Dual TVRO Mediator
Installation and Operation User Guide
Doc. No.: UM-TM-170331-V1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dual TVRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Intellian Dual TVRO

  • Page 1 Dual TVRO Mediator Installation and Operation User Guide Doc. No.: UM-TM-170331-V1.2...
  • Page 2: Antenna

    Information in this document is subject to change without notice. Every effort has been made to ensure that the information in this manual is accurate. Intellian is not responsible for printing or clerical errors.
  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION INTELLIAN DUAL TVRO MEDIATOR COMPONENTS LIST DUAL TVRO MEDIATOR INSTALLATION FRONT AND REAR PANELS OF THE MEDIATOR DIMENSIONS INSTALLATION SITE THE LED STATUS LIGHTS CONNECT THE CABLES ANTENNA 1 ANTENNA 2 MULTI-SWITCH WARRANTY SPECIFICATION...
  • Page 4: Introduction

    Intellian Dual TVRO Mediator Introduction Components List Intellian Dual TVRO Mediator Intellian’s Dual TVRO Mediator is designed for a ship that has two Item Image Q’ty Description Size Remark Intellian Satellite TV Antenna Systems. Intellian Mediator will compare the satellite signal receptions between the 2 antennas and switch to the...
  • Page 5: Dual Tvro Mediator Installation

    Dual TVRO Mediator Installation You will need to wire the Intellian Satellite TV Antenna System differently than specified in its original manual. These instructions will require Front and Rear Panels of the Mediator you to do additional installation steps. The following instructions and...
  • Page 6: Installation Site

    Intellian Dual TVRO Mediator Installation Site The LED Status Lights The Mediator should be installed below deck, in a location that is 1. Power – Red: Mediator is powered up • Dry, cool, and ventilated. • Easily accessible from your main TV viewing area.
  • Page 7: Connect The Cables

    (Not Supplied) (Not Supplied) (Not Supplied) (Not Supplied) (Not Supplied) (Not Supplied) (Not Supplied) IRD 1 IRD 2 IRD 3 IRD 4 IRD 5 IRD 6 IRD 7 IRD 8 * TV, IRD and Multiswitch are not supplied by Intellian...
  • Page 8: Antenna

    Intellian Dual TVRO Mediator Antenna 1 1. Connect the coaxial cable from the RF1 connector on the antenna to Antenna1 the ANTENNA connector on the ACU1. 2. Connect the coaxial cable from the RECEIVER connector on the ACU1 to the RF1’s ANT1 connector on the Mediator.
  • Page 9: Antenna 2

    Antenna 2 1. Connect the coaxial cable from the RF1 connector on the antenna to Antenna2 the ANTENNA connector on the ACU2. 2. Connect the coaxial cable from the RECEIVER connector on the ACU2 to the RF1’s ANT2 connector on the Mediator. 3.
  • Page 10: Multi-Switch

    Intellian Dual TVRO Mediator Multi-switch Intellian recommends that an ACTIVE multiswitch be used in all installations. 1. Connect the four IF cables from the four RECEIVER connectors on the Mediator to the 4 input connectors on the multiswitch. 2. Connect the IF cable from the output connector on the multiswitch to the ‘Satellite In’/ ‘ANT’...
  • Page 11: Warranty

    Warranty This product is warranted by Intellian Technologies Inc., to be free from defects in materials and workmanship for a period of THREE (3) YEARS on parts and TWO (2) YEARS on labor performed at Intellian Technologies, Inc. service center from the purchased date of the product.
