No. Item Description
Displays BUC information summary of
each antenna.
- RF Output: Displays RF Output level.
- TX State: Displays Transmit
State(STANDBY, TRANSMIT,
TRANSMIT INHIBIT, WARM-UP).
BUC
• STANDBY: Transmit standby state.
Information
2
• TRANSMIT: Transmit active
Summary
state(On).
• TRANSMIT INHIBIT: Transmit
Inhibit state, Transmit Control I/O
not active state(Off).
• WARM-UP: Power is turning on.
- Attenuator: Displays attenuation value.
The Amp Status, Amp Information,
Antenna Set points, Config and IP Settings can
3
1/2/3 be activated by using MEO(Ka-band)
Satellite.
- Amp Status: Displays Amp
Status(FAULT, POWER ON. READY).
• FAULT: Amp is faulty.
• POWER ON: BUC power is turning
Amp on.
4
• READY: Amp is in operation.
Status
- Control: Displays BUC control
method(REMOTE ALL, REMOTE
ETHERNET, REMOTE SERIAL,
REMOTE WEB).
No. Item Description
• REMOTE ALL(Default): Control
BUC via Remote Ethernet, Remote
Serial and Web.
• REMOTE ETHERNET: Control BUC
via Remote Ethernet.
• REMOTE SERIAL: Control BUC via
Remote Serial.
• REMOTE WEB: Control BUC via
Remote Web.
- RF Output: BUC Output level.
- TX State: Select the Transmit
State(STANDBY, TRANSMIT) in the
drop-down list.
Amp
• STANDBY: Transmit standby state.
4
Status • TRANSMIT: Transmit active
state(On).
- Power Mode: Select the Power
Mode to control the transmit
power(MANUAL, ALC(Automatic
Level Control), Reset Fault) in the
drop-down list.
• MANUAL: Output the power as
Manual RF Set Pt.
• ALC(Automatic Level Control):
Output the power as modem
output level(Transmit).
- Reset Fault: Reset the BUC Fault
state.
