Aaeon PCM-8152 3rd Generation Installation Instructions Manual

For m15-6 to m15-10 consoles

Advertisement

TB230 (Rev1) - PCM-8152 3rd Generation Aaeon motherboard kit Installation
Instructions for M15-6 to M15-10 Consoles
Introduction: This document will provide you with the necessary instructions to install a PCM-8152 motherboard kit in an M15-6
through M15-10 console. Make sure you read the entire document before going to do the install.

Materials List:

PCM-8152 motherboard
PC104 extender board
DVI to TTL daughter board and cable
LCD cable and descrambler shaped bracket
1Gb DDR RAM
80 strand IDE cable
PS2 keyboard & mouse cable
COM port ribbon cable
2 port USB cable
RJ45 Ethernet cable
300W ATX PS w/ brackets and power cable
SSHD w/ Linux software install mounted on bracket
Motherboard mounting plate
5x 6-32x1/2 standoffs with threaded holes on both ends
4x 6-32x1/2 standoffs
4x custom 5mm offset standoffs
4x 6-32x1 standoffs
4x 6-32x1/2 setscrews
3x DB9 ribbon cable extenders
USB connector panel
DB25, KB, & Ethernet blank out covers
Console fan/DP4 power cable
Drive/inverter power cable
60cfm 80mm fan w/ Molex connector
2x L-brackets for mounting 80mm fan
Note: The kit will come with the Aaeon MB and 80mm fan mounted to the mounting plate and the special standoffs mounted onto the
MB.

Procedure:

1. Remove floppy drive bay, CPU7, MB, and power supply from M15.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCM-8152 3rd Generation and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aaeon PCM-8152 3rd Generation

  • Page 1 60cfm 80mm fan w/ Molex connector 2x L-brackets for mounting 80mm fan Note: The kit will come with the Aaeon MB and 80mm fan mounted to the mounting plate and the special standoffs mounted onto the Procedure: 1. Remove floppy drive bay, CPU7, MB, and power supply from M15.
  • Page 2 2. Mark and drill the 4 holes for the motherboard mounting plate. (see picture 1) Picture 1: Red circles indicate the 4 holes you need to mark on the M15 base to drill and mount the MB mounting plate. 3. Position the ATX power supply so the fan is blowing towards the MB. Make sure the angle bracket is on the bottom of the ATX PS and mark your two holes.
  • Page 3 7. Connect ATX power connector into MB and LCD cable into the LCD, and then connect the ATX PS to the 80mm fan, the console fan/digitizer power cable, and the inverter/drive power cable. Power up the MB and verify it powers on. If that looks ok, install the CPU7P3 card into the PC104 socket and connect the IDE cable to the SSHD.
  • Page 4 9. Mount USB cables, Ethernet, KB and mouse connectors to I/O panel. Take the floppy drive bay and flip it 180 degrees from its normal orientation, so the bottom is against the side wall of the M15. Mount the SSHD into the floppy drive bay. Place the I/O panel where the plastic went for the floppy drive door, then place the floppy drive bay against the I/O panel and secure from the back with 6- 32 screws.
  • Page 5 PCM-8152 Motherboard Connection Diagram...
  • Page 6 PCM-8152 Motherboard Connection Table Connector Label Function TV_Out Connector Audio SPDIF Connector Internal LVDS Connector ATX Power Connector Extension LVDS Connector (Optional) DVI Connector Audio Connector LAN LED Connector CN10 COM1-4 Connector CN11 CPU Fan Connector CN12 Digital I/O-1 Connector (801H) CN13 Digital I/O-2 Connector (800H) CN16...
