the default settings (refer to "Presettings"). Each text object can be changed individually via the context menu. © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 50 Note: the text cannot be processed anymore after conversion. Delete object Deletes the object. Press Ctrl+Enter to jump to the next line. Enter or double-click fixes the object, which then can no longer be edited. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 51: Generate Graphic

    The date/time format can be globally pre-set. Additionally, deviating settings can be performed for every single date/clock time object ("Context menu date/clock time object"). A maximum of five date/time objects can be placed. Presettings Context menu date/time object © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 52: Presettings

    "Presettings" tab and click "Date/time". The configuration window for date and time appears. The tab "Date and time" is divided into two sections: - Format for date and time. - Font Tab date and time Font © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 53: 5.7.2.1.1 Tab Date And Time

    Calendar day with three digits (001 to 365) Example: 28 May 2019 = 148.2019 Month of the year with two digits (01 to 12) Abbreviation for the month (up to 4 characters) © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 54: 5.7.2.1.2 Font

    Two characters for twelve-hour format with the letters AM or PM 5.7.2.1.2 Font Selection option between "Figure style1" and "Figure style 2". "Font 1" and "Font 2" are in the toolbar via the button © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 55: Context Menu Date/Time Object

    Note: The following configuration can produce nonsensical print images: - Print sequence "Print lines in sequences" - Numbering machines linked to each other, each with different repetitions Presettings Context menu numbering machine object © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 56: Presettings

    - Number circle - Font Numbering machine range Number circle 5.7.3.1.1 Numbering machine range Function Description Step Indicates the interval at which the numbering machine counts on (e.g. 1,4,7... in steps of 3). © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 57: 5.7.3.1.2 Number Circle

    ("Presettings"). Each numbering machine object can be changed individually via the context menu. To open the context menu, right-click the desired numbering machine object. The context menu opens as in the following figure: © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 58: Barcode

    Global presettings can be set in the menu bar via the "Presettings Barcode" tab. - OR - Settings of already-inserted barcode objects can be called via the right mouse button "Barcode Format". The configuration window for barcode appears. © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 59 Indicates the character sequence without control characters. Parameter Function Description Display plain text Inserts plain text below the barcode. The plain text is the character sequence that has been entered into the barcode object. © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 60 Ratio of wide to narrow element in calculation of the code length. Module ratio Start and stop characters for the barcode type coda bar. (2/5 matrix) May contain letters A - D. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 61: Consecutive Numbering/Dating

    Make the desired settings and confirm with OK. To save the settings made, click OK. The red dash below the editing field determines the inserted position of the date/time and numbering machine object. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 62: Context Menu Barcode Object

    Text and barcode objects can be converted into graphics. Graphics are fixed and can no longer be moved. Limited editing is possible via the additional function "Selection". Click the object with the right mouse button. Select "Generate graphic". The object has been converted to a graphic. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 63: Graphic

    300 dpi so that the imprint can be produced in optimal quality. For a distortion-free printout in optimal quality, a graphic should not exceed the maximum height of 300 pixels and the maximum width of 1000 pixels. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 64: Context Menu Graphic Object

    Text and barcode objects can be converted into graphics. Graphics are fixed and can no longer be moved. Limited editing is possible via the additional function "Selection". Click the object with the right mouse button. Select "Generate graphic". The object has been converted to a graphic. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 65: External Print Triggering

    The PCset graphic software application External print triggering REINER special accessories are available for external trigger types. Triggering via external switch 5.8.1 Triggering via external switch For triggering via an external switch, the contacts in the jack socket must be short-circuited.

  • Page 66: Maintenance

    Different seals are required depending on the type of ink used (refer to "Replacing the seal"). Use seal of the enclosed print cartridge. Damage to health caused by ingestion of ink. Changing the print cartridge Fig. © ERNST REINER GmbH & Co. KG Originalanleitung...
  • Page 67 The print carriage returns to the basic position. The change position can also be selected via the display menu. In the basic position, drying of the ink is prevented (refer to "Clean nozzles"). © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 68: Cleaning The Contacts Of The Print Cartridge

    Remove the print cartridge from the device. Clean the contacts on the print cartridge with a soft cloth slightly soaked in ethanol (spirit). Hold print cartridge locking © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 69: Clean Nozzles

    Clean nozzles If there are streaks in the imprint or problems with the print quality, the ink may have dried on the nozzles Imprint without streaking Imprint with streaking Manual nozzle cleaning © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 70: Manual Nozzle Cleaning

    To dissolve the dried ink, press a soft cloth slightly soaked in ethanol (spirit) against the nozzles for about three seconds. Wipe off dissolved ink and dry nozzles For further information (also refer to "Cleaning the contacts of the print cartridge"). © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 71: Clean Seal

    Replacing the seal Replacing the seal Fig. Different seals are required depending on the type of ink used. - Inkjet print cartridge P5-S3-BK: use red seal - Inkjet print cartridge P5-MP3-BK: use blue seal © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 72: Clean Housing

    Clean housing If liquids come into contact with the inside of the device, it may cause an electric shock. Cleaning agents that are too aggressive may damage the housing surface. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 73: Recognising And Removing Interferences

    Fig. Disconnect mains cable from jetStamp 1025. Open the battery compartment locking Wait about 3 seconds. Close the battery compartment again. Connecting the mains cable to the jetStamp 1025 Start PCset graphic. Check charge indicator. © ERNST REINER GmbH & Co. KG...

  • Page 74: Causes For Uncharged Batteries

    The print image was not transferred. The interrupted data transfer between PC and device was interrupted. Print carriage Confirm The print carriage movement has blocked. movement blocked Possibly due to an obstacle or heavy soiling. © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 75: Correctable Error Messages

    The device must be unlocked by entering a password via the PCset graphic or the device menu. Device error messages Message Eliminate message by Device error xx Switch the device off and on © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 76: Technical Data And Accessories

    Mod. = Model = Serial number = Quality control = jetStamp 1025 has the CE-mark according to the currently valid low-voltage and EMC directive. = jetStamp 1025 is in accordance with the following standards or standardised documents FCC 47 CFR Ch.1 Part 15 Bluetooth: FCC: R7TAMB2300.

  • Page 77: Technical Data

    USB, Bluetooth or micro SD card Power supply 4 x AA NiMH rechargeable batteries; chargeable via included mains adapter. Input: 100 - 240 VAC, 50 - 60 Hz, 0,4 A Output: 12 VDC 1,3 A © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 78: Transport And Disposal

    Old devices must not be disposed of in the common household waste but in a specified acceptance point for recycling of electrical and electronic devices. Accessories Inkjet print cartridge Order no. P5-S3-BK: 1 037 100-000 Inkjet print cartridge MP3 (fast drying) Order no. P5-MP3-BK: 1 037 100-120 © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 79: Contact

    © 2019 Ernst Reiner GmbH & Co. KG All rights reserved. Translation, reprint and other reproduction of these operating instructions, even in parts and no matter the form, shall require our express written consent. We reserve the right to make content changes to these operating instructions without notice.

  • Page 80: Operating Instructions

    PCset graphic Hilfe jetStamp 1025 Operating instructions © ERNST REINER GmbH & Co. KG Originalanleitung...

  • Page 81: Index

    12 - N - Disable password protection 34 Display and button functions 9 Numbering machine 55 Disposal 78 - O - - E - Objects 32 Establish Bluetooth connection 43 © ERNST REINER GmbH & Co. KG...
  • Page 82 Safety notes on rechargeable batteries 16 Safety, Description 15 Saved print images 23 Set password 34 Settings 12 Date/Time 13 Device security 12 Factory settings 13 Print 12 Signals 12 Signals 37 All Acoustic Signal 12 © ERNST REINER GmbH & Co. KG...
  • Page 83 .reiner.de...
