DAWs Without Proprietary Soundcards
For software which can send and receive audio via any soundcard connected to the computer, Nucleus can be connected
directly to the DAW using the USB connection.
DAW
Computer
Ethernet
(DAW control
and Remote)
Nucleus Owner's Manual
Monitoring
USB
(Soundcard and
DAW keyboard
commands)
Note.
Socket locations are approximate
Headphones
Recording
Sources
MP3
Player
Mains
Power
Page 7
